Jasmine™ Scale JLS5
Assembly, Installation and Operating Instructions
NOTE: Check all parts for shipping damage. In case of shipping damage, DO NOT use. Contact carrier/dealer for
further instruction.
To ensure the safe installation, operation and use of the Jasmine Scale, these instructions MUST be followed:
DO NOT use this equipment without first reading and understanding these instructions. If you are
unable to understand the Warnings, Cautions, and Instructions, contact distributor before
attempting to use this equipment, otherwise, injury or damage may result.
The weight capacity is limited to the lowest rated capacity of any one of the components in use (i.e.,
Patient Lift, Sling or Scale). The patient's weight MUST NOT exceed the lowest rated capacity of any
component.
After ANY adjustments, repair or service and before use, make sure that all attaching component
parts are secure.
Invacare products are specifically designed and manufactured for use in conjunction with Invacare
accessories. Accessories designed by other manufacturers have not been tested by Invacare and are
not recommended for use with Invacare products.
Kit Description
DESCRIPTION
Load Cell Assembly
Nylon Washers
Swivel Bar Pin
Locknut
Mounting Screw
Small Steel Washer
Specifications
Weight Range:
Resolution:
Display:
Automatic Power Down:
Size:
Weight:
Power:
Battery Life:
Temperature Range:
For more information regarding Invacare products, parts, and services, please visit www.invacare.com
Part No 1152408
SAVE THESE INSTRUCTIONS
WARNING
ACCESSORIES WARNING
QUANTITY
1
2
1
1
1
1
Up to 500 lbs (226.7 Kg)
+/- 0.2 lbs (0.1 Kg)
Liquid Crystal Digital
Two minutes
5-3/4 L X 3-5/8 W X 4 H
.55 lbs
9-Volt Alkaline battery (included)
Approximately 1500 readings
50° To 104°F (10° To 40°C)
1
Jasmine™ Scale JLS5
Advertisement
Table of Contents
Related Manuals for Invacare Jasmine JLS5
Summary of Contents for Invacare Jasmine JLS5
-
Page 1: Specifications
After ANY adjustments, repair or service and before use, make sure that all attaching component parts are secure. Invacare products are specifically designed and manufactured for use in conjunction with Invacare accessories. Accessories designed by other manufacturers have not been tested by Invacare and are not recommended for use with Invacare products. Kit Description... - Page 2 2. Remove the socket head screw, washer, bushings, top rubber cap, nylon spacers, washer and nut that attach the swivel bar or cradle attachment to the boom. NOTE: When the attaching hardware is removed, the pin, washer and o‐ring will become loose. NOTE: Save the socket screw, small steel washer and locknut to secure the Jasmine Scale to the boom. NOTE: Save the remaining hardware for future use of the swivel bar or cradle attachment without the scale. Bushing Washer Socket Head Screw Side Rubber Cap FIGURE 1 Removing the Swivel Bar/Cradle Attachment Jasmine™ Scale JLS5 Top Rubber Cap Side Rubber Cap Washer Bushing Nylon Spacer Swivel Bar Nylon Spacer O-ring Washer...
- Page 3 (Detail ʺBʺ of FIGURE 2). 5. Secure swivel bar pin to the load cell assembly with a screw and locknut. Tighten securely (Detail ʺBʺ of FIGURE 2). After ANY adjustments, repair or service and BEFORE use, make sure all attaching hardware is tightened securely - otherwise injury or damage may occur. 6. Weigh the patient. Refer to Operating the Scale and Weighing the Patient in the Jasmine Patient Lift Owner’s Manual, Invacare P/N 1150704. DETAIL “A” Top Rubber Locknut Washer Nylon...
