1
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE.
INSTALLATION AND
OPERATING INSTRUCTIONS
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS: CSA C22.2 No-12 & No 250 / UL 153 & UL1598
EFL42S
ELECTRIC FIREPLACE
WARNING
!
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS UNTIL
COOLED.
SAFETY INFORMATION
NEVER ALLOW CHILDREN TO
WARNING
TOUCH GLASS.
!
If the information in these instructions are
not followed exactly, a fi re or explosion
may result causing property damage,
personal injury or loss of life.
- Do not store or use gasoline or other fl ammable
vapors and liquids in the vicinity of this or any
other appliance.
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
Phone (705)721-1212 • Fax (705)722-6031 • www.napoleonfi replaces.com • ask@napoleonproducts.com
$10.00
1.16C
W415-1142 / A / 11.06.12
Advertisement
Table of Contents
Related Manuals for Napoleon EFL42S
Summary of Contents for Napoleon EFL42S
- Page 1 NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE. INSTALLATION AND OPERATING INSTRUCTIONS CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS: CSA C22.2 No-12 & No 250 / UL 153 & UL1598 EFL42S ELECTRIC FIREPLACE WARNING HOT GLASS WILL CAUSE BURNS.
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION DIMENSIONS LISTING APPROVALS GENERAL INSTRUCTIONS LOCATING APPLIANCE UNPACKING AND TESTING APPLIANCE GROUNDING APPLIANCE INSTALLATION MINIMUM CLEARANCE TO COMBUSTIBLES MINIMUM MANTEL CLEARANCES INSTALLING THE APPLIANCE RECESSING INSTALLATION 3.4.1 MINIMUM CLEARANCE TO COMBUSTIBLES 3.4.2 FRAMING 3.4.3 MOUNTING BRACKET INSTALLATION HARD WIRING INSTALLATION FINISHING GLASS DOOR REMOVAL... -
Page 3: Introduction
1.0 INTRODUCTION WARNING • THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED. • Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance according to operating instructions could cause fi re or injury. •... -
Page 4: Dimensions
This appliance has been tested in accordance with the CSA Standards for fi xed and location-dedicated electric room appliances in the United States and Canada. If you need assistance during installation, please contact your local dealer. Model Number EFL42S NOTE: This appliance must be electrically wired and grounded Description Wall-Mount... -
Page 5: General Instructions
GENERAL INSTRUCTIONS WARNING READ THESE INSTRUCTIONS COMPLETELY BEFORE BEGINNING INSTALLATION. FAILURE TO FOLLOW THEM COULD CAUSE AN APPLIANCE MALFUNCTION RESULTING IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. ALL ELECTRIC APPLIANCES HAVE HOT AND ARCING OR SPARKING PARTS INSIDE. DO NOT USE IT IN AREAS WHERE GASOLINE, PAINT OR FLAMMABLE LIQUIDS ARE PRESENT. -
Page 6: Locating Appliance
2.0 LOCATING APPLIANCE WARNING DUE TO HIGH TEMPERATURES, THIS ELECTRIC APPLIANCE SHOULD BE LOCATED OUT OF TRAFFIC. KEEP COMBUSTIBLE MATERIALS SUCH AS FURNITURE, PILLOWS, BEDDING, PAPERS, CLOTHES AND CURTAINS AT LEAST 36" FROM THE FRONT OF THE APPLIANCE. NEVER LOCATE THIS ELECTRIC APPLIANCE WHERE IT MAY FALL INTO A BATHTUB OR OTHER WATER CONTAINER. -
Page 7: Installation
THIS APPLIANCE IS HEAVY. IT IS HIGHLY RECOMMENDED THAT TWO PEOPLE INSTALL THIS APPLIANCE. 68.6 Your EFL42S is a wall-mounted appliance. Select a suitable location that is not susceptible to moisture and is away from drapes, furniture and high traffi c areas. NOTE: Follow all National and local electrical codes. -
Page 8: Minimum Clearance To Combustibles
MINIMUM CLEARANCE TO COMBUSTIBLES Measurements are taken from the glass front. Bottom 0" 8" to mantel Sides 0" 8" to ceiling Back 0" NOTE: The power switch is located on the lower right hand side of the appliance. Always ensure that access to this switch remains available. MINIMUM MANTEL CLEARANCES WARNING WHEN USING PAINT OR LACQUER TO FINISH THE MANTEL, THE PAINT OR LACQUER MUST BE... -
Page 9: Installing The Appliance
INSTALLING THE APPLIANCE Due to the many different materials used on different walls, it is highly recommended that you consult your local builder before you install this appliance on the wall. Body Select a location that is not prone to moisture. Glass Front Have two people hold the appliance against the wall to determine the fi... -
