- Page 1 ® 1/2” CROWN AIR STAPLER Model 54753 ASSEMBLY AND OPERATION INSTRUCTIONS 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our Web site at http://www.harborfreight.com TO PREVENT SERIOUS INJURY, READ AND UNDERSTAND ALL WARNINGS AND INSTRUCTIONS BEFORE USE. © ® Copyright 2005 by Harbor Freight Tools .
-
Page 2: Specifications
Wear an ANSI approved dust mask or respirator when working around metal, wood, and chemical dusts and mists. Other people in the work area must also wear ANSI approved impact safety goggles. SKU 54753 For technical questions, please call 1-800-444-3353. Page 2... - Page 3 19. Maintenance. The maintenance outlined in the maintenance section should be performed regularly. For your safety, this product should be serviced or repaired regularly only by a qualified technician. Compressed air only. Never use combustible gas as a power source. SKU 54753 For technical questions, please call 1-800-444-3353. Page 3...
- Page 4 When unpacking, check to make sure that the tool is intact and undamaged. If any parts are missing or broken, please call Harbor Freight Tools at the number on the cover of this manual as soon as possible. SKU 54753 For technical questions, please call 1-800-444-3353. Page 4...
- Page 5 To fire, place the nose of the Stapler on the workpiece. Gently and briefly squeeze the Trigger (28) once. Do not fire repeatedly. Staples could bounce off of one another, damaging the work piece or causing PERSONAL INJURY. SKU 54753 For technical questions, please call 1-800-444-3353. Page 5...
- Page 6 Periodically lubricate the driving mechanism and magazine with a light oil. Wipe down with a clean cloth. Inspect and clean the Air Filter Regulator and the Air Compressor according to manufacturer’s instructions. SKU 54753 For technical questions, please call 1-800-444-3353. Page 6...
-
Page 7: Parts List
REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. NOTE: Some parts are listed and shown for illustration purposes only and are not available individually as replacement parts. SKU 54753 For technical questions, please call 1-800-444-3353. Page 7... - Page 8 Assembly Drawing SKU 54753 For technical questions, please call 1-800-444-3353. Page 8...
