- Page 1 271S4 www.philips.com/welcome EN User manual Customer care and warranty Troubleshooting & FAQs...
-
Page 2: Table Of Contents
5.1 Resolution & Preset Modes ....25 6. Power Management ......26 7. Regulatory Information .....27 8. Customer care and warrant ....33 8.1 Philips’ Flat Panel Monitors Pixel Defect Policy ..........33 8.2 Customer Care & Warranty ....35 9. Troubleshooting & FAQs ....39 9.1 Troubleshooting ..........39... -
Page 3: Important
1. Important • Please use approved power cord provided 1. Important by Philips all the time. If your power cord is missing, please contact with your local This electronic user’s guide is intended for service center. (Please refer to Customer anyone who uses the Philips monitor. -
Page 4: Notational Descriptions
1. Important • Temperature: 0-40°C 32-95°F 1.2 Notational Descriptions • Humidity: 20-80% RH The following subsections describe notational Important information for Burn-in/Ghost conventions used in this document. image Notes, Cautions and Warnings • Always activate a moving screen saver Throughout this guide, blocks of text may be program when you leave your monitor accompanied by an icon and printed in bold or unattended. -
Page 5: Disposal Of Product And Packing
From the planning, design and production stages, Philips emphasizes the important of making products that can easily be recycled. At Philips, end-of-life management primarily entails This marking on the product or on its... -
Page 6: Setting Up The Monitor
1. Place the monitor face down on a smooth surface. Pay attention not to scratch or damage the screen. 2.1 Installation Package contents 271S4 2. Hold the stand with both hands. user s manual 使用产品前请阅读使用说明 (1) Gently attach the stand to the VESA 保留备用... -
Page 7: Operating The Monitor
2. Setting up the monitor Connecting to your PC 2.2 Operating the monitor Description of the control buttons 2 3 4 AC power input DP input DVI input VGA input Kensington anti-theft lock Connect to PC 1. Connect the power cord to the back of the monitor firmly. -
Page 8: The Osd Menu
On-Screen Display. You can use this as a On-Screen Display (OSD) is a feature in all reference when you want to work your way Philips LCD monitors. It allows an end user to around the different adjustments later on. adjust screen performance or select functions... - Page 9 2. Setting up the monitor Resolution notification Height adjustment This monitor is designed for optimal performance at its native resolution, 1920 × 1080 @ 60 Hz. When the monitor is powered on at a different resolution, an alert is displayed on screen: Use 1920 × 1080 @ 60 Hz for best results.
-
Page 10: Remove The Base Assembly For Vesa Mounting
2. Setting up the monitor Note 2.3 Remove the Base Assembly for This monitor accepts a 100mm x 100mm VESA Mounting VESA-Compliant mounting interface. Before you start disassembling the monitor base, please follow the instructions below to avoid any possible damage or injury. 1. -
Page 11: Image Optimization
How does it work? • Office: Enhances text and dampens SmartImage is an exclusive, leading edge Philips brightness to increase readability and technology that analyzes the content displayed reduce eye strain. This mode significantly on your screen. Based on a scenario you select,... -
Page 12: Smartcontrast
3.3 Philips SmartControl Premium wizard by Standard pane. The new SmartControl Premium software by Philips allows you to control your monitor via an easy to use on-screen graphic interface. Complicated adjustments are a thing of the past as this user friendly software guides you... - Page 13 3. Image Optimization Start with Standard pane Adjust menu • Adjust Menu allows you to adjust Brightness, Contrast, and Resolution. • You can follow the instruction and do the adjustment. • Cancel prompts user if you want to cancel installation. Color menu •...
- Page 14 3. Image Optimization 1. "Show Me" starts color calibration tutorial. 2. Start - starts the 6-step color calibration sequence. 3. Quick View loads the before/after images. 4. To return to Color home pane, click the Cancel button. 5. Enable color calibration - by default is on. If unchecked, does not allow for color calibration to happen, dimes out start and quick view buttons.
- Page 15 3. Image Optimization First Color Calibration Screen Eco Power menu • Previous button is disabled until the second color screen. • Next goes to the succeeding target (6-targets). • Final next goes File > Presets pane. Options menu • Cancel closes the UI and returns to the plug in page.
- Page 16 3. Image Optimization Option>Auto Pivot. menu. Disabled removes SmartControl Premium from the right click context menu. • Enable Task Tray icon is checked (On) by default. Enable context menu shows the task tray menu for SmartControl Premium. A right click on the task tray icon displays the menu options for Help, Technical Support.
- Page 17 3. Image Optimization To enable Theft Deterrence, click on On button Help>Version - Will only be active when to bring up the following screen: selecting Version from the drop- down Help menu. On a non-supported display capable of • User can enter PIN between 4 and 9 digits DDC/CI, only the Help and Options tabs are numbers only.
