LENCO DC-511 Manual

DC-511 Manual
For information and support, www.lenco.eu
1. Get to know your camera
5.0 Mega pixels resolution sensor
Digital still camera
Digital video camcorder
Built-in flash Light
8x digital zoom
2.4" TFT color display
Micro SD card support
2xAAA alkaline batteries
Smile detection
Anti-shaking still capture
2. Functional parts
1 Shutter Press this button to take photographs / start filming.
Power on/off Press this button to turn on, press again to turn off.
2
button
3 Strap hook Hook for attaching the wrist strap to the camera.
4 Busy indicator When the indicator is blinking,the camera is busy
Note: Keep the lens clean. Dirt and fingerprints will affect the
5 Lens
quality of the picture.
Use the built-in flash to give the subject extra lighting if it is in
6 Flash light dark surrounding （ t he best flash distance is recommended
within 1.5m).
Macro mode: Select this mode to take close-up
photographs (distance 11cm - 18cm).
7 Macro switch
Normal mode: Select this mode to take photographs from
0.5m - infinity.
8 LCD screen
9 Mode Press it to select PHOTO/VIDEO mode.
10 Menu Press it to enter camera setting mode.
11 Up
Up & Digital zoom in.
For RIGHT selection in menu mode.
12 Right/Flash light
For flash light function selection in photo mode.
13 Down Down & Digital zoom out.
14 Delete Press it to delete the photos/videos in playback mode.
15 Playback Press it to enter playback mode.
To start /stop recording a video clip in playback mode, or to
16 Enter
confirm changes in menu mode.
For LEFTselection in menu mode.
17 Left / EV±
For exposure value set up in photo/video mode.
18 Tripod connector To fix the camera on tripod (not included).
19 USB interface
Via this connection, you can connect to a computer.
20 Micro SD card slot SD card storage location.
21 Battery door Door for battery.
3. Explanation of the status icons
Item Function Description
Photographs mode.
Videos capture mode.
1 Mode selected
Photo playback mode.
Video playback mode.
Force flash: The flash is on in any
environment.
Auto flash: The camera determines if
2 Flash indicator
the flash should be used or not.
No flash : The flash is turned off.
3 Self-timer 10s Timer
4 ISO
Light Sensitivity select.
Photo mode: No. of pictures had been taken.
Photo/Video
Video mode: Recording time in second.
5
counter
Playback mode: No. of pictures or video file.
12M = 4032x3024; 8M = 3264x 2448
Selected
5M = 2560x1920; 3M = 2048x1536;
6
resolution
1.3M = 1280x960; VGA = 640x480
Super fine.
7 Picture quality
Fine.
Normal.
Micro SD card
The Micro SD card is inserted and will be
8
indication
used as storage for PHOTO and VIDEO
9 Brightness alert
Alert user to hold the camera steadily.
Mode (0.5m – infinity).
Normal/Macro
10
Macro mode (11cm – 18cm).
mode indicator
The batteries are full.
11 Battery indicator
The batteries are empty.
12 Exposure value
Show EV ± v alue.
13 White Balance
White balance selection.
14 Scene mode Landscape/Backlight/Night scene/Portrait/Sports
15 Smile detection
On/off
16 Zoom indicator Showing zoom ratio.
4. Details for camera setting
Single or 10s timer selection
capture Mode Single / 10s Timer
12M pixel resolution 4032 x 3024
8.0M pixel resolution 3264x 2448
5.0M pixel resolution 2560 x 1920
Resolution
3.0M pixel resolution 2048 x 1536
1.3M pixel resolution 1280 x 960
640 x 480
VGA resolution
Quality Super Fine/Fine/Normal Picture quality setting
Sharpness Strong/Normal/Soft Sharpness setting
Auto Automatic white balance
White balance selected for
Daylight
daylight surrounding
White balance selected for cloudy
Cloudy
surrounding
White balance
White balance selected for
Tungsten
tungsten lighting
White balance selected for
Fluorescent
fluorescent surrounding
Auto/Landscape/ Scene setting
Scene Backlight/Night
scene/Portrait/Sports
ISO Auto/50/100/200 Sensitivity select
Smile
On / Off Smile detection setting
detection
Anti-shaking On / Off Anti-shaking setting
VGA 640 x 480
Resolution Video resolution set up
QVGA 320 x 240
Date/Time YY/MM/DD Date or time setting
Auto power off Off / 1Minute / 3 Minutes Auto power off selection
Beep sound Off/On Beep sound setting
English/T-Chinese/ Select display language
S-Chinese/French/
Language
Deutsch/Italian/Spanish/
Portuguese/Japanese
Date stamp
Date stamp Date &Time /Date /Off
Select power frequency in your
Frequency 50Hz / 60Hz
location
Internal Memory/ Format the memory location
Format
SD card selection (all data will be lost).
Default setting
Default setting Cancel / OK
Version See the firmware version
Note: The camera will remain the last setting when it is turned off.
5. Using the camera
5.1 Installing the batteries
1. Open the battery door.
2. Insert 2xAAA alkaline batteries into the camera.
3. Close the battery door.
