Page 1: Instruction Manual
10” TABLE SAW MODEL: KC-10FX INSTRUCTION MANUAL COPYRIGHT © 2002 ALL RIGHTS RESERVED BY KING CANADA TOOLS INC. - Page 2 IMPORTANT INFORMATION 2-YEAR KING CANADA TOOLS LIMITED WARRANTY OFFERS A 2-YEAR LIMITED WARRANTY FOR THIS 10” TABLE SAW FOR INDUSTRIAL USE. PROOF OF PURCHASE Please keep your dated proof of purchase for warranty and servicing purposes. REPLACEMENT PARTS Replacement parts for this tool are available at our authorized KING CANADA service centers across Canada. For servicing, contact or return to the retailer where you purchased your product along with your proof of purchase.
-
Page 3: General Safety Instructions For Power Tools
GENERAL SAFETY INSTRUCTIONS FOR POWER TOOLS 1. KNOW YOUR TOOL footwear is recommended. Wear protective hair covering to Read and understand the owners manual and labels affixed to contain long hair. Roll up long sleeves above the elbows. the tool. Learn its application and limitations as well as its 12. -
Page 4: Specifications
GETTING TO KNOW YOUR 10” TABLE SAW MODEL: KC-10FX 1. Magnetic switch 4. Blade guard & splitter 2. Blade raising handwheel 5.Blade tilting handwheel 3. Miter gauge 6. Dust chute SPECIFICATIONS Horsepower ....................3HP Amps/Voltage . -
Page 5: Electrical Requirements
ELECTRICAL REQUIREMENTS MODEL: KC-10FX WARNING! ALL ELECTRICAL CONNECTIONS MUST BE DONE BY A QUALIFIED ELECTRICIAN. FAILURE TO COMPLY MAY RESULT IN SERIOUS INJURY! ALL ADJUSTMENTS OR REPAIRS MUST BE DONE WITH THE TABLE SAW DISCONNECTED FROM THE POWER SOURCE. FAILURE TO COMPLY MAY RESULT IN SERIOUS INJURY! - Page 6 ASSEMBLY ASSEMBLING EXTENSION WINGS Assemble the Table Extension Wings to your saw as follows: Fasten extension wings to the table using six hex. head screws and lockwashers supplied. Use a straight edge to level the extension wings to the table surface as shown in fig.
- Page 7 ADJUSTMENTS ADJUSTING 45 AND 90 DEGREE POSITIVE STOPS Your saw is equipped with a positive stop at 45 and 90 degrees. To check and adjust the positive stops, proceed as follows: 1. Raise the saw blade to it’s maximum. 2. Set the blade at 90 degrees to the table by turning the blade tilting handwheel counter-clockwise as far as it will go.
-
Page 8: Operation
OPERATION CHANGING BLADES 1. Turn off saw and disconnect the electrical plug. 2. Raise the saw blade fully, hold the guard up and lock the saw at 0 degrees. Remove the table insert. 3. Jam a large piece of scrap wood into the blade teeth at the front. Fig. 4. - Page 9 OPERATION CROSSCUTTING Crosscutting requires the use of the miter gauge to position and guide the work. Place the work against the miter gauge and advance both the miter gauge and work toward the saw blade, as shown in Fig. 12. The miter gauge may be used in either table slot, however, most operators prefer the left groove for average work.
- Page 10 OPERATION USING ACCESSORY MOULDING CUTTERHEAD* Moulding is cutting a shape on the edge of face of the work. Cutting moulding with a moulding cutterhead in the circular saw is a fast, safe and clean operation. The many different knife shapes available make it possible for the operator to produce almost any kind of moulding, such as various styles of corner moulds, picture frames, table edges, etc.
-
Page 11: Troubleshooting
TROUBLESHOOTING PROBLEM SOLUTION SAW WILL NOT START 1. Saw not plugged in. 1. Plug in saw. 2. Fuse blown or circuit breaker tripped. 2. Replace fuse or reset circuit breaker. 3. Cord damaged. 3. Have cord replaced by a certified electrician. 4.
