Dodge Charger 2012 User Manual

Hide thumbs Also See for Charger 2012:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual , Manual
> 2014 Charger // User GUide
includes srT

Advertisement

Table of Contents
loading

Related Manuals for Dodge Charger 2012

Summary of Contents for Dodge Charger 2012

  • Page 1 > 2014 Charger // User GUide includes srT...
  • Page 2 > iMportant This User Guide is intended to familiarize you with the important features of your vehicle. The DVD enclosed contains your Owner’s Manual, Navigation/Uconnect Manuals, Warranty ® Booklets, Tire Warranty and roadside assistance (new vehicles purchased in the U.S.) or roadside assistance (new vehicles purchased in Canada) in electronic format.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION/WELCOME UTILITY WELCOME FROM CHRYSLER GROUP LLC . . . 2 TRAILER TOWING WEIGHTS (MAXIMUM TRAILER WEIGHT RATINGS) . . . 71 CONTROLS AT A GLANCE RECREATIONAL TOWING DRIVER COCKPIT ....4 (BEHIND MOTORHOME, ETC.) .

  • Page 4: Introduction/Welcome

    INTRODUCTION/WELCOME WELCOME FROM CHRYSLER GROUP LLC Congratulations on selecting your new Chrysler Group LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essentials that are traditional to our vehicles. Your new Chrysler Group LLC vehicle has characteristics to enhance the driver's control under some driving conditions.
  • Page 5 If your symptoms persist, please see an authorized dealer. CHRYSLER, DODGE, JEEP, RAM TRUCK, SRT, ATF+4, MOPAR and Uconnect are registered trademarks of Chrysler Group LLC.

  • Page 6: Controls At A Glance

    CONTROLS AT A GLANCE DRIVER COCKPIT 1. Memory Seat pg. 20 2. Headlight Switch pg. 28 3. Turn Signal/Wiper/Washer/High Beams Lever (behind steering wheel) pg. 27 4. Instrument Cluster pg. 6 5. Electronic Vehicle Information Center (EVIC) Display 6. Engine Start/Stop Button pg. 12 7.
  • Page 7 CONTROLS AT A GLANCE 10. Power Outlet pg. 70 11. Shifter 12. Speed Control pg. 29 13. Electronic Vehicle Information Center (EVIC) Controls pg. 65 14. Trunk Release Button 15. Power Brake Pedal 16. Power Door Locks 17. Power Mirrors 18.

  • Page 8: Instrument Cluster

    CONTROLS AT A GLANCE INSTRUMENT CLUSTER 1. Engine Coolant Temperature Gauge 2. Tachometer 3. Electronic Vehicle Information Center (EVIC) Display Warning Lights - Low Fuel Warning Light - Engine Temperature Warning Light - Charging System Light** - Seat Belt Reminder Light - Oil Pressure Warning Light BRAKE - Brake Warning Light**...
  • Page 9 CONTROLS AT A GLANCE 4. Fuel Gauge 5. Speedometer 6. Fuel Filler Location Indicators - Turn Signal Indicators - Electronic Stability Control (ESC) Off Indicator* - High Beam Indicator - Door Ajar Indicator - Front Fog Light Indicator - Decklid Ajar Indicator - Vehicle Security Indicator* - Windshield Washer Fluid Low - Electronic Speed Control Set...

  • Page 10: Getting Started

    GETTING STARTED KEY FOB Locking And Unlocking The Doors • Press and release the LOCK button on the RKE transmitter to lock both doors. The turn signal lights will flash and the horn will chirp to acknowledge the signal. • Press and release the UNLOCK button on the RKE transmitter once to unlock the driver’s door (EVIC can be setup for driver door first, otherwise this will unlock all...
  • Page 11 GETTING STARTED Emergency Key • Should the battery in the vehicle or the Key Fob transmitter go dead, there is an emergency key located in the Key Fob. To remove the emergency key, slide the button at the back of the Key Fob sideways with your thumb and then pull the key out with your other hand.

