User Manual
PRODUCT #:
ITEM:
FPDD605
Double Dishwasher from Fisher Paykel
FEATURES:
Available in White or Black. Features 163 F Sanitizing Temperature in Final Rinse, Double DishDrawer Energy Guide,
Economical Eco Option, 9 Wash Programs, Heating Element in each Drawer, Independent Wash Programs for
Separation of Wash Loads, Rinse Agent Dispenser, Unique Flow Thru Detergent Dispenser, Uses as Little as 2 Gallons
of Water per Drawer. Oversized item - ships by Truck.
SPECIFICATIONS:
32-1/4 - 34-5/8 H x 23-7/16 W x 22-7/16 D
Electrical:
110-120V AC, 9 amps
Suggested Outlet:
GFI outlet behind unit
Plumbing:
3/8" male hot/cold + 2" waste. Min PSI 4.3/Max. 120 PSI
Notes:
3 prong plug, door clearance 20.16"
Warranty:
1 Year
Certifications:
UL
Country of Origin:
United States
Installed By:
Client's Contractor
www.spaequip.com
BRAND:
Fisher & Paykel
SOURCE FOR PURCHASE:
SpaEquip Inc.
211 Wappo Ave
Calistoga, CA 94515
(707) 737-1100
www.spaequip.com
P: 707-737-1100 F: 707-737-1150
Product Code: FPDD605
Page 1 of 18
Advertisement
Table of Contents
Related Manuals for Fisher & Paykel DD24DCTX6
Summary of Contents for Fisher & Paykel DD24DCTX6
- Page 1 Product Code: FPDD605 User Manual PRODUCT #: ITEM: FPDD605 Double Dishwasher from Fisher Paykel BRAND: Fisher & Paykel SOURCE FOR PURCHASE: SpaEquip Inc. 211 Wappo Ave Calistoga, CA 94515 (707) 737-1100 www.spaequip.com FEATURES: Available in White or Black. Features 163 F Sanitizing Temperature in Final Rinse, Double DishDrawer Energy Guide, Economical Eco Option, 9 Wash Programs, Heating Element in each Drawer, Independent Wash Programs for Separation of Wash Loads, Rinse Agent Dispenser, Unique Flow Thru Detergent Dispenser, Uses as Little as 2 Gallons of Water per Drawer.
- Page 2 Product Code: FPDD605 STYLE LINE UP Designer Stainless Steel- Flat Door Designer Integrated Classic Stainless Steel DD24DDFTX6 DD24DDTI6 DD24DCTX6 DD24DDFX6 DD24DDI6 DD24DCX6 Classic White Classic Black DD24DCTW6 DD24DCTB6 DD24DCW6 DD24DCB6 www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 2 of 18...
- Page 3 Product Code: FPDD605 STYLE LINE UP Designer Stainless Steel- Flat Door Designer Integrated DD24SDFTX6 DD24SDTI6 DD24SDFX6 DD24SDI6 Classic Stainless Steel Classic White DD24SCTX6 DD24SCTW6 DD24SCX6 DD24SCW6 Classic Black DD24SCTB6 DD24SCB6 www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 3 of 18...
- Page 4 Product Code: FPDD605 PRODUCT COMPARISON TABLE DishDrawer® Tall DishDrawer® Tall DishDrawer® Std DishDrawer® Std Models Double Single Double Single FINISH Flat Door Stainless Steel Stainless Steel Integrated White Black CAPACITY Six place setting capacity per drawer Adjustable racks Folding tines 13”- top drawer 13”-top drawer Largest dinner plate capacity...
- Page 5 Product Code: FPDD605 DIMENSIONS- Inches DishDrawer® Tall DishDrawer® Tall Models Double Single DD24DCTX6 DD24SCTX6 DD24STI6 DD24STI6 DD24DCTW6 DD24DDFTX6 DD24DTI6 DD24SCTW6 DD24SDFTX6 ” cavity ” cavity DD24DCTB6 DD24SCTB6 PRODUCT DIMENSIONS ¾ ¾ 34-36 ⅜” ” ” Overall height* of product 34-36 ⅜”...
- Page 6 Product Code: FPDD605 DIMENSIONS DishDrawer® Std DishDrawer® Std Models Double Single DD24DCX6 DD24SCX6 DD24DCW6 DD24DDFX6 DD24DI6 DD24SCW6 DD24SDFX6 DD24SI6 DD24DCB6 DD24SCB6 PRODUCT DIMENSIONS 32 ¼” - 34 ” Overall height* of product 32 ¼” - 34 ” 32 ¼” - 34 ”...
