Uniden Voyager Owner's Manual

Waterproof, portable two-way vhf transceiver
Hide thumbs Also See for Voyager:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual , Manual
Voyager
Owner's Manual

Advertisement

Table of Contents
loading

Related Manuals for Uniden Voyager

Summary of Contents for Uniden Voyager

  • Page 1 Voyager Owner’s Manual...

  • Page 2: Table Of Contents

    Contents Contents ....................1 Controls and Indications ................2 LCD Display ...................3 Warning! ....................4 Lithium Ion Battery Pack Warning ..........4 Introduction ....................5 Features ..................5 Technical Support and Service ............5 Included in your Package ..............6 Getting Started ..................7 Mounting the Drop-in Charger ............7 Attaching the Antenna ..............7 Attaching the Battery Pack.............8 Attaching the Beltclip ..............8...

  • Page 3: Controls And Indications

    Controls and Indicators Antenna Belt Clip Battery Battery Release Clip PTT (Push to Talk) Key Triple Watch Button (TRI) Lock Button (LOCK) TX Power / (/5W) Microphone 10. Speaker MIC Jack / Cap 11. Volume / Power Knob 12. Squelch Knob 13.

  • Page 4: Lcd Display

    Controls and Indicators LCD Display This indicator will appear only when the PTT switch is pressed and the radio is sending a transmission (TX). This indicator indicate whether the transmitting power is W or C Channel Number Display. D This indicator will be displayed if the displayed channel is a memory (MEM) channel for scanning.

  • Page 5: Warning

    Warning! • The VOYAGER is waterproof only when both the antenna, speaker mic cap and the battery are properly attached. • Do not operate the transmitter of any radio equipment unless all the Radio Frequency (RF) connectors are secure and any open connectors are properly terminated.

  • Page 6: Introduction

    The VOYAGER is a waterproof, portable two-way VHF transceiver. It is compact, lightweight, rugged and fits easily in your hand. This handheld VHF marine radio will give you consistent, outstanding performance in virtually all conditions and situations. To ensure that you get the most from the Voyager features, please read this operating guide carefully before using the unit. Features •...

  • Page 7: Included In Your Package

    Included in your Package AC Adapter Antenna VOYAGER DC Adapter Drop-in Charger Lithium Battery Beltclip Wrist Strap Mounting Screws Reference Guide/ Speaker Microphone Printed Material SM078...

  • Page 8: Getting Started

    Plug one end of the AC adapter into the wall outlet and the other end into the drop-in charger. When you mount the drop-in charger on your boat, use the DC adapter instead. Attaching the Antenna Attach the antenna to the VOYAGER. Be sure the antenna is firmly seated.

  • Page 9: Attaching The Battery Pack

    Place the battery pack onto the back of the radio. It will only fit in one way. Snap the battery release clip until it clicks. Be sure the battery pack fits tightly against the VOYAGER’s body. Attaching the Beltclip Hold the beltclip in the direction as follows. Apply it to the hanger piece on the back of the radio.

  • Page 10: Charging The Battery Pack

    The charger won’t overcharge the battery pack. When charging is completed, the charge LED is no longer illuminated. • Do not transmit when the VOYAGER is in the drop-in charger! • You can monitor incoming calls while the VOYAGER is in the drop-in charger.

  • Page 11: Operation

    See “Controls and Indicators” (page. 2) for button, knob, and key positions. • When you turn on your VOYAGER, it is automatically tuned to channel 16, frequency for distress, safety, and calling. • When you press any key (except PTT), a short tone sounds.

  • Page 12: Selecting A Channel

    Operation Selecting a Channel Turn on your VOYAGER. [ UP ] To select a higher channel, press the button. To select a lower channel, press the button. [ DOWN ] • To change the channel continuously, press and hold the button for more than 1 second.

  • Page 13: One-Touch Channel 16/9

    Operation One-touch Channel 6/9 Example: While you are monitoring channel 20, you want to check channel 16 or channel 9. You are now on channel 20. To monitor channel 16, press the 16/9 button. To monitor channel 9, press the 16/9 button again.

  • Page 14: Programming A Channel Into Memory

    Operation • While in Triple Watch mode, you can change the currently selected channel using the button. • A momentary press of the 16/9 button interrupts Triple Watch mode and remains on 16, or on channel 9 if you press once more. To return to the previous mode, simply press the button again.

  • Page 15: Transmitting

    Operation To stop scanning, press the SCAN button once more. SCAN and TRIPLE disappear from the display. • Scanning starts from the lowest to highest channel and stops when it finds an active channel. It remains on that channel until the transmission ends, then resumes scanning after a 3 second delay period. •...

  • Page 16: Lighted Keys And Display

    Operation Lighted Keys and Display To light the display, press any key excluding the PTT key. • If you press any button other than the PTT key while the display and keypad are illuminated, it remains illuminated for another 5 seconds. Battery Indicator When the unit is on, battery power is always indicated on the display.

  • Page 17: Tone Enable/Disable

    Operation Tone Enable/Disable The Tone sounds can de enabled/disabled as follows; Turn on the radio while pushing and holding [ ] sw. The Tone enable/disable will be switched. * When Tone enable is selected, all the tone sounds. * When Tone disable is selected, all the tone does not sound. When power switch is turned on without pressing [ ] sw, the previous setting of Tone enable/disable is kept.

  • Page 18: Troubleshooting

    Troubleshooting • Will not transmit on 5 watt range but will transmit on the  watt range Cause: Low voltage ➾ Recharge or replace the batteries • Will not transmit while on the charger Cause: Low voltage ➾ The unit is not designed to transmit while on the charger. The charger does not supply enough power for transmitting.

  • Page 19: Specifications

    Specifications General Channels Transmit 56 International Receive 57 International Frequency Control Frequency Tol. Transmit ± 1 PPM (at 25 ° C) Receive ± 1 PPM (at 25° C) Oper. Temp. -20°C to + 55°C Antenna Flexible Whip Microphone Built-in Electret type Display Liquid Crystal Display Speaker...

  • Page 20: International Marine Vhf Channel Chart

    Marine Channels - International Channel Frequency (MHz) Ship to Ship to Permanent Traffic Type Desig Transmit Receive Ship Shore Scan List 156.050 160.650 Duplex 156.100 160.700 Duplex 156.150 160.750 Duplex 156.200 160.800 Duplex 156.250 160.850 Duplex 156.300 156.300 156.350 160.950 Duplex 156.400 156.400 156.450 156.450...
  • Page 21 Marine Channels - International Channel Frequency (MHz) Ship to Ship to Permanent Traffic Type Desig Transmit Receive Ship Shore Scan List 156.275 160.875 Duplex 156.325 160.925 Duplex 156.375 156.375 156.425 156.425 156.475 156.475 RX Only 156.525 156.575 156.575 156.625 156.625 156.675 156.675 156.725 156.725 156.775 156.775...
  • Page 22 Memo...

  • Page 23: Warranty

    Elements of Warranty: Uniden warrants to the original retail owner for the duration of this warranty its Voyager (hereinafter referred to as the Product), to be free from defects in materials and craftsmanship with only the limitations or exclusions set out below.
  • Page 24 © 2008 Uniden Australia Pty Limited/Uniden New Zealand Limited Printed in China UTZZ01626ZZ(0)