  • Page 12: Remote Start

    GETTING STARTED REMOTE START • Press the REMOTE START button on the Key Fob twice within five seconds. Pressing the REMOTE START button a third time shuts the engine off. • To drive the vehicle, press the UNLOCK button and cycle the ignition to the ON/RUN position.
  • Page 13 GETTING STARTED To Lock the Vehicle • Both front door handles have LOCK buttons located on the outside of the handle. With one of the vehicle's Keyless Enter-N-Go™ Key Fobs located outside the vehicle and within 5 ft (1.5 m) of the driver's or passenger front door handle, press the door handle LOCK button to lock all four doors and trunk.
  • Page 14 GETTING STARTED To Enter the Trunk • With a valid Keyless Enter-N-Go™ Key Fob located outside the vehicle and within 5 ft (1.5 m) of the deck lid, press the button on the right side of Center High Mounted Stop Light (CHMSL) which is located on the deck lid.
  • Page 15 GETTING STARTED Stopping • Bring the vehicle to a complete stop. • Shift the transmission to PARK (P). • Press the ENGINE START/STOP button once. The ignition switch will return to the OFF position. NOTE: If the transmission is not in PARK and the vehicle is in motion, the ENGINE START/STOP button must be held for two seconds with the vehicle speed above 5 mph (8 km/h) before the engine will shut off.

  • Page 16: Security Alarm

    GETTING STARTED SECURITY ALARM To Arm: • Press the Keyless Enter-N-Go™ Start/Stop button until the Electronic Vehicle Informa- tion Center (EVIC) indicates that the vehicle ignition is “OFF”. Press the power door lock switch while the door is open, press the Key Fob LOCK button, or with one of the Key Fobs located outside the vehicle and within 5 ft (1.5 m) of the driver's and passenger front door handles, press the Keyless Enter-N-Go™...

  • Page 17: Supplemental Restraint System (Srs) - Air Bags

    GETTING STARTED NOTE: When the ignition switch is first turned to the ON/RUN position, this light will turn on for four to eight seconds as a bulb check. During the bulb check, if the driver's seat belt is unbuckled, a chime will sound. After the bulb check or when driving, if the driver or front passenger seat belt remains unbuckled, the Seat Belt Indicator Light will flash or remain on continuously.

  • Page 18: Child Restraints

    GETTING STARTED WARNING! • Relying on the air bags alone could lead to more severe injuries in a collision. The air bags work with your seat belt to restrain you properly. In some collisions, the air bags won't deploy at all. Always wear your seat belts even though you have air bags. •...
  • Page 19 GETTING STARTED LATCH — Lower Anchors And Tethers For CHildren • Your vehicle is equipped with the child restraint anchorage system called LATCH, which stands for Lower Anchors and Tethers for CHildren. • All rear seating positions have lower an- chors and top tether anchors.
  • Page 20 GETTING STARTED Installing The Child Restraint Using The LATCH Lower Anchors NOTE: Never “share” a LATCH anchorage with two or more child restraints. 1. Loosen the adjusters on the lower straps and on the tether strap of the child seat so that you can more easily attach the hooks or connectors to the vehicle anchorages.
  • Page 21 GETTING STARTED Installing The Top Tether Strap (With Either Lower Anchors Or Vehicle Seat Belt): • When installing a forward-facing child restraint, always secure the top tether strap, up to the tether anchor weight limit, whether the child restraint is installed with the lower anchors or the vehicle seat belt.

  • Page 22: Front Seats

    GETTING STARTED FRONT SEATS Power Seats • The power seat switches are located on the outboard side of the front seat cushions. • The power seat switch controls forward/ back, up/down and tilt adjustment. • The recline switch controls the angle of the seatback.
  • Page 23 GETTING STARTED • To program your Key Fobs, perform the following: • Change the ignition to OFF. • Select desired memory profile 1 or 2. • Once the profile has been recalled, press and release the SET (S) button on the memory switch, then press and release the side of the rocker switch labeled 1 or 2 accordingly.