-
Page 4: Operating The Scale
Weighing the Patient The weight capacity is limited to the lowest rated capacity of any one of the components in use (e.g. Patient Lift, Sling or Scale). The patient's weight MUST NOT exceed the lowest rated capacity of any component. - Page 5 DO NOT operate key strokes with pointed objects (e.g. pencils, pens, fingernails, etc.) Otherwise damage to the key pad will result. NOTE: The display will indicate the last weight that was measured. The word ʺLOCKʺ will be seen in the display box. NOTE: The ZERO key is pressed in order to avoid capturing the weight of the sling and the hardware. If the ZERO key is not pressed the weight of the sling and the weight of the hardware will be included in the weight displayed. NOT ZERO‐ING OUT WILL GIVE A FALSE READING OF THE USERʹS TRUE WEIGHT. 3. Press the ZERO key. When the ZERO key is pushed the following will happen: A. The scale will reset to zero and the word ʺZEROʺ will appear in the display. B. The lock function will then be turned off and the word ʺLOCKʺ will disappear from the display. NOTE: The scale is now active and continually updating the weight display. 4. Place the patient in the sling. For patient placement instructions refer to Operation in the Jasmine Patient Lift Owner’s Manual, Invacare P/N 1150704. 5. Activate the lift mechanism to raise the patient until they are completely supported by the lift. For patient lifting instructions, refer to Lifting the Patient in the Jasmine Patient Lift Owner’s Manual, Invacare P/N 1150704. 6. Note the weight display. 7. When the weight display becomes stable press the LOCK button to lock the weight display. This will be indicated by the word ʺLOCKʺ appearing in the display window. NOTE: Should it be necessary to unlock the weight while the patient is still supported by the lift, the UNLOCK button may be pressed. The weight will unlock and the word ʺLOCKʺ will disappear from the display window. The weight value will then be updated. Once the weight becomes stable the weight can be locked again by pressing the LOCK button. NOTE: Stable being defined as the weight fluctuating ± two tenths of a pound. For example, a patient weighing ...
-
Page 6: Replacing The Battery
When battery replacement is needed, LO BAT will appear on the display. Perform the following: 1. Slide the battery door open in the direction of the arrow. 2. Remove existing battery. 3. Install the NEW battery. 4. Reinstall the battery door. Calibrate the Jasmine Scale NOTE: For this procedure, refer to FIGURE 5 on page 7. NOTE: The Jasmine Scale will be pre‐calibrated at the factory with the load cell. Should it be necessary to re‐calibrate the scale, follow the instructions outlined below. 1. The patient and the sling MUST be removed from the scale to properly calibrate the Jasmine Scale. Refer to Operation in the Jasmine Patient Lift Owner’s Manual, Invacare P/N 1150704, for further instructions. 2. For sling detachment instructions, refer to Lifting the Patient in the Jasmine Patient Lift Owner’s Manual, Invacare P/N 1150704. 3. Turn the scale display power on by pressing the ON/OFF key. 4. Rotate the Swivel Bar until the back of the scale display is visible. 5. Insert the tip of a paper clip or similar tool into the small hole on the back of the scale display and press the CAL button. NOTE: Once the CAL button is pressed, “CAL1” will be seen in the display window. 6. Press the UNITS key. The display reads CAL2. 7. Press the LOCK/UNLOCK key. The display reads UNLD. 8. Press the ZERO key. The display reads LOAD. 9. Hang 200 pounds of calibrated weight from the scale and press the ZERO key. -
Page 7: Troubleshooting
BACK VIEW OF SCALE DISPLAY FRONT VIEW OF SCALE DISPLAY MODEL JLS5 CAPACITY 500 lb, 227 kg FIGURE 5 Calibrate the Jasmine Scale PROBABLE CAUSE Battery failure. CAL button Display Window SOLUTION Check battery. Replace if necessary. Contact Invacare. Jasmine™ Scale JLS5... -
Page 8: Limited Warranty
If within such warranty period any such product shall be proven to be defective, such product shall be repaired or replaced, at Invacare’s option. This warranty does not include any labor or shipping charges incurred in replacement part installation or repair of any such product.
