- Page 1 Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu...
- Page 2 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model...
- Page 3 This appliance has been manufactured to the strictest standards and complies with all applicable legislation, including Electrical safety (LVD) and Electromagnetic interference compatibility (EMC). Parts intended to come into contact with food conform to EEC/89/109.4 IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
-
Page 4: Before First Use
Important Never store inflammable or explosive items and strong corrosive acids or alkalis in the appliance. This is a household appliance, which is produced in accordance with the national standard. It is intended for food storage only, not for storage of blood, medicine and biological products. To prevent risk of fire, keep the appliance away from petrol or any other inflammables. -
Page 5: Setting The Temperature
The fridge may have an odour to it at first use. This will disappear as the appliance cools. Please note: The appliance will work continuously until it comes down to the correct temperature. If the appliance is switched off, you should allow five minutes before switching it on again to prevent unnecessary damage to the compressor. - Page 6 Fridge • Never put liquids in the refrigerator uncovered. • Never put hot foods in the refrigerator. Warm food should be allowed to cool to room temperature before being put into the refrigerator. • Nothing should rest against the rear wall of the refrigerator, as this will cause frost and possible condensation problems which will be difficult to remove.
- Page 7 of the ice-box defrosting, heavy build up of frost in the ice-box and excessive unnecessary use of energy. Freezing fresh food • Set the thermostat knob to 5-7. • Wrap and seal the food in aluminium foil, cling film, watertight plastic bags, polythene containers with lids or special freezer containers.
-
Page 8: Care And Cleaning
Care and cleaning Always disconnect the appliance from the power supply before any cleaning or maintenance. The fridge sections should be cleaned using a solution of bicarbonate of soda and lukewarm water. Do not use abrasive products or detergents. After washing, rinse and dry thoroughly. Clean the shelves and balconies separately by hand with soap and water. -
Page 9: Defrosting The Ice-Box
Defrosting the ice-box The ice box should be defrosted regularly to ensure the most efficient running, at a minimum of once every six months. • Do not use heaters or defrosting sprays in this appliance. • Never use any metallic or sharp objects to remove the ice as this could damage the lining. -
Page 10: Changing The Light Bulb
3. Troubleshooting If you have any problems with your appliance, you should check the troubleshooting prior to calling CDA Customer Care to prevent unnecessary service calls and potential cost. If the appliance is not working •... - Page 11 • The cooling system at the rear of the appliance is clean and free of dust, and not touching the rear wall. • There is enough ventilation at the side and rear walls. The temperature of the room is adequate (10 o C or above). •...
-
Page 12: Installation
Installation Product Dimensions and aperture required for installation: Your refrigerator is designed to be installed into a standard larder unit of width 560-570mm and depth of 550mm. the diagram below shows the product dimensions and aperture required. Note also the arrows on the diagram show ventilation requirements. - Page 13 Installation Fig. 3 - Fitting the decor door bracket Unscrew and remove the nuts and washers from the appliance door. Place fig. 3 fixing bracket on the appliance door by inserting the holes to adjustment bolts. Dimension B= Measure from the underside surface of kitchen unit to the bottom of fixing bracket.
- Page 14 Installation Fig. 6 - Aligning the decor door Close the door and check the alignment with the other unit doors. Adjust the decor door by screwing or unscrewing the adjustment bolts for vertical adjustment and by the help of the slots on the fixing bracket for other directions.
- Page 15 Installation Fig.9 - Fitting the plinth Fit the plinth section, providing minimum 25 mm gap between the cabinet door and fix it. Never cover over the ventilation slots. Once installed the plinth must not block the ventilation slots in the appliance.
-
Page 16: Reversing The Door
Reversing the door It is possible to reverse the door on this appliance, if required. To do so, follow the steps below: 1. Open the door. 2. Remove the white hinge screw cover plate carefully to gain access to the hinge screws. -
Page 17: Electrical Information
Electrical information Warning! This appliance must be earthed. The mains lead of this appliance has been fitted with a BS 1363A 13 amp fused plug. To change a fuse in this type of plug, follow the steps below: 1. Remove the fuse cover and fuse. 2. - Page 18 Do not shorten the supply cable, the appliance may require removing for servicing. N.B. Ensure that the plug socket is situated in an easily accessible place. If the power supply cord is damaged, it must replaced by a CDA authorised agent.
- Page 20 Please contact our Customer Care Department, or for Service on the details below. Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