  • Page 24: Rear Seats

    GETTING STARTED REAR SEATS Folding Rear Seatback • Pull on the loops, located near the outer top of the seatbacks, to fold down either or both seatbacks. These loops can be tucked away when not in use. • When the seatback is raised to the upright position, make sure it is latched by strongly pulling on the top of the seatback above the seat loop.

  • Page 25: Heated And Cooled Cupholders

    GETTING STARTED Rear Heated Seats • Second row heated seat switches are lo- cated on the rear of the center console. • Press the switch once to select High-level heating. Press the switch a second time to select Low-level heating. Press the switch a third time to shut the heating elements Off.

  • Page 26: Adjustable Pedals

    GETTING STARTED WARNING! • Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion or other physical conditions must exercise care when using the heated cup holders. It may cause burns even at low temperatures, especially if used for long periods of time.

  • Page 27: Tilt/Telescoping Steering Column

    GETTING STARTED TILT/TELESCOPING STEERING COLUMN Manual Tilt/Telescoping Steering Column • The tilt/telescoping control handle is lo- cated below the steering wheel at the end of the steering column. • To unlock the steering column, push the lever downward (toward the floor). •...

  • Page 28: Operating Your Vehicle

    OPERATING YOUR VEHICLE ENGINE BREAK-IN RECOMMENDATIONS • A long break-in period is not required for the engine and drivetrain (transmission and axle) in your vehicle. • Drive moderately during the first 300 miles (500 km). After the initial 60 miles (100 km), speeds up to 50 or 55 mph (80 or 90 km/h) are desirable.

  • Page 29: Turn Signal/Wiper/Washer/High Beam Lever

    OPERATING YOUR VEHICLE TURN SIGNAL/WIPER/WASHER/HIGH BEAM LEVER Turn Signal/Lane Change Assist • Tap the lever up or down once and the turn signal (right or left) will flash three times and automatically turn off. Front Wipers Intermittent, Low And High Operation •...

  • Page 30: Headlight Switch

    OPERATING YOUR VEHICLE HEADLIGHT SWITCH Automatic Headlights/Parking Lights/Headlights • Rotate the headlight switch, located on the instrument panel to the left of the steering wheel, to the first detent from the off position for parking light and to the second detent for headlight •...

  • Page 31: Speed Control

    OPERATING YOUR VEHICLE SPEED CONTROL • The Speed Control switches are located on the steering wheel. Cruise ON/OFF • Push the ON/OFF button to activate the Speed Control. • CRUISE READY will appear on the instrument cluster to indicate the Speed Control is on.
  • Page 32 OPERATING YOUR VEHICLE Distance Setting (ACC Only) • The specified following distance for ACC can be set by varying the distance setting between 3 (long), 2 (medium), and 1 (short). Using this distance setting and the vehicle speed, ACC calculates and sets the distance to the vehicle ahead. This distance setting displays in the Electronic Vehicle Information Center (EVIC).
  • Page 33 OPERATING YOUR VEHICLE • The default status of FCW is the “Far” setting. • The far setting provides warnings for potential collisions more distant in front of the vehicle, allowing the driver to have the most reaction time to avoid a collision. •...
  • Page 34 OPERATING YOUR VEHICLE WARNING! • Leaving the Electronic or Adaptive Speed Control system on when not in use is dangerous. You could accidentally set the system or cause it to go faster than you want. You could lose control and have a collision. Always leave the Electronic or Adaptive Speed Control system off when you are not using it.

  • Page 35: Electronic Shifter - 3.6L Engine

    OPERATING YOUR VEHICLE ELECTRONIC SHIFTER – 3.6L ENGINE • Your new vehicle is equipped with a state of the art, fuel efficient 8 speed transmis- sion. The electronic shift lever in this ve- hicle does not slide like a conventional shifter.