- Page 18 3. Image Optimization • Help - Access to User Manual file: Open User Manual file using the default browser window. • Technical Support - Displays the tech support page. • Check for Update - Takes the user to PDI Landing and checks the user’s version against the most current available.
-
Page 19: Smartdesktop Guide
3. Image Optimization Drag and Drop Windows Once the partitions are configured and Align to partition is selected a window can be dragged 3.4 SmartDesktop Guide into the region and it will automatically align. When the window and mouse cursor are within SmartDesktop the region, the region will become highlighted. - Page 20 3. Image Optimization Title Bar Options Note If more than one display is attached, the user Desktop partition can be accessed from the title can select the targeted display to change the bar of the active window. This provides a quick partition.
- Page 21 3. Image Optimization • Find Windows – In some cases, the user may have sent multiple windows to the same partition. Find Windows will show all open windows and move the selected window to the forefront. • Desktop Partition – Desktop Partition shows the current selected partition and allows the user to quickly change to any of the partitions shown in the drop down.
- Page 22 3. Image Optimization SmartDesktop Partition Definitions Name Description Image Full Desktop Applies all settings to the entire desktop. Vertical Assesses the screen resolution and divides the display into two evenly sized vertical regions. For 90/270 maintain vertical configuration. Horizontal Assesses the screen resolution and divides the display into two evenly sized horizontal regions.
- Page 23 3. Image Optimization Name Description Image Horizontal Split Top Assesses the screen resolution and divides the display into two evenly sized horizontal regions, the top region is single, the bottom region is spilt into two evenly sized regions. For 90 Partition 1 on right side Vertical Partition 2&3 on left side Vertical.
-
Page 24: Powersensor
4. PowerSensor™ • Since some dark colored clothing tends to 4. PowerSensor™ absorb infrared signals even when the user is within 100 cm or 40 inches of the display, How does it work? step up signal strength when wearing black or other dark clothes. -
Page 25: Technical Specifications
5. Technical `Specifications 5. Technical Specifications Picture/Display Monitor Panel Type TFT-LCD Backlight Panel Size 27" W (68.6cm) Aspect Ratio 16:9 Pixel Pitch 0.31 x 0.31 mm Brightness 300 cd/m² SmartContrast 20,000,000:1 Contrast Ratio (typ.) 1000:1 Response Time (typ.) Optimum Resolution 1920 x 1080 @ 60Hz Viewing Angle 170°... - Page 26 Finish Texture Note 1. EPEAT Gold or Silver is valid only where Philips registers the product. Please visit www.epeat.net for registration status in your country. 2. This data is subject to change without notice. Go to www.philips.com/support to download the...
-
Page 27: Resolution & Preset Modes
5. Technical `Specifications 5.1 Resolution & Preset Modes Maximum Resolution 1920 x 1080 @ 60 Hz (analog input) 1920 x 1080 @ 60 Hz (digital input) Recommended Resolution 1920 x 1080 @ 60 Hz (digital input) H. freq (kHz) Resolution V. -
Page 28: Power Management
6. Power Management 6. Power Management If you have VESA DPM compliance display card or software installed in your PC, the monitor can automatically reduce its power consumption when not in use. If an input from a keyboard, mouse or other input device is detected, the monitor will 'wake up' automatically. -
Page 29: Regulatory Information
Ergonomic, User-centered design electronic equipment have been adhered to Visual ergonomics in products with a display. in order to make Philips monitors safe to use Adjustability for user comfort (displays, throughout its life cycle. headsets) Acoustic performance – protection... - Page 30 7. Regulatory Infomation CE Declaration of Conformity For more information, please visit www.tcodevelopment.com This product is in conformity with the following standards Technology for you and the planet • EN60950-1:2006+A11:2009+A1:20 10+A12:2011 (Safety requirement of Information Technology Equipment). (Only for selective models) •...
- Page 31 7. Regulatory Infomation Energy Star Declaration Changes or modifications not expressly approved by the party responsible for (www.energystar.gov) compliance could void the user's authority ® As an ENERGY STAR Partner, we to operate the equipment. have determined that this product Use only RF shielded cable that was supplied ®...
- Page 32 7. Regulatory Infomation EN 55022 Compliance (Czech Republic Only) Cependant, rien ne peut garantir l'absence d'interférences dans le cadre d'une installation particulière. Si cet appareil est la cause d'interférences nuisibles pour la réception des signaux de radio ou de télévision, ce qui peut être décelé en fermant l'équipement, puis en le remettant en fonction, l'utilisateur pourrait essayer de Polish Center for Testing and Certification...