Page 10: Recessing Installation
RECESSING INSTALLATION Due to the many different fi nish materials used on walls, it is highly recommended that you consult your local builder before you install this appliance in the wall. Select a location that is not prone to moisture and is located at least 36" away from combustible materials such as curtain drapes, furniture, bedding, paper etc. -
Page 11: Mounting Bracket Installation
3.4.3 MOUNTING BRACKET INSTALLATION Remove the glass front, refer to "GLASS FRONT INSTALLATION" section for removal instructions. Remove the glass media from the appliance prior to installing the mounting brackets. Prior to installing the mounting brackets determine if you will be recessing the appliance partially or fully. -
Page 12: Hard Wiring Installation
HARD WIRING INSTALLATION WARNING ENSURE ALL POWER IS TURNED OFF BEFORE HARD WIRING THIS APPLIANCE. HARD WIRING CONNECTION If it is necessary to hard wire this appliance, a qualifi ed electrician may remove the cord connection, and wire the appliance directly to the house hold wiring. This appliance must be electrically connected and grounded in accordance with local codes, if hard wired. -
Page 13: Finishing
4.0 FINISHING WARNING POWER SUPPLY SERVICE MUST BE COMPLETED PRIOR TO FINISHING TO AVOID RECONSTRUCTION. AIR OPENINGS CANNOT BE COVERED IN ANY CIRCUMSTANCES. GLASS DOOR REMOVAL WARNING GLASS MAY BE HOT, DO NOT TOUCH GLASS UNTIL COOLED. FACING AND/OR FINISHING MATERIALS MUST NOT INTERFERE WITH AIR FLOW THROUGH AIR OPENINGS, LOUVRES OPENINGS, OPERATION OF LOUVRES OR DOORS OR ACCESS FOR SERVICE. -
Page 14: Operating Instructions
5.0 OPERATING INSTRUCTIONS Once the appliance has been plugged into a grounded electrical outlet, it is ready to operate. NOTE: Ensure the house circuit breakers for the power supply are turned on. In the event of a power failure, when the main power switch of the appliance is in the "I" ON position and the hand held remote control is in the OFF position, the fl... -
Page 15: Maintenance
6.0 MAINTENANCE FUSE REPLACEMENT WARNING PREPARATION FOR MAINTENANCE ALWAYS DISCONNECT THE POWER AND ALLOW THE ELECTRIC APPLIANCE TO COOL BEFORE PERFORMING ANY CLEANING, MAINTENANCE OR RELOCATION OF THIS ELECTRIC APPLIANCE. TURN CONTROLS TO OFF AND REMOVE PLUG FROM OUTLET OR TURN OFF THE HOUSE CIRCUIT BREAKER TO ELECTRIC APPLIANCE RECEPTACLE. -
Page 16: Wiring Diagram
7.0 WIRING DIAGRAM WARNING ENSURE ALL POWER IS TURNED OFF BEFORE HARD WIRING THIS APPLIANCE. W415-1142 / A / 11.06.12... -
Page 17: Replacement Parts
8.0 REPLACEMENT PARTS Contact your dealer or the factory for questions concerning prices and policies on replacement parts. Normally all parts can be ordered through your Authorized dealer / distributor. WARNING FOR WARRANTY REPLACEMENT PARTS, A PHOTOCOPY OF THE ORIGINAL INVOICE WILL BE REQUIRED TO HONOUR THE CLAIM. FAILURE TO POSITION THE PARTS When ordering replacement parts always give the following information: IN ACCORDANCE WITH THIS... -
Page 18: Troubleshooting
9.0 TROUBLESHOOTING WARNING TURN OFF THE APPLIANCE COMPLETELY AND LET COOL BEFORE SERVICING. ONLY A QUALIFIED SERVICE PERSON SHOULD SERVICE AND REPAIR THIS ELECTRIC APPLIANCE. SYMPTOM PROBLEM TEST SOLUTION Dim or no fl ame Drum LED’s are burnt out Inspect the LED’s inside the fl ame generation cylinder drum (W010-2918) and replace them if necessary Ember bed is not Ember LED’s are burnt out... -
Page 19: Warranty
10.0 WARRANTY NAPOLEON® electric appliances are manufactured under the strict Standard of the world recognized ISO 9001 : 2008 Quality Assurance Certifi cate. NAPOLEON® products are designed with superior components and materials, assembled by trained craftsmen who take great pride in their work. Once assembled the complete appliance is thoroughly inspected by a qualifi ed technician before packing to ensure that you , the customer, receive the quality product that you expect from NAPOLEON®. - Page 20 W415-1142 / A / 11.06.12...
