  • Page 1 RADION receiver SD B810 Reference Guide...

  • Page 3: Table Of Contents

    RADION receiver SD Table of Contents | en Table of contents Introduction About documentation Bosch Security Systems, Inc. product manufacturing dates General installation Installation workflow Unpacking information Wall tamper switch installation Magnet cover installation Complete installation Maintenance RADION receiver SD...
  • Page 4 Applications for this product 12.2 Installation consideration RADION universal transmitter 13.1 Installation considerations 13.2 Reed switch settings RADION keyfob 14.1 RADION keyfob FB 14.2 RADION keyfob TB RADION panic Appendices 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 5: Introduction

    Bosch Security Systems, Inc. product manufacturing dates Use the serial number located on the product label and refer to the Bosch Security Systems, Inc. website at http://www.boschsecurity.com/datecodes/. The following image shows an example of a product label and highlights where to find the manufacturing date within the serial number.
  • Page 6 | Introduction RADION receiver SD 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 7: General Installation

    Enroll point RF ID for wireless points Verify LED responses on devices Perform a local walk test for installed detectors Review signal strength and margin of each point Complete the installation Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...

  • Page 8: Unpacking Information

    This is achieved by performing an overall service walk test. Refer to your control panel documentation for system-walk, or other system-wide testing procedures. 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 9: Maintenance

    In the normal operating mode, an alarm can be transmitted only after three (3) minutes have passed since the previous alarm restoral. This 3 minute lockout time reduces unnecessary RF transmissions in high traffic areas, thereby extending battery life. Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...

  • Page 10: Radion Receiver Sd

    RADION receiver SD RADION receiver SD The B810 is a wireless receiver that connects RADION wireless peripherals to supported Bosch control panels via the SDI2 bus connection. A compatible control panel powers the receiver through the wiring connection. Features include: –...

  • Page 11: Ul Product Requirements

    For product-specific UL requirements, refer to desired product title below for more information. RADION Repeater When selecting a suitable 16.5VAC Class 2 plug in transformer, the following transformers are suggested: – MG Electronics (MGT-1640) – Codex SEP-1640 Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...
  • Page 12 The RFGB-A has not been investigated by UL, and not part of a UL Listed system. RADION TriTech Notice! Pet Immunity has not been evaluated by UL. Notice! Draft and Insect Immunity has not been evaluated by UL. 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.
  • Page 13 P## Type = 1 Instant on open or short (Point is constantly armed regardless of the status of the system). ￚP## Invisible Point/Silent Bell = Yes (Keypads do not display alarm activity from this – point). Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...

  • Page 14: B810 Installation

    Refer to your control panel documentation for information on the valid addresses for that control panel. The figure below shows the address switch setting for address 1. Figure 3.1: Address switch set to 1 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 15: Base Mounting Installation

    Ensure that the wiring used meets the following specifications: – Four-conductor unshielded 0.65 mm (22 AWG) to 2.0 mm (18 AWG) maximum. – Wire length must not exceed 243 m (800 ft) from the control panel Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...

  • Page 16: Programming Wireless Points In The Control Panel

    Refer to the Points Menu Parameters section inside the Keypad Installer Menu chapter of the B5512/B4512 and/or D9412GV4/D7412GV4 v2.xx Series Installation and System Reference Guides, or Points – Point Assignments in RPS Help File for more information. 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.
  • Page 17 Use the following procedure to test the frequency strength and range of the RADION system. From the keypad, access the Wireless Menu, and select the Diagnostics menu option. Select the RF Repeaters menu option. Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...

  • Page 18: Enroll Point Rf Id For Wireless Points (Auto-Learn Mode)

    Use the following pattern testing procedure to test the detector range and functionality. Notice! Also see Control Panels (D9412GV4/D7412GV4 v2.00) SIA CP-01 Quick Reference Guide P/N: F. 01U.265.466, and/or Control Panels (B5512/B4512) SIA CP-01 Quick Reference Guide P/N: F. 01U.265.464. 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 19: Signal Level And Margin

    Use the following procedure to test the frequency strength and range of the RADION system. From the keypad, access the Wireless Menu, and select the Diagnostics menu option Select the RF Points menu option. Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...

  • Page 20: Complete The Installation

    . The receiver remains in this state as long as the communication link is present, and no other issues are present that would prevent the receiver from operating in a normal condition. 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.
  • Page 21 5 – switch 8. LED condition State description Continuous Flash: A continuous pattern of Indicates the receiver is in Maintenance short off time, followed by long on time. Mode. Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...