  • Page 36: Transmission Modes/Autostick

    OPERATING YOUR VEHICLE Shifting From REVERSE to DRIVE • Bring the vehicle to a complete stop, firmly depress the brake pedal, then pull the shift lever fully rearward and release when “D” is highlighted in the EVIC. • To shift back into REVERSE from DRIVE, bring the vehicle to a complete stop, firmly depress the brake pedal, press the lock button on the shift lever, then push the shift lever forward to the second detent and release when “R”...
  • Page 37 OPERATING YOUR VEHICLE Autostick® (3.6L 8–Speed Transmission, If Equipped) • Autostick® is only available on vehicles equipped with SPORT mode. • When the transmission is in DRIVE, it will operate automatically, shifting between the eight available gears. While in SPORT mode, the transmission will only shift be- tween seven of the eight available gears.

  • Page 38: Climate Controls

    OPERATING YOUR VEHICLE CLIMATE CONTROLS Uconnect® 4.3 Climate Controls Uconnect® 8.4 Climate Controls...
  • Page 39 OPERATING YOUR VEHICLE Climate Control Knobs • For your convenience the climate controls can also be operated by using the soft-keys located on the touchscreen or the climate control knobs below the touchscreen. Automatic Operation • Press the AUTO button. •...

  • Page 40: Power Sunroof

    OPERATING YOUR VEHICLE POWER SUNROOF • The power sunroof switch is located on the overhead console. Opening Sunroof Express Open • Press the switch rearward and release it within one-half second. The sunroof will fully open and stop automatically. Manual Open •...

  • Page 41: Wind Buffeting

    OPERATING YOUR VEHICLE Pinch Protection Feature • This feature will detect an obstruction in the opening of the sunroof during Express Close operation. If an obstruction in the path of the sunroof is detected, the sunroof will automatically retract. Remove the obstruction if this occurs. Next, press the switch forward and release to Express Close.

  • Page 42: Electronics

    ELECTRONICS YOUR VEHICLE'S SOUND SYSTEM 1. Uconnect® Voice Command Button pg. 63 2. Uconnect® Phone Button pg. 58 3. Steering Wheel Audio Controls (Left) pg. 56 4. Steering Wheel Audio Controls (Right) pg. 56 5. Volume Knob/Audio Power Button 6. SD Card (push in to insert/eject) pg. 57...
  • Page 43 ELECTRONICS 7. Uconnect® Radio pg. 42 8. Tune/Scroll Knob/Browse/Enter Button 9. CD Player pg. 50 10. Media Hub: Audio Jack / USB Port (located inside front console) pg. 56 11. CD Eject Button...

  • Page 44: Identifying Your Radio

    ELECTRONICS IDENTIFYING YOUR RADIO Uconnect® 4.3 & 4.3S • Models 4.3 and 4.3S have a 4.3 inch touch screen with hard–keys to each side of it. • Model 4.3S has all Model 4.3 features, plus SiriusXM Satellite Radio (1 year trial subscription included).

  • Page 45: Uconnect® 4.3 & 4.3S At A Glance

    ELECTRONICS Uconnect® 4.3 & 4.3S AT A GLANCE Displaying the Time • If the time is not currently displayed at the top of the screen when in Radio mode, press the Settings button, then touch clock. Select Show Time, then touch On. Setting the Time •...

  • Page 46: Uconnect® 8.4 & 8.4N At A Glance

    ELECTRONICS Equalizer • Touch the Equalizer soft-key to adjust the Bass, Mid and Treble. Use the + or - soft-key to adjust the equalizer to your desired settings. Press the Done soft-key when done. Balance/Fade • Touch the Balance/Fade soft-key to adjust the sound from the speakers. Use the arrow soft-key to adjust the sound level from the front and rear or right and left side speakers.
  • Page 47 ELECTRONICS Setting the Time • Model 8.4N synchronizes time automatically via GPS, so should not require any time adjustment. If you do need to set the time manually, follow the instructions below for Model 8.4. • For Model 8.4, turn the unit on, then touch the time display at the top of the screen. Touch Yes.