- Page 7 Product Code: FPDD605 DIMENSIONS- Milimeteres DishDrawer® Tall DishDrawer® Tall Models Double Single DD24DCTX6 DD24SCTX6 DD24STI6 DD24STI6 DD24DCTW6 DD24DDFTX6 DD24DTI6 DD24SCTW6 DD24SDFTX6 456mm cavity 480mm cavity DD24DCTB6 DD24SCTB6 PRODUCT DIMENSIONS 863.5- 923.5 Overall height* of product 863.5- 923.5 863.5- 923.5 Overall width of product Overall depth of product (excl.
- Page 8 Product Code: FPDD605 DIMENSIONS DishDrawer® Std DishDrawer® Std Models Double Single DD24DCX6 DD24SCX6 DD24DCW6 DD24DDFX6 DD24DI6 DD24SCW6 DD24SDFX6 DD24SI6 DD24DCB6 DD24SCB6 PRODUCT DIMENSIONS 819.5-879.5 Overall height* of product 819.5-879.5 819.5-879.5 Overall width of product Overall depth of product (excl. curvature/handle) Depth of drawer (open) (excl.
- Page 9 Product Code: FPDD605 FINISH & DESIGN Feature Benefit Select the DishDrawer® A range of styles and finishes will model that will best compliment any kitchen and match compliment the design other Fisher & Paykel kitchen of the kitchen and the appliances.
- Page 10 Product Code: FPDD605 CAPACITY Flexible Racking System Feature Benefit Basket • The basket supports dishes and accessories and keeps them from coming Holds accessories in place and keeps dishes away into contact with the spray arm. from the spray arm. The drain filter access panel snaps onto the basket over the drain filter and •...
- Page 11 Product Code: FPDD605 Six Place Setting Capacity Per Drawer Feature Benefit DD24S models have a maximum 6 place Clean up after a dinner party using a double setting capacity, while DD24D models have a or two single DishDrawer®, or use a single maximum 12 place setting capacity (6 per drawer to economically wash a small load of drawer).
- Page 12 Product Code: FPDD605 WASH PROGRAMS Choice of Wash Programs Feature Benefit A wide range of wash programs for the perfect wash performance with All single and double DishDrawer® feature nine wash programs any type of dish load. Choose a fast eco program for lightly soiled, (including eco options).
- Page 13 Product Code: FPDD605 Genuine Half Load Wash Option Feature Benefit Running a single DishDrawer® is an efficient way of washing a small load of dishes. A Running a single DishDrawer® saves energy, single DishDrawer®, or half load, will save water and detergent compared to a both the user and the environment running conventional dishwasher.
- Page 14 Product Code: FPDD605 PERFORMANCE Ergonomically Superior Feature Benefit DishDrawer® incorporates the kitchen sliding drawer concept with the dishwasher, giving • the user easier access, improved visibility and Bending down to load a dishwasher will less movement to open and close. become a thing of the past.
- Page 15 Product Code: FPDD605 Water Softener (selected models) Feature Benefit DishDrawer® features a water softener that can be adjusted to give the best performance given the water hardness of different areas. Using hard water can be detrimental to The salt reservoir must be filled with granular performance, causing glasses to become salt made for dishwashing water softening opaque and dishes to become spotted or...
- Page 16 Product Code: FPDD605 SAFETY Three Stage Flood Protection Feature Benefit DishDrawer® comes with the following flood protection mechanisms: • High strength hose withstands water pressure several times greater than normal. Flood protection mechanisms minimise the risk of the DishDrawer® • overfilling for peace of mind for the user.
- Page 17 Product Code: FPDD605 CONTROLS Easy to Use Primary and Secondary Control Panels Feature Benefit The primary control panel features the following buttons: Primary Controls • Power – turns the DishDrawer® on and off or stops the wash programme mid-cycle. • Start/pause –...
- Page 18 Product Code: FPDD605 Clean Dishes Indicator (LCD models only) Feature Benefit Useful where dishes have been left in the DishDrawer® and the user The clean dish indicator option can be turned on, where the 00 symbol cannot remember if they are clean or dirty, or in situations where will remain in the electronic display after a wash program has finished household members regularly remove only a few clean dishes without to indicate the dishes are clean.
