ThinkPad
Hardware Maintenance Manual
June 2006
This manual supports:
ThinkPad R60, R60e
(MT 0656, 0657, 0658, 0659, 9455, 9456, 9457, 9458, 9459, 9460,
9461, 9462, 9463, 9464)
®
R60, R60e
