WHITE/BLACK
H2/5
This wire provides 200 mA programmable output whenever the transmitter
button(s) controlling Aux 3 is pressed. This output can be programmed to provide
the following types of outputs
Validity: Output that sends a signal as long as the transmission is re-
ceived.
Latched: Output that sends a signal when the Aux channel button is pressed
and continues until the same button is pressed.
Latched, reset with ignition: Similar to the latched output, this type of output
turns On the first time the Aux channel button is pressed, and turns Off the
next time the same button is pressed. This type of output additionally stops
and resets whenever the ignition is turned On and then Off.
30 seconds timed: The output sends a continuous signal for 30 seconds.
Note: Bitwriter® programs from 1 to 90 seconds.
LIGHT BLUE
H2/6
This wire produces a (-) 200mA output for progressive locks in which the driver
door unlocks first and the remaining locks unlock with a second press of the
unlock button on the remote.
20
Warning! Never use this wire to drive anything but
a relay or a low-current input! This transistorized out-
put can only supply 200 mA. Connecting directly to
a solenoid, motor, or other high-current device will
cause the module to fail.
(-) 200mA AUX 3 OUTPUT
Warning! Never use this wire to drive anything but
a relay or a low-current input! This transistorized out-
put can only supply 200 mA. Connecting directly to
a solenoid, motor, or other high-current device will
cause the module to fail.
(-) 200mA 2ND UNLOCK OUTPUT