  • Page 48: Radio

    ELECTRONICS RADIO Models 4.3 & 4.3S Models 8.4 & 8.4N...

  • Page 49: Siriusxm Satellite Radio

    ELECTRONICS • To access the Radio mode, touch the Radio hard-key on the upper left side of the faceplate (4.3 & 4.3S) or the Radio soft-key at the lower left of the screen (8.4 & 8.4N). • Unless otherwise noted, the information provided on the operation and functionality of the radios in this section is common to all Uconnect®...
  • Page 50 ELECTRONICS Selecting SiriusXM Satellite Channels Seek Up/Seek Down • Touch the Seek arrow soft-keys for less than two seconds to seek through channels in SAT mode. • Touch and hold either arrow soft-key for more than two seconds to bypass channels without stopping.
  • Page 51 ELECTRONICS Browse • Lets you browse the SiriusXM Satellite Radio channel listing, Favorites, Genres, Game Zone, and Weather channels. Jump setting, and also provides the SiriusXM Satellite Radio channel list. Browse contains many sub-menus. Browse Sub-Menu Sub-Menu Description Shows the channel listing. Genre Provides a list of all genres, and lets you jump to a channel within the selected genre.

  • Page 52: Ipod®/Cd/Aux Controls

    ELECTRONICS iPod®/CD/AUX CONTROLS Models 4.3 & 4.3S • The iPod®/CD/AUX controls are accessed by pressing the Player hard-key to enter the Player main screen, then touch the source soft-key and choose between Disc, AUX, iPod® or Bluetooth®. NOTE: Uconnect® will usually automatically switch to the appropriate mode when something is first connected or inserted into the system.
  • Page 53 ELECTRONICS Models 8.4 & 8.4N • The iPod®/USB, CD, Audio Jack, SD Card or Bluetooth® source is accessed by touching the Player soft-key to enter the Player main screen, then touch the source soft-key and choose between Disc, Aux, iPod®, Bluetooth® or SD Card. NOTE: Uconnect®...

  • Page 54: Garmin® Navigation (8.4N Only)

    ELECTRONICS GARMIN® NAVIGATION (8.4N ONLY) • Uconnect® 8.4N integrates Garmin’s consumer-friendly navigation into your vehicle. Garmin Navigation includes Lane Assist and Junction View, Speed Limit information, and a database with over 6 million points of interest. • Touch the NAV soft-key in the menu bar to access the Navigation system. Changing the Navigation Voice Prompt Volume 1.
  • Page 55 ELECTRONICS • Dead Reckoning technology uses the speed sensors attached to your vehicle’s drivetrain and a gyroscope to supplement the existing GPS data. The combined data provides accurate positioning for your vehicle in tunnels, indoor parking garages, urban canyons, and any other area where GPS signals can become obstructed. Finding Points of Interest •...
  • Page 56 ELECTRONICS Following Your Route • Your route is marked with a magenta line on the map. If you depart from the original route, your route is recalculated. A speed limit icon could appear as you travel on major roadways. • Lane Assist helps you decide which lane to be in at upcoming junctions. •...

  • Page 57: Siriusxm Travel Link (8.4N Only)

    ELECTRONICS SiriusXM TRAVEL LINK (8.4N ONLY) • SiriusXM Travel Link is only available in the United States. • SiriusXM Travel Link brings a wealth of useful information into your vehicle and right to your fingertips. • To access Travel Link, touch More soft-key, then the Travel Link soft-key. NOTE: SiriusXM Travel Link requires a subscription, sold separately after the 1 year trial subscrip- tion included with your vehicle purchase.