  • Page 22: Leds

    Operating environment 0ﾟC to +49ﾟC (+32ﾟF to +120ﾟF) Relative humidity Up to 93% non-condensing Frequency 433.42 MHz Wiring distance Maximum distance of 243 m (800 ft) from the control panel 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 23: Battery Requirements

    3.7 VDC nominal replaceable RFSM-A smoke CR123A Lithium 3 VDC detector RFUN-A universal CR123A Lithium 3 VDC transmitter RFBT-A bill trap Lithium 1.5 VDC RFDL-11-A TriTech Alkaline 1.5 VDC detector Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...
  • Page 24 3 VDC RFKF-TB-A key fob CR2032 (coin Lithium 3 VDC RFKF-FB-A key fob cell) RFPB-SB-A panic CR2032 (coin Lithium 3 VDC button cell) RFPB-TB-A panic button Table 3.2: Battery requirements 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 25: Radion Repeater

    Ensure that the wiring used meets the following specifications: – Two-conductor unshielded wire. – The minimal requirement for wire length is 1.83 m (6 ft) from the repeater Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...

  • Page 26: Specifications

    (5.50 in x 8.25 in x 1.25 in) Compatible plug-in transformers RFRP-A: – BOSCH CX4010 Plug-in Transformer – F.01U.020.504 (110 VAC primary voltage input, 18 VAC, 22 – BOSCH D1640 Plug-in Transformer – 4.998.125.832 (16 VAC, 40 VA – MG Electronic (MGT-1640), primary rated 120 VAC, 60 Hz, 0.48 Amps, secondary rated 16.5 VAC, 40 VA –...
  • Page 27 Indicates an AC power failure is detected. flash pattern continuous – A communication failure within internal hardware pulse between On and components inside the receiver Off states with a short delay after the 2 pulse Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...

  • Page 28: Radion Glassbreak

    Table 5.1: Specifications Installation considerations For the best detector performance, select a mounting location that is: – Mounted on the ceiling within a maximum range of 20 ft (6 m) 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 29: Testing

    Activate the tester. The sensor alarms and goes into test mode for one minute. During test mode, the LED blinks continuously. To extend test time, fire the tester at the sensor at least once a minute. Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...
  • Page 30 In normal mode, the sensor will not trip to the tester, unless the tester is held next to the sensor. Each time the sensor alarms, it also goes into test mode for one minute. Room acoustics can artificially extend the range of a glassbreak sensor. 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 31: Hand Clap Test

    Use the wall tamper tab to activate an alarm when the glass break has been removed from the wall. Maintenance Clean the cover with a damp (water) cloth as needed to keep it free of dust and dirt. Always test the sensor after cleaning it. Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...

  • Page 32: Radion Tritech

    Features include: – 11m x 11m (35 ft by 35 ft) coverage – Flexible mounting height – Compatible with Bosch RADION wireless systems – Draft and Insect immune – Cover activated tamper indication. Optional wall-activated tamper is included Dimension 138.00 mm x 72.00 mm x 64.00 mm...

  • Page 33: Sensitivity Settings

    LED to indicate the edges of the Microwave pattern. Adjust as necessary. Please reference the LED table below for LED descriptions. LED Condition Cause Steady LED PIR activation (Walk Test) Steady green Microwave activation Steady blue Alarm signal Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...
  • Page 34 Walk test from the opposite direction to determine the coverage pattern boundaries from both sides. When walk test is completed, the detector returns to normal operation after 90 sec of inactivity. 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 35: Radion Pir

    In the normal operating mode, an alarm can be transmitted only after three (3) minutes have passed since the previous alarm restoral. This 3 minute lockout time reduces unnecessary RF transmissions in high traffic areas, thereby extending battery life. Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...
  • Page 36 This occurs when there is no activity in the sensor’s coverage pattern during the 90-sec interval. When walk testing is completed. the detector returns to normal operation after 90 seconds of inactivity. 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 37: Radion Pir C

    LED activation. Each alarm will also extend the Test Mode. Adjust as necessary. Notice! Excessive use of the Walk Test Mode may reduce battery life. Use only for initial setup and maintenance testing. Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...
  • Page 38 This occurs when there is no activity in the sensor’s coverage pattern during the 90-sec interval. When walk testing is completed. the detector returns to normal operation after 90 seconds of inactivity. 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 39: Radion Smoke

    Drift compensation adjustment -1.64%/m (0.5%/ft) maximum Sounder 85 dBA at 3 m Self-diagnostics feature Monitors detector sensitivity and operational status. Frequency 433.42 MHz Table 9.1: Specifications Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...

