Reliant Scale RLS6
Assembly, Installation and Operating Instructions
NOTE: Check all parts for shipping damage. In case of shipping damage, DO NOT use. Contact carrier/dealer for further
instruction.
To ensure the safe installation, operation and use of the Reliant Scale, these instructions MUST be followed:
DO NOT use this product without first completely reading and understanding these instructions and
any additional instructional material such as owner's manuals, service manuals or instruction sheets
supplied with this product or optional equipment. If you are unable to understand the warnings,
cautions or instructions, contact a healthcare professional, dealer or technical personnel before
attempting to use this equipment - otherwise, injury or damage may occur.
After any adjustments, repair or service and before use, make sure all attaching hardware is
tightened securely - otherwise injury or damage may occur.
Invacare products are specifically designed and manufactured for use in conjunction with Invac-
are accessories. Accessories designed by other manufacturers have not been tested by Invacare
and are not recommended for use with Invacare products.
Kit Description
PART NO
1117147
1064338
1080975
1008882
1092593
1065214
1119556
1119555
Specifications
WEIGHT RANGE:
RESOLUTION:
DISPLAY:
AUTOMATIC POWER DOWN
SIZE:
WEIGHT:
POWER:
BATTERY LIFE:
TEMPERATURE RANGE:
For more information regarding Invacare products, parts, and services, please visit www.invacare.com
Part No 1114832
SAVE THESE INSTRUCTIONS
WARNING
ACCESSORIES WARNING
DESCRIPTION
Load Cell Assembly
Nylon Washers
Swivel Bar Pin
Locknut
Mounting Screw
Small Steel Washer
1/8-inch thick nylon washer (9805 lift)
1/4-inch thick nylon washer (450/600 lbs lift)
Up to 600 lbs (272.7 kg)
+/- 0.2 lbs (.1 kg)
Liquid Crystal Digital
Two minutes
5-3/4 L x 3-5/8 W x 4 H
1.55 lbs
Nine volt alkaline battery (Included)
Approximately 1500 readings
50° to 104° F (10° to 40° C)
QTY
1
2
1
1
1
1
2
2
1
Reliant Scale RLS6
Advertisement
Table of Contents
Summary of Contents for Invacare RLS6
-
Page 1: Specifications
After any adjustments, repair or service and before use, make sure all attaching hardware is tightened securely - otherwise injury or damage may occur. Invacare products are specifically designed and manufactured for use in conjunction with Invac- are accessories. Accessories designed by other manufacturers have not been tested by Invacare and are not recommended for use with Invacare products. - Page 2 Remove the Swivel Bar Invacare slings and patient lift accessories are specifically designed to be used in conjunction with Invacare patient lifts. Slings and accessories designed by other manufacturers are not to be uti- lized as a component of Invacare’s lift system.
- Page 3 Reliant Scale Part No 1114832 DETAIL "B" - ATTACHING THE Reliant Scale Mounting Screw Shoulder Bolt Nylon Nylon Washer Washers Load Cell Assembly FIGURE 2 Install the Reliant Scale HANGER BAR Locknut Swivel Bar Swivel Bar Pin Reliant Scale RLS6...
-
Page 4: Operating The Scale
Pressing this key when the scale is on will reset the weight shown in the display window to zero. The function of this key is to change the unit of measurement from pounds (lbs) to kilograms (kg). -
Page 5: Weighing The Patient
Weighing the Patient The weight capacity is limited to the lowest rated capacity of any one of the components in use (i.e. Patient Lift, Sling or Scale). The patient's weight MUST NOT exceed the lowest rated capacity of any component. -
Page 6: Replacing The Battery
Calibrate the Reliant Scale NOTE: For this procedure, refer to FIGURE 5 on page 7. NOTE: The Reliant Scale will be pre‐calibrated at the factory with the load cell. Should it be necessary to re‐calibrate the scale, follow the instructions outlined below. 1. The patient and the sling MUST be removed from the scale to properly calibrate the Reliant Scale. Refer to Operation in the Patient Lift Owner’s Manual for further instructions. 2. For sling detachment instructions, refer to Lifting the Patient in the Patient Lift Owner’s Manual. 3. Turn the scale display power on by pressing the ON/OFF key. 4. Rotate the Swivel Bar until the back of the scale display is visible. 5. Insert the tip of a paper clip or similar tool into the small hole on the back of the scale display and press the CAL button. NOTE: Once the CAL button is pressed, “CAL1” will be seen in the display window. 6. Press the UNITS key. The display reads CAL2. Reliant Scale RLS6 Assembled Scale 9V Battery Battery Door Arrow FIGURE 4 Replacing the Battery Part No 1114832... -
Page 7: Troubleshooting
BACK VIEW OF THE SCALE DISPLAY FRONT VIEW OF SCALE DISPLAY FIGURE 5 Calibrate the Reliant Scale PROBABLE CAUSE Battery failure. CAL Button Display Window SOLUTIONS Check battery. Replace if necessary. Contact Invacare for Service at 1-800-333-6900. Reliant Scale RLS6... -
Page 8: Limited Warranty
If within such warranty period any such product shall be proven to be defective, such product shall be repaired or replaced, at Invacare’s option. This warranty does not include any labor or shipping charges incurred in replacement part installation or repair of any such product.