  • Page 58: Steering Wheel Audio Controls

    ELECTRONICS STEERING WHEEL AUDIO CONTROLS • The steering wheel audio controls are lo- cated on the rear surface of the steering wheel. Left Switch • Press the switch up or down to search for the next listenable station or select the next or previous CD track.
  • Page 59 ELECTRONICS USB Port • Connect your iPod® or compatible device using a USB cable into the USB Port. The USB Port is contained within the center console. USB Memory sticks with audio files can also be used. Then, audio from the device can be played on the vehicles sound system while providing metadata (artist, track title, album, etc.) information on the radio display.

  • Page 60: Uconnect® Phone (Bluetooth® Hands Free Calling)

    ELECTRONICS Uconnect® Phone (Bluetooth® HANDS FREE CALLING) • If the Uconnect® Phone Button exists on your steering wheel, then you have the Uconnect® Phone features. • The Uconnect® Phone is a voice-activated, hands-free, in-vehicle communications system with Voice Command Capability (see Voice Command section). •...
  • Page 61 ELECTRONICS Start pairing procedure on mobile phone • Search for available devices on your Bluetooth® enabled mobile phone. This is usually within Settings or Options under “Bluetooth®.” See your mobile phone’s manual for details. • When your phone finds the system, select “Uconnect®” as the paired device. Models 4.3 &...
  • Page 62 ELECTRONICS Phone Menu Screen – Models 4.3 & 4.3S Phone Menu Screen – Models 8.4 & 8.4N...
  • Page 63 ELECTRONICS Making A Phone Call • Press the Uconnect® Phone button • After the BEEP, say “dial” then the number (or “call” then the name as listed in your phone; see Phonebook). NOTE: You can also initiate a call by using the touchscreen on the Phone main screen. Receiving A Call –...
  • Page 64 ELECTRONICS Voice Command Tips (8.4 and 8.4N ONLY) • Using complete names (i.e; Call John Doe vs. Call John) will result in greater system accuracy. • You can “chain” commands together for faster results. Say “Call John Doe, mobile”, for example.

  • Page 65: Uconnect® Voice Command (8.4 & 8.4N Only)

    ELECTRONICS Uconnect® Voice Command (8.4 & 8.4N ONLY) • If the Uconnect® Voice Command button exists on your steering wheel, then you have the Voice Command feature. • The Voice Command feature lets you keep your hands on the steering wheel, and your eyes on the road.
  • Page 66 ELECTRONICS NOTE: For the shortened SiriusXM Satellite Radio mode commands to be recognized you must be in that mode. For example, if you are in SiriusXM Satellite Radio mode you can say “39”, but if you are not in SiriusXM mode, you would need to say “Tune to Satellite Channel 39.” Common Navigation Voice Commands •...

  • Page 67: Electronic Vehicle Information Center (Evic)

    ELECTRONICS WARNING! Any voice commanded system should be used only in safe driving conditions following applicable laws regarding phone use. Your attention should be focused on safely oper- ating the vehicle. Failure to do so may result in a collision causing you and others to be severely injured or killed.

  • Page 68: Programmable Features

    ELECTRONICS PROGRAMMABLE FEATURES Electronic Vehicle Information Center (EVIC) • The EVIC can be used to view or change the following settings. Press the UP DOWN button until System Setup displays, then press the SELECT button. Scroll through the settings using the UP or DOWN buttons. Press the SELECT button to change the setting.

  • Page 69: Universal Garage Door Opener (Homelink®)

    ELECTRONICS • Touch the More soft-key on the bottom of the screen, then touch the Settings soft-key to access the Settings screen. When making a selection, scroll up or down until the preferred setting is highlighted, then press and release the preferred setting until a check-mark appears next to the setting, showing that setting has been selected.
  • Page 70 ELECTRONICS Programming A Rolling Code • For programming Garage Door Openers that were manufactured after 1995. These Garage Door Openers can be identified by the “LEARN” or “TRAIN” button located where the hanging antenna is attached to the Garage Door Opener. It is NOT the button that is normally used to open and close the door.
  • Page 71 ELECTRONICS Programming A Non-Rolling Code • For programming Garage Door Openers manufactured before 1995. 1. Turn the ignition switch to the ON/RUN position. 2. Place the hand-held transmitter 1 to 3 in (3 to 8 cm) away from the HomeLink® button you wish to program while keeping the HomeLink®...

