Seiko Cal. 3M22 Instructions Manual

Seiko kinetic cal. 3m22/4m21/5m42/5m43 analogue watch
Hide thumbs

Advertisement

Table of Contents

®
You are now the proud owner of a SEIKO KINETIC
Cal. 3M22/4M21/
5M42/5M43. For best results, please read the instructions in this
®
booklet carefully before using your SEIKO KINETIC
. Please keep this
manual handy for ready reference.
®
Usted es ahora un honrado poseedor del SEIKO KINETIC
Cal. 3M22/
4M21/5M42/5M43. Para obtener de él los mejores resultados, lea las
instrucciones del presente folleto con cuidado antes del uso de su reloj
®
SEIKO KINETIC
. Guarde este manual para fácil referencia.

Advertisement

Table of Contents
loading

Related Manuals for Seiko Cal. 3M22

Summary of Contents for Seiko Cal. 3M22

  • Page 1 ® You are now the proud owner of a SEIKO KINETIC Cal. 3M22/4M21/ 5M42/5M43. For best results, please read the instructions in this ® booklet carefully before using your SEIKO KINETIC . Please keep this manual handy for ready reference.
  • Page 2 Please check the case back of your watch to find its calibre number inscribed on it. As illustrated below, the calibre number of your watch is the 4-digit number to the left of the hyphen mark. This booklet includes the instructions for the following watch calibre numbers: Cal. 3M22, 4M21, 5M42 and 5M43.
  • Page 4 Oscillating weight Peso oscilador Rotor & Generating coil block Rotor y Bloque de bobina generadora Circuit block Bloque de circuito Capacitor Condensador...
  • Page 5 The AUTOMATIC POWER GENERATOR Arm movement is the energy source which sets the oscillating weight in motion. This, in turn, causes the rotor to spin even faster than an F1 racing car engine. The result is an electric current which is produced by the coil. This is stored by the capacitor, which supplies the circuit block with power to drive the watch as needed.
  • Page 6 ® SEIKO KINETIC is a revolutionary watch that has realized the long-cherished dream of a “perpetual energy source”. Unlike mechanical watches or conventional quartz watches, it requires no windup springs or batteries. Instead, it utilizes the movement of the wearer as its power source.

  • Page 7: Table Of Contents

    ENERGY DEPLETION FOREWARNING FUNCTION ........... INSTANT-START FUNCTION ..................REMARKS ON THE RESERVE POWER OF THE CAPACITOR ........DATE SETTING – Cal. 3M22/5M42 ................DATE AND DAY SETTING – Cal. 5M43 ..............TIME SETTING – Cal. 3M22/5M42/5M43 ..............TIME SETTING – Cal. 4M21 ..................

  • Page 8: Features

    ® Cal. 3M22/4M21/5M42/5M43 is an analogue watch featuring an Automatic Power Generator newly developed by SEIKO. It generates the electrical energy to power the watch, utilizing the movement of the arm, and stores it in a capacitor. Therefore, the watch does not use a battery. The watch is also equipped with a power reserve indicator and an energy depletion forewarning function so that its constant operation can be assured.
  • Page 9 The watch is provided with a capacitor to store the electrical energy generated by the Automatic Power Generator. Cal. 3M22/4M21 : When the watch is fully charged, the watch keeps operating for more than 3 days. Cal. 5M42/5M43 : When the capacitor is fully charged, the watch keeps operating for more than 7 days.

  • Page 10: Display And Crown Operation

    DISPLAY AND CROWN OPERATION [Cal. 3M22/5M42] [Cal. 5M43] Hour hand Hour hand Minute hand Minute hand Button Button Crown Crown a b c a b c Second hand Date Second hand Day and date (a) Normal position Free (b) First click: •...
  • Page 11 [Cal. 4M21] Hour hand Minute hand Button Crown Second hand (a) Normal position Free (b) Extended position Time setting...

  • Page 12: How To Charge And Start The Watch

    2. After the watch is swung about 100 times, the second hand starts moving at one- second intervals. * There will be about 3 hours (Cal. 3M22/4M21) / 6 hours (Cal. 5M42/5M43) of power reserve available. 3. Swing the watch further about 400 times (Cal. 3M22/4M21) / 300 to 400 times (Cal.
  • Page 13 * There will be about 1 day (Cal. 3M22/4M21) / 2 days (Cal. 5M42/5M43) of power available. * It is not necessary to charge the capacitor fully before you wear the watch. While the watch is on your arm, the Automatic Power Generator will ensure constant operation.

