- Page 1 INSTALLATION INSTRUCTIONS DishDrawer dishwasher DD24D 7 & DD24DT 7 models US CA 590204D 04.13...
- Page 2 FOLLOW THE INSTALLATION SEQUENCE RELEVANT TO YOUR MODEL STANDARD HEIGHT DOUBLE MODELS TALL HEIGHT DOUBLE MODELS Classic Designer Integrated Classic Designer Integrated DD24DCX7 DD24DCTX7 DD24DTI7 DD24DI7 DD24DCW7 DD24DDFX7 DD24DCHTX7 DD24DDFTX7 DD24DHTI7 DD24DCB7 DD24DCTW7 DD24DCTB7 PARTS SUPPLIED PARTS SUPPLIED PARTS SUPPLIED PARTS SUPPLIED PARTS SUPPLIED PARTS SUPPLIED...
-
Page 3: Important Safety Instructions
SAFETY AND WARNINGS - ALL MODELS IMPORTANT SAFETY INSTRUCTIONS! WARNING! Installation of this dishwasher requires basic mechanical and electrical skills. Electrical hazard Be sure to leave these Instructions with the Customer. Installation must comply with your local building, electricity, and plumbing regulations. Before installing the dishwasher, remove the house fuse or open the circuit breaker. - Page 4 PARTS SUPPLIED - ALL MODELS Drain hose Drain hose Wire clip (2) Side mounting Phillips Rubber Clamp (1) support (1) joiner (1) bracket kit mounting 5⁄8” (16 mm) washer for (for securing (for securing (A and B) (2) brackets (2) screws (9) inlet hose (1) Drain hose joiner)
- Page 5 OPTIONALLY HARD WIRING PRIOR TO INSTALLATION REMOVE THE LOWER DRAWER REMOVE THE ACCESS COVER & POWER CORD Access cover To prevent kinked hoses, we recommend rotating the drawer anti-clockwise and resting it on its side after removal. WARNING! Press the release tabs in on Electrical Shock Hazard either side and push back Before continuing, ensure that the product is...
-
Page 6: Product Dimensions
PRODUCT DIMENSIONS Plan Side Product dimensions STANDARD HEIGHT MODELS TALL HEIGHT MODELS inches (mm) overall height of product 32 5⁄16 - 34 5⁄8”( 32 5⁄16 - 34 5⁄8”( 32 5⁄16 - 34 5⁄8”( 34 - 36 3⁄8”( 34 - 36 3⁄8”( 34 - 36 3⁄8”( 820-880 820-880... -
Page 7: Cabinetry Dimensions
CABINETRY DIMENSIONS Plan Side Minimum clearances from adjacent cabinetry min. ½ ” (13 mm) min. 1⁄16” (2 mm) clearance from a clearance corner cupboard to adjacent cupboard door Cabinetry dimensions STANDARD HEIGHT MODELS TALL HEIGHT MODELS inches (mm) inside height of cavity* min. - Page 8 STANDARD HEIGHT INTEGRATED MODELS ONLY - CUSTOM PANEL CALCULATIONS FRONT PANEL SPECIFICATIONS The following calculations assume the top of the upper panel is aligned with the top of the adjacent cabinetry. The fi nal 5⁄8 - 13⁄16” (16-20 mm) panel thickness panel/cabinetry alignment is achieved by adjusting the feet: min.
- Page 9 TALL HEIGHT INTEGRATED MODELS ONLY - CUSTOM PANEL CALCULATIONS FRONT PANEL SPECIFICATIONS The following calculations assume the top of the upper panel is aligned with the top of the adjacent cabinetry. The fi nal 5⁄8 - 13⁄16” (16-20 mm) panel thickness panel/cabinetry alignment is achieved by adjusting the feet: min.