  • Page 72: Power Outlet

    ELECTRONICS POWER OUTLET • There are three 12 Volt electrical outlets on this vehicle. • The front 12 Volt power outlet has power available only when the ignition is placed in the ACC or RUN position. • The center console outlet is powered directly from the battery (power available at all times).

  • Page 73: Utility

    UTILITY TRAILER TOWING WEIGHTS (MAXIMUM TRAILER WEIGHT RATINGS) Engine/ Frontal Area Max. GTW Max. Tongue Wt. Transmission (Gross Trailer Wt.) (See Note) 22 sq ft (2.04 sq m) 1,000 lbs (454 kg) 100 lbs (45 kg) 3.6L Automatic 32 sq ft (2.97 sq m) 1,000 lbs (454 kg) 100 lbs (45 kg) 5.7L Automatic...

  • Page 74: Srt

    AUTOSTICK® Steering Wheel Mounted Paddle Shifters Or Console Mounted Shifter • AutoStick® is a driver-interactive trans- mission feature that offers manual gear shifting to provide you with more control of the vehicle. AutoStick® allows you to maximize engine braking, and improve overall vehicle performance.

  • Page 75: Electronic Control Damping System

    ELECTRONIC CONTROL DAMPING SYSTEM • This vehicle may be equipped with an electronic controlled damping system. This system reduces body roll and pitch in many driving situations including cornering, acceleration and braking. There are three modes of operation: Automatic (Auto) Mode •...

  • Page 76: Performance Features

    Track Mode • In track mode, the transmission has a sportier, more aggressive shift pattern. • This mode includes SPORT Suspension and affects transmission shifting in ei- ther normal Drive or Autostick®. • If Autostick® (console shifter or paddle shifters) is engaged while in “Track” mode, the transmission will remain in the selected gear even when maximum en- gine speed is reached.
  • Page 77 1/8 Mile, 1/4 Mile • When selected, this screen displays the time it takes the vehicle to travel 1/8 mile (1/4 mile) within 30 seconds and the vehicle's speed when it reaches 1/8 mile (1/4 mile). Instantaneous G-Force • When selected, this screen displays the current G-Force (lateral and longitudinal) along with a friction circle that displays the directions of the forces.

  • Page 78: Summer/Three-Season Tires

    Gauges 2 • Coolant Temperature • Oil Temperature • Transmission Temperature • Intake Air Temperature • Oil Pressure • Battery Voltage Engine • When selected, this screen displays miles per hour (mph), horsepower (hp), torque (ft/lb), oil pressure (psi) and gear selector values. Handling •...

  • Page 79: What To Do In Emergencies

    WHAT TO DO IN EMERGENCIES ROADSIDE ASSISTANCE • Dial toll-free 1-800-521-2779 for U.S. Residents or 1-800-363-4869 for Canadian Residents. • Provide your name, vehicle identification number, license plate number, and your loca- tion, including the telephone number from which you are calling. •...
  • Page 80 WHAT TO DO IN EMERGENCIES • Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly. The TPMS malfunction indicator is combined with the low tire pressure telltale. When the system detects a malfunction, the telltale will flash for approximately one minute and then remain continuously illuminated.
  • Page 81 WHAT TO DO IN EMERGENCIES BRAKE - Brake Warning Light • The Brake Warning light illuminates when there is either a system malfunction or the parking brake is applied. If the light is on and the parking brake is not applied, it indicates a possible brake hydraulic malfunction, brake booster problem or an Anti-Lock Brake System problem.
  • Page 82 WHAT TO DO IN EMERGENCIES - Electronic Throttle Control (ETC) Indicator Light • This light informs you of a problem with the system. • If a problem is detected, the light will come on while the engine is running. Cycle the ignition when the vehicle has completely stopped and the shift lever is placed in the PARK position;...

