Please read all instructions carefully before using this product Table of Contents Safety Notice Hardware Pack Assembly Instruction Parts List Warranty Ordering Parts Model PL-43231 Retain This Manual for Reference 07-01-05 OWNER'S MANUAL MARCY Magnetic Recumbent Bike PL-43231 IMPEX INC.
BEFORE YOU BEGIN Thank you for selecting the MARCY Magnetic Recumbent Bike PL-43231 by IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. provide you complete customer satisfaction. If you have any questions, or find there are missing or damaged parts, we guarantee you complete satisfaction through direct assistance from our factory.
OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. SAVE THESE INSTRUCTIONS.
Page 4
WARNING LABEL REPLACEMENT The Warning Label shown here has been placed on the Rear Stabilizer. If the label is missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the label in location shown.
ASSEMBLY INSTRUCTION NOTE: It is strongly recommended two or more people assembling this machine to avoid possible injury. STEP 1 (See Diagram1) A.) Attach the Front Stabilizer (#2) to the Main Frame (#1). Secure it with two M10 x 3” Carriage Bolts (#15), 1”...
Page 7
STEP 2 (See Diagram 2) A.) Note: In able to hold the Handlebar Post (#4) while connecting the cables and wires, extra help may be needed. Attach the Handlebar Post (#4) to the Main Frame (#1). Connect the Middle Computer Sensor Wire (#24) from the bottom of Handlebar Post to the Lower Computer Sensor Wire (#25) from the main body of the bike.
Page 8
STEP 3 (See Diagram 3) A.) Attach the Seat Support (#9) to the Seat Post (#8). Secure it with two M8 x 2 ¾” Hex Bolts (#21), four Ø 5/8” Washers (#20), and two M8 Aircraft Nuts (#22). B.) Attach the Seat Handle (#10) to the Seat Support. Secure it with two M8 x 2 ¾” Hex Bolts (#21), four Ø...
Page 9
STEP 4 (See Diagram 4) A.) Attach the Seat (#13) onto the Seat Support (#9). Secure it with four M8 x 5/8” Allen Bolts (#18). B.) Attach the Backrest Board (#14) to the Seat Support. Secure it with four M8 x 5/8” Allen Bolts (#18). DIAGRAM 4...
Page 10
STEP 5 (See Diagram 5) A.) Thread the Left Pedal (#11) Counterclockwise into the Left Crank. Thread the Right Pedal (#12) Clockwise into the Crank on the other side. DIAGRAM 5...
PARTS LIST KEY NO. DESCRIPTION Main Frame Front Stabilizer Rear Stabilizer Handlebar Post Handle Bar Computer Base Frame Seat Post Seat Support Seat Handle Left Pedal Right Pedal Seat Backrest Board M10 x 3” Carriage Bolt Ø 1” Bent Washer M10 Acorn Nut M8 x 5/8”...
COMPUTER AUTO START / STOP When exercise starts, the monitor will automatically turn on and display the progress. When exercise stops, the monitor will automatically turn off (after 4 minutes) to save energy. Press “MODE” key to scan Time, Speed, Distance, and Calories. DISPLAY: Time Display the elapsed time.
Maintenance and Storage 1. Inspect and tighten all parts each time you use the machine. Replace any worn parts immediately. 2. The bike can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use solvents. 3. Store the machine IN-DOOR. Excess moisture and water would cause rust on the frame.
IMPEX authorized service center or for products used for commercial or rental purposes. No other warranty beyond that specifically set forth above is authorized by IMPEX.