-
Page 10: Cavity Preparation
CAVITY PREPARATION Important! COUNTERTOP The power outlet must be located in a cabinet adjacent to the dishwasher cavity. Moisture 110-120 VAC max. 15 A 3⁄8” (10mm) protection Water Connection tape must be applied. Recommended HOT (Maximum 140°F/60°C). Supplied hose to suit 3⁄8”... - Page 11 MAXIMUM DISTANCE OF HOSES & CORD FROM CHASSIS EDGE Left hand side Right hand side Drain hoses - 78 ½” (2000 mm) Drain hoses - 70 ½” (1800 mm) Inlet hose - 64 ¾” (1650 mm) Inlet hose - 49 ”...
- Page 12 NOW CHOOSE WHICH INSTALLATION METHOD (a) or (b) IS MORE SUITABLE FOR YOUR CABINETRY... RECOMMENDED METHOD (a) - SECURE WITHOUT DRAWER REMOVAL (FRAMELESS CABINETRY ONLY) ATTACH SIDE MOUNTING BRACKETS PULL THROUGH HOSES & PUSH INTO THE CAVITY optionally attach the Clip all four side mounting brackets into two top mounting brackets their slots using a flat-bladed screwdriver.
- Page 13 SECURE TO THE CABINETRY ON THE SIDES OPTIONALLY SECURE TO THE CABINETRY ABOVE The top mounting brackets will only bend (x2) Open the upwards a maximum drawer halfway. of 3⁄8” (10 mm). Using a flat-bladed screwdriver, prize the gray Replace the gray rubber plug out rubber plug back into of the trim moulding.
- Page 15 ALTERNATIVE METHOD (b) - SECURE BY DRAWER REMOVAL PULL THROUGH HOSES & PUSH INTO THE CAVITY REMOVE THE LOWER DRAWER To prevent kinked hoses, we recommend rotating the drawer counter-clockwise and resting it on its side after removal. optionally attach the two top mounting brackets (x2) You can initially level the product...
- Page 16 SECURE TO THE CABINETRY ON THE SIDES OPTIONALLY SECURE TO THE CABINETRY ABOVE To access the side brackets, The top mounting you might have to push aside brackets will only bend (x2) the insulation. After securing, upwards a maximum of ensure the sound insulation is 3⁄8”(10 mm).
- Page 17 FIT THE SUPPLIED TOEKICK PANEL (OPTIONAL FOR INTEGRATED MODELS) Where the toekick meets the bottom of the tub is the Mounting rail cut-off point Lay the toekick face down on Turn the toekick over and Smooth the edge with a file. a chopping board or similiar score along the same line Be careful of sharp edges.
- Page 18 INTEGRATED MODELS ONLY - INSTALLING THE FRONT PANELS ATTACH PANELS TO PANEL BRACKETS REMOVE BRACKETS FROM PRODUCT WARNING! Electrical Shock Hazard There must be at least 5⁄8” (16mm) x6 16 mm x6 3 screws used each side Before continuing, ensure that the product is disconnected from the power supply.
- Page 19 INTEGRATED MODELS ONLY - INSTALLING THE FRONT PANELS ADJUST PANEL HEIGHT TO ALIGN THE CABINETRY GAPS FITTING A CUSTOM TOEKICK PANEL 16 mm x5 5⁄8” (16mm) x5 + or - 1⁄16” (2 mm) With the front panels fitted, insert an appropriately sized Philips screwdriver into the hole above the door pin and rotate the panels up or down to align the gaps You can optionally glue your...
- Page 20 THERE ARE THREE DIFFERENT DRAINAGE OPTIONS. CHOOSE WHICH IS MORE SUITABLE. Dishwasher and Standpipe Ø 1½ ” (38 mm) Dishwasher using Air Break with Drain Hose Joiner Dishwasher using sink trap with drain hose joiner If space is limited for fixing, push If space is limited hose through drain for fixing, push...
-
Page 21: Final Checklist
FINAL CHECKLIST TROUBLESHOOTING Excessive water remaining above the filter plate, after the rinse cycle Check all parts are installed. Check for a kinked drain hose or blocked waste connection, highloop not Ensure product is level, securely fastened to the cabinetry and opens and properly installed or drain hose not routed correctly.
