Summary of Contents for CDA DC740
- Page 1 DC940 Built-In Double Oven Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu...
- Page 2 Any other use could be dangerous and may lead to premature failure of the appliance. The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance.
- Page 3 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model Serial Number...
- Page 4 Disposing of a household appliance separately avoids possible negative consequences for the environment and health deriving from inappropriate disposal and enables the constituent materials to be recovered to obtain significant savings in energy and resources. As a reminder of the need to dispose of household appliances separately, the product is marked with a crossed-out wheeled dustbin.
-
Page 5: First Use Of The Oven
• Do not place hot enamel parts in water. Leave them to cool first. • Do not allow vinegar, coffee, milk, saltwater, lemon or tomato juice to remain in contact with enamel parts. • Do not use abrasive cleaners or powders that will scratch the surface of the enamel. -
Page 6: Oven Controls And Use
60 minutes conventional Lower oven 60 minutes fan oven Please note: • This oven has been fitted with a cooling fan to achieve maximum efficiency and to maintain low surface temperatures. • The cooling fan will switch on automatically when the oven is switched on and runs for a while after the oven has been switched off - the length of time can vary and will be increased by poor ventilation. - Page 7 Conventional oven This function uses the top and bottom heating elements only with a temperature between 50ºC and 250ºC. Natural convection creates a perfect cooking zone in the centre of the oven, ideal for dark fruit cakes and pastries. Warming oven This function uses the bottom heating element only with a temperature set between 50ºC and 250ºC.
- Page 8 Defrost Using the fan only this oven function circulates the air around the oven cavity, speeding up the natural defrost process (1kg takes approximately one hour, depending on the type of food). Fan Oven Using the circular element and the fan with a temperature between 50ºC and 250ºC, this cooking function blows the air into and around the oven cavity.
-
Page 9: Setting The Clock
Programming the Oven Please note: • The semi-automatic and automatic cooking programmes will only work with the main oven. • The alert beep will cut off after two minutes if it is not switched off manually. 1 Cooking time indicator 2 End of cooking time indicator 3 Minute minder indicator Setting the clock... - Page 10 The minute minder The minute minder can be used when the oven is switched on or off. It can be set for up to 23 hours and 59 minutes. To set the minute minder: • Touch repeatedly until the minute minder indicator flashes. •...
-
Page 11: Programming The Oven
Programming the Oven Semi-automatic cooking The main oven can be set to switch off automatically at a preset time up to a maximum of 10 hours. To set a semi-automatic cooking programme: • Select the oven function and temperature (the oven will switch on). •... -
Page 12: Care And Maintenance
• Touch until the end of cooking time indicator flashes. • Then touch to select the required end of cooking time. When the correct time shows on the display, wait for approximately five seconds. The cooking time and end of cooking time indicators will remain lit to confirm the automatic programme is on. - Page 13 Proprietary stainless steel cleaners are available. We recommend the CDA E-Cloth available from the CDA Sales Team for cleaning stainless steel surfaces as this has been designed to prolong the finish of your appliance. Inside of Oven The oven should always be cleaned after use when it has cooled down.
-
Page 14: Changing The Oven Lamp
Changing the Oven Lamp Before any maintenance is started involving electrical parts, the appliance must be disconnected from the power supply. If the oven has been in use, let the oven cavity and the heating elements cool down before attempting any maintenance. - Page 15 IMPORTANT Never use screwdrivers or other utensils to remove the light cover. This could damage the enamel of the oven or the lamp holder. Remove only by hand. IMPORTANT Never replace the bulb with bare hands as contamination from your fingers can cause premature failure.
-
Page 16: Oven Door
Oven Door Removing the Oven Door The oven door can easily be removed as follows: • Open the door to the full extent (fig. 4). • Open the lever A completely on the fig. 3 left and right hinges (fig. 5). •... -
Page 17: Mains Electricity Connection
Mains Electricity Connection Warning! This appliance must be earthed To connect this appliance to a UK standard mains supply, connect the bridging links between 1-2-3 for the live feed and 4-5 for the neutral feed. We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. - Page 18 Feed the mains lead through the Green/yellow cable clamp to prevent accidental Blue disconnection. Brown Tighten the cable clamp securely and close the connector cover. Green and Yellow = Earth (PE) Fig.9 Blue = Neutral Brown = Live Please note: •...
-
Page 19: Installation
How to install your oven You will need the following housing area fit your oven correctly. DC740 only: We recommend that you fit end support panels onto the adjacent units to allow the oven to be secured in place (as shown in... -
Page 20: Dimensions
DC740 DC940 Dimensions Oven Housing Dimensions Oven Housing Height (mm) Height (mm) Width (mm) Width (mm) Depth (mm) 560 (min) Depth (mm) 560 (min) DC740 DC940 30-50 = airflow end support panels 720 min 24 (22 BL/WH) 24 (22 BL/WH) = airflow fig.10... - Page 24 Please contact our Customer Care Department for Service on the details below Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
