Section 2 - Installation
Power
Plug in the GO-PL-200 into an AC wall outlet. Note that it is not recommended to connect the GO-PL-200 to a power
strip or UPS.
Note: Power source is confirmed when the Power LED on the GO-PL-200 is illuminated.
Connect the Ethernet Cable
Connect the included Ethernet cable to the Ethernet port
located on the GO-PL-200 and attach the other end of the
Ethernet cable to your PC or Ethernet device. Network
Connectivity is confirmed when the Ethernet LED on the
GO-PL-200 is illuminated.
Power Saving Mode Enabled
When the Ethernet link activity has been down for 5
minutes, the GO-PL-200 will automatically go into power
saving mode. The Power LED will blink intermittently.
WARNING! D-Link powerline devices cannot be configured while in
Power Saving Mode.
D-Link GO-PL-200/GO-PLK-200 User Manual

Hardware Installation

ROOM C
1
ROOM A ROOM B
2
GO-PL-200
Internet Router
EXISTING PLC NETWORK
GO-PL-200
PC
ROOM C
GO-PL-200 GO-PL-200
PC
PC