- Page 33 7. Regulatory Infomation North Europe (Nordic Countries) Information Ergonomie Hinweis (nur Deutschland) Der von uns gelieferte Farbmonitor entspricht Placering/Ventilation den in der "Verordnung über den Schutz vor VARNING: Schäden durch Röntgenstrahlen" festgelegten FÖRSÄKRA DIG OM ATT HUVUDBRYTARE Vorschriften. OCH UTTAG ÄR LÄTÅTKOMLIGA, NÄR DU STÄLLER DIN UTRUSTNING PÅPLATS.
- Page 34 7. Regulatory Infomation China RoHS EU Energy Label The People's Republic of China released a regulation called "Management Methods for Controlling Pollution by Electronic Information Products" or commonly referred to as China RoHS. All products including CRT and Monitor which are produced and sold for China market have to meet China RoHS request.
-
Page 35: Customer Care And Warrant
No manufacturer can guarantee the types of bright dot defects. that all panels will be free from pixel defects, but Philips guarantees that any monitor with an unacceptable number of defects will be repaired or replaced under warranty. This notice explains the different types of pixel defects and defines acceptable defect levels for each type. - Page 36 In order to qualify for repair or replacement due to pixel defects during the warranty period, a TFT Monitor panel in a Philips flat panel monitor must have pixel or sub pixel defects exceeding the tolerances listed in the following tables.
-
Page 37: Customer Care & Warranty
8.2 Customer Care & Warranty For warranty coverage information and additional support requirement valid for your region, please visit www.philips.com/support website for details. You may also contact your local Philips Customer Care Center number listed below. Contact Information for WESTERN EUROPE region:... - Page 38 Estonia FUJITSU +372 6519972(workshop) Georgia Esabi +995 322 91 34 71 +36 1 814 8080(General) Hungary Profi Service +36 1814 8565(For AOC&Philips only) Kazakhstan Classic Service I.I.c. +7 727 3097515 +371 67460399 Latvia ServiceNet LV +371 27260399 +370 37 400160(general)
- Page 39 Mon.~Fri. 9:00am-6:00pm Macau Technology Ltd. Macau: Sat. 9:00am-1:00pm Tel: (853)-0800-987 REDINGTON INDIA Tel: 1 800 425 6396 India Mon.~Fri. 9:00am-5:30pm SMS: PHILIPS to 56677 +62-21-4080-9086 PT. CORMIC Mon.~Thu. 08:30-12:00; 13:00- (Customer Hotline) Indonesia SERVISINDO 17:30 +62-8888-01-9086 PERKASA Fri. 08:30-11:30; 13:00-17:30"...
- Page 40 8. Customer care and warranty +84 8 38248007 Ho Chi Minh City FPT Service Informatic +84 5113.562666 Mon.~Fri. 8:00-12:00, 13:30-17:30 Vietnam Company Ltd. - Ho Chi Danang City Sat. 8:00-12:00 Minh City Branch +84 5113.562666 Can tho Province EA Global Supply Philippines (02) 655-7777;...
-
Page 41: Troubleshooting & Faqs
Philips customer service representative. • Disconnect the monitor from mains power source immediately for safety Common Problems • Contact with Philips customer service No Picture (Power LED not lit) representative immediately. • Make sure the power cord is plugged into Imaging Problems the power outlet and into the back of the monitor. -
Page 42: Smartcontrol Premium Faqs
Image appears blurred, indistinct or too dark For further assistance, refer to the Consumer • Adjust the contrast and brightness on Information Centers list and contact Philips On-Screen Display. customer service representative. An "after-image", "burn-in" or "ghost image" remains after the power has been turned off. -
Page 43: General Faqs
These are the driver files for your Function. How can I do? monitor. Follow the instructions in your Ans.: Philips Service center has a right to user manual to install the drivers. Your ask for legitimate identification and computer may ask you for monitor authorization, in order to establish drivers (.inf and .icm files) or a driver... - Page 44 Can I connect my LCD monitor to any warranty conditions. PC, workstation or Mac? How should I clean the LCD surface? Yes. All Philips LCD monitors are fully Ans.: compatible with standard PCs, Macs Ans.: For normal cleaning, use a clean, soft and workstations.
- Page 45 9. Troubleshooting & FAQs may cause "burn in", also known as "after-imaging" or "ghost imaging", on your screen. "Burn-in", "after-imaging", or "ghost imaging" is a well-known phenomenon in LCD panel technology. In most cases, the "burned in" or "atter-imaging" or "ghost imaging" will disappear gradually over a period of time after the power has been switched off.
- Page 46 2013 © Koninklijke Philips N.V. All rights reserved. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license from Koninklijke Philips N.V. Specifications are subject to change without notice. Version: M4271SEE1T...