  • Page 40: Battery Replacement

    Press and hold the Test/Silence button for 4 sec. The LED flashes 1 to 9 times. Count the number of LED flashes and use the Smoke detector sensitivity conditions table to determine the status of the detector’s sensitivity and the recommended action. 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 41: Test/Silence Button

    Slide a slotted screwdriver into the slot on the detector cap and gently push down to pry off the cap. Figure 9.2: Remove the detector cap Squeeze the optical chamber where indicated and pull it up and away from the detector. Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...
  • Page 42 Ensure that the batteries are properly installed. Mount the detector onto the mounting base. 10. Test the detector’s sensitivity. 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 43: Radion Contact Sm

    When installing the magnet, verify that the notches in the magnet base, line up with the notches in the transmitter base, otherwise the magnet and transmitter do not function effectively. Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...
  • Page 44 ￚ Z coordinates graphic. Use the table in conjunction with the graphic to determine desired distances between the magnet and the transmitter based on the type of installation (wood or metal). Notice! The content in the Installation Guide table applies to EN installations. 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 45: Radion Contact Rm

    The removal of the plastic flaps is optional, depending on your installation needs. – For added security, you can use an adhesive with the screws to secure the transmitters and magnets. Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...
  • Page 46 X ￚ Y coordinates graphic. Use the table in conjunction with the graphic to determine desired distances between the magnet and the transmitter based on the type of installation. 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 47: Radion Specialty

    Up to 93%, non-condensing Temperature (operating) Functional range: -10°C to +49°C (+14°F to +120°F) UL only: 0ﾟC to +49ﾟC (+32ﾟF to+120ﾟF) Frequency 433.42 MHz Table 12.1: Specifications Figure 12.1: Specialty Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...

  • Page 48: Applications For This Product

    Velcro strips inside the cash drawer. Warning! It is important to check the Velcro strips on a weekly basis for wear and replace when appropriate in order to prevent potential false alarms. 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 49: Radion Universal Transmitter

    Frequency 433.42 MHz Table 13.1: Specifications Single EOL Resistor Option Use a 2.2 kￚΩ EOL resistor. Refer to the diagram below. Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...

  • Page 50: Installation Considerations

    (wood or metal). Notice! The content in the graphical table applies to EN installations. 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 51: Reed Switch Settings

    Please note, insert the jumper onto the pin prior to installing the battery. Failure to do so may result in unexpected operation of the device. Callout ￚ Description 1 ￚ No jumper disables the internal reed switch 2 ￚ Jumper on enables the internal reed switch Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...

  • Page 52: Radion Keyfob

    – Uniquely coded arm and disarm buttons – Panic alarm – LED indicator 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 53: Radion Keyfob Tb

    – Uniquely coded arm and disarm buttons – Panic alarm – LED indicator Figure 14.2: Keyfob buttons and LED Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...
  • Page 54 | RADION keyfob RADION receiver SD 1 ￚ Arm button 2 ￚ LED 3 ￚ Disarm button 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 55: Radion Panic

    (2.51 in x 1.40 in x 0.51 in) Power/voltage One CR2032 Lithium battery, 3 VDC Battery replacement Panasonic CR2032, Duracell DL2032. Check your Battery yearly to ensure proper functionality Battery life Up to 5 years Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...
  • Page 56 Wrist Strap Wrist Strap transmitters provide single or two-button activation confirmed by emitting LED flashes with all transmissions to clearly show users when the unit is operating. 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.

  • Page 57: Appendices

    Point away from objects that rapidly change temperature Do not mount the device that has direct exposure to sunlight. Do not point toward window. Intended for indoor use only. Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...
  • Page 58 Temperature range Frequency range Duration of time Questions are answered in the reference guide. Universal sign for connecting or disconnecting power. Universal sign for connecting to a power source. 2014.03 | 06 | F.01U.261.834 Reference Guide Bosch Security Systems, Inc.
  • Page 59 RADION receiver SD Appendices | en Battery-related information. Perform a walk test Walk test has concluded Device has wall tamper detection. Bosch Security Systems, Inc. Reference Guide 2014.03 | 06 | F.01U.261.834...
