Setting Bass Sound Control
1
Check that Defeat mode is off (page 26).
2
Touch [SETUP] on the main source screen.
The SETUP selection screen is displayed.
3
Touch [AUDIO].
The AUDIO SETUP screen appears.
4
Touch [
] of A.PROC.
The A.PROCESSOR list is displayed.
5
Touch [
] of BASS SOUND CONT.
The BASS SOUND CONT screen appears.
Setting Bass Compressor
You can adjust the sound of low frequencies as desired.
6
Touch [ ] or [ ] of BASS COMP. to select the
desired mode.
Bass sound is emphasized more as the mode is
sequentially switched as MODE 1
vivid low frequencies.
Select OFF when the setting is not necessary.
Touch [RETURN] to return to the previous screen.
Setting Bass Focus
Using the previously specified delay number (time difference) allows
you to set a time difference between the front-rear/left-right speakers.
Namely, it enables a time correction based on your preference. With an
initial delay of 0.1 ms for each of the 0 to 200 steps, audible time
correction can be achieved.
6
Set the delay number in the front and rear, and on
the right and left of the desired speaker by touching
the respective [ ] or [ ] button.
• Any setting in Bass Focus is applied in time correction, too
(pages 43-44).
• Touch [RETURN] to return to the previous screen.
46
-EN
2
3, offering you
Autogood products internet store http://130.com.ua
Speaker Setup
The PXA-H700 or PXA-H701 can be set according to the playable
frequency range of your speakers.
Check the playable frequency range of the speakers (not including the
subwoofer) before performing this operation to verify whether the
speakers can play low frequencies (of about 80 Hz or less).
• Avoid stopping, pausing, switching the disc, cueing, fast-forwarding
or switching the audio channel of this unit while making this
adjustment. The setting is cancelled if Decode mode is switched.
1
Check that Defeat mode is off.
2
Touch [SETUP] on the main source screen.
The SETUP selection screen appears.
3
Touch [AUDIO].
The AUDIO SETUP screen will appear.
4
Touch [
] of A.PROC.
The A.PROCESSOR list screen appears.
5
Touch [
] of SPEAKER SETUP.
The adjusting screen of SPEAKER SETUP appears.
6
Select the speaker characteristic by touching [ ],
[ ] of the desired speaker setting.
1
*
When no speaker is connected.
OFF
:
SMALL:
When a speaker that cannot play low frequencies
(80 Hz or less) is connected.
2
LARGE
*
: When a speaker that can play low frequencies
(80 Hz or less) is connected.
1
*
It is not possible to set the front speakers to "OFF".
2
*
If the front speakers are set to "SMALL", the rear and
centre speakers cannot be set to "LARGE".
• The subwoofer can be set only to ON/OFF.
• If the centre speaker is turned "OFF", the centre channel's audio
signals are added to the audio signals output from the front speakers.
• If you set the speaker response to "OFF", also set the speaker setting
to "OFF" (page 42).
• Perform the setup for all the speakers ("Front", "Centre", "Rear"
and "Subwoofer"). If not, the sound may not be balanced.
• When centre is set to "OFF", the setting is ineffective even if centre
is set with this function.
• Through changing the settings on each speaker, a change in the
output of the other speakers may occur due to the setting
requirements.
• When using the PRO LOGIC II, if the rear speaker is set to
"LARGE", then there will be no output from the subwoofer.
