4.
NOTE: A channel cannot be linked to disarm and be controlled by a separate button on the same
transmitter. A different transmitter, however can still control that channel independently.
One application for Transmitter Code Linking is memory seats. Most memory seats have two recall positions. One
transmitter could output Channel 4 on disarm to recall one of the seat memory positions. Then, the second trans-
mitter would be linked to Channel 5 and each time it was used to disarm, the second seat position would be
recalled.
NOTE: Once a channel has been linked, that output is no longer programmable. A one second pulse
will be supplied whenever the system is disarmed using the linked transmitter.

table of zones

When using the diagnostic functions, use the Table of Zones to determine which input has triggered the system.
It is also helpful in deciding which input to use when connecting optional sensors and switches.
NOTE: The Warn Away triggers report to the LED when the system is disarmed. However, the siren
does not indicate a Warn Away trigger.
ZONE NO.
1
2
3
4
5
6
7
8
36
Press the disarm button on transmitter. While HOLDING the Valet/program switch, press
the transmitter button that is used to disarm the system. The siren will chirp once. The
selected channel is now linked to disarm of that transmitter only.
TRIGGER TYPE
Instant
Multiplex-Instant
Sensor 1
Programmable
Multiplex-Instant
Sensor 2
Multiplex-Warn Away
Sensor 1
Multiplex-Warn Away
Sensor 2
Progressive
WIRE/INPUT DESCRIPTION
H1/6 BLUE wire. Connect to optional hood/trunk pins.
BLUE and GREEN wires of plug-in shock sensor.
Inputs longer than 0.8 second will trigger this zone.
GREEN (H1/5) or VIOLET (H1/7): This input is
programmable to be an instant or progressive trigger.
GREEN/BROWN wire (H3/1): Use for optional
sensors. Inputs longer than 0.8 second will trigger this zone.
BLUE and GREEN wires of plug-in shock sensor.
Inputs shorter than 0.8 second will trigger this zone.
Green/brown wire (H3/1): For optional Warn Away
sensors. Inputs shorter than 0.8 second will trigger this zone.
Zone 7 is reported on power up and panic.
YELLOW wire (H1/9): If the ignition is turned on while
the system is armed, the siren will chirp ten times and then
the full triggered sequence will begin.