  • Page 14: Number Of Swings And Power Reserve

    NUMBER OF SWINGS AND POWER RESERVE • Cal. 3M22/4M21 2-second intervals 1-second intervals ✩ MORE THAN POWER 1 DAY 2 DAYS 3 DAYS RESERVE FULL NUMBER OF SWINGS 100 1,200 ✩ The illustration above provides a general guideline of the relationship between the power reserve and the number of swings, which may vary slightly.
  • Page 15 * The watch is equipped with a system to prevent overcharge. Even if it is further swung after being fully charged, no malfunction will result. • Cal. 5M42/5M43 2-second intervals 1-second intervals ✩ MORE THAN POWER 2 DAYS 4 DAYS 7 DAYS RESERVE FULL...
  • Page 16 3. Another 400 to 500 swings, 800 to 1,000 swings in total, will reserve up to 4 days of power. 4. An additional 600 to 750 swings, 1,400 to 1,750 swings in total, will reserve more than 7 days of power, and fully charge the capacitor. * The watch is equipped with a system to prevent overcharge.

  • Page 17: Power Reserve Indicator

    POWER RESERVE INDICATOR The current power reserve of the capacitor can be checked instantly by using the power reserve indicator function. 1. Press the button at the 2 o’clock position. The second hand moves quickly and stops. 2. The number of seconds that the second hand advances indicates the power reserve in the capacitor.
  • Page 18 When the second hand advances 30 seconds at a press of the button, the capacitor is fully charged and the watch will keep operating for more than 3 days (Cal. 3M22/ 4M21) / 7 days (Cal. 5M42/5M43). It can continue operating for a maximum of 7 days (Cal.
  • Page 19 1. To allow easy reading of the second hand, we recommend that the button be pressed when the second hand is at the 12 o’clock position. When the second hand points to “LO”, the capacitor has a power reserve of between 1 and 2 days (Cal. 3M22/4M21) / 2 and 4 days (Cal. 5M42/5M43).

  • Page 20: Energy Depletion Forewarning Function

    This function is available as long as: the watch previously had more than 2 days (Cal. 3M22/4M21) / 4 days (Cal. 5M42/5M43) of power reserve before it stopped. it has been left untouched for 1 to 4 weeks.

  • Page 21: Remarks On The Reserve Power Of The Capacitor

    * After you swing the watch several times and note that the hands are moving, be sure to put it on your wrist so that it will be charged further until the second hand is moving at one-second intervals. Note: If the second hand continues moving at two-second intervals after the watch is put on your wrist, swing it from side to side until the second hand starts moving at one-second intervals, and then, put in on your wrist.

  • Page 22: Date Setting - Cal. 3M22/5M42

    DATE SETTING – Cal. 3M22/5M42 1. Pull out the crown to the first click. If the crown is of the screw lock type, unscrew the crown by turning it counterclockwise, and then pull it out to the first click. 2. Turn the crown clockwise until the previous day’s date appears.

  • Page 23: Date And Day Setting - Cal. 5M43

    DATE AND DAY SETTING – Cal. 5M43 1. Pull out the crown to the first click. If the crown is of the screw lock type, unscrew the crown by turning it counterclockwise, and then pull it out to the first click. 2.

  • Page 24: Time Setting - Cal. 3M22/5M42/5M43

    TIME SETTING – 3M22/5M42/5M43 1. Pull out the crown all the way to the second click when the second hand is at the 12 o’clock position. If the crown is of the screw lock type, unscrew the crown by turning it counterclockwise, and then pull it out to the second click.

  • Page 25: Time Setting - Cal. 4M21

    TIME SETTING – 4M21 1. Pull out the crown when the second hand is at the 12 o’clock position. If the crown is of the screw lock type, unscrew the crown by turning it counterclockwise, and then pull it out. 2.

  • Page 26: Rotating Bezel

    ROTATING BEZEL [For the models with rotating bezel] The rotating bezel can show up to 60 minutes of elapsed time. By setting it before you start, you can know how many minutes have elapsed. • For models in which the rotating bezel rotates only counterclockwise, the time measured is never shorter than the actual elapsed time if the bezel is turned by accident.

  • Page 27: To Preserve The Quality Of Your Watch

    TO PRESERVE THE QUALITY OF YOUR WATCH I WATER RESISTANCE Condition Scuba Accidental Taking a bath of use Swimming, and shallow diving** contact with yachting and Indication on diving water such taking a case back saturation as rain and shower Degree diving splashes...
  • Page 28 • Before using in water, be sure the ** We recommend that you wear a crown is pushed in completely. SEIKO Diver’s Watch for scuba • Do not operate the crown and bar WR diving. button when the watch is wet or in water.
  • Page 29 3 years. Have your watch Years with magnetic objects. checked by an AUTHORIZED SEIKO DEALER or SERVICE CENTER to I CHEMICALS ensure that the case, crown, button, gasket and crystal seal remain intact. Be careful not to expose the...

  • Page 30: Specifications

    7. Duration of charge Full charge (Cal. 3M22/4M21) ..More than 3 days Full charge (Cal. 5M42/5M43) ..More than 7 days 8. Capacitor ..........Button type capacitor, 1 piece 9. IC (Integrated Circuit) ......C-MOS-IC, 1 piece...