  • Page 83: If Your Engine Overheats

    WHAT TO DO IN EMERGENCIES Vehicles Not Equipped With Keyless Enter-N-Go™ • Turn the ignition switch to the ON/RUN position (Do not start the engine.) • Fully depress the accelerator pedal, slowly, three times within 10 seconds. • Turn the ignition switch to the OFF/LOCK position. NOTE: If the indicator message illuminates when you start the vehicle, the oil change indicator system did not reset.

  • Page 84: Jacking And Tire Changing

    WHAT TO DO IN EMERGENCIES JACKING AND TIRE CHANGING Jack Location/Spare Tire Stowage • The jack and spare tire are both stowed under an access cover in the trunk. Follow these steps to access the jack and spare tire. NOTE: The spare tire must be removed in order to access the jack.
  • Page 85 WHAT TO DO IN EMERGENCIES 3. Remove the fastener securing the spare tire. 4. Remove the spare tire. 5. Remove the fastener securing the jack. 6. Remove the scissors jack and lug wrench from the spare wheel as an assembly. Turn the jack screw to the left to loosen the lug wrench, and remove the wrench from the jack assembly.
  • Page 86 WHAT TO DO IN EMERGENCIES Preparations For Jacking 1. Park the vehicle on a firm, level surface as far from the edge of the roadway as possible. Avoid icy or slippery areas. 2. Turn on the Hazard Warning flasher. 3. Set the parking brake. 4.
  • Page 87 WHAT TO DO IN EMERGENCIES 4. Place the jack underneath the lift area that is closest to the flat tire. Turn the jack screw clockwise to firmly engage the jack saddle with the lift area of the sill flange. NOTE: If the vehicle is too low for jack placement, slide the jack on its side and rotate it up into position.
  • Page 88 WHAT TO DO IN EMERGENCIES 10. Finish tightening the lug nuts. Push down on the wrench while at the end of the handle for increased leverage. Tighten the lug nuts in a star pattern until each nut has been tightened twice. The correct tightness of each lug nut is 110 ft-lb. (150 N·m). If in doubt about the correct tightness, have them checked with a torque wrench by your autho- rized dealer or at a service station.
  • Page 89 WHAT TO DO IN EMERGENCIES WARNING! • Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel.

  • Page 90: Tirefit Kit

    WHAT TO DO IN EMERGENCIES TIREFIT KIT • Your vehicle may be equipped with a TIREFIT Kit. • Small punctures up to 1/4” (6 mm) in the tire tread can be sealed with TIREFIT. Foreign objects (e.g., screws or nails) should not be removed from the tire. TIREFIT can be used in outside temperatures down to approximately -4°F (-20°C).
  • Page 91 WHAT TO DO IN EMERGENCIES Using The Power Button • Push and release the Power Button (4) once to turn On the TIREFIT kit. Push and release the Power Button (4) again to turn Off the TIREFIT kit. Using The Deflation Button •...
  • Page 92 WHAT TO DO IN EMERGENCIES (B) Setting Up To Use TIREFIT: 1. Turn the Mode Select Knob (5) to the Sealant Mode position. 2. Uncoil the Sealant Hose (6) and then remove the cap from the fitting at the end of the hose. 3.
  • Page 93 WHAT TO DO IN EMERGENCIES • If the tire does not inflate to at least 26 psi (1.8 kPa) pressure within 15 minutes: • The tire is too badly damaged. Do not attempt to drive the vehicle further. Call for assistance.
  • Page 94 WHAT TO DO IN EMERGENCIES NOTE: • If the tire becomes over-inflated, press the Deflation Button to reduce the tire pressure to the recommended inflation pressure before continuing. • When having the tire serviced, advise the authorized dealer or service center that the tire has been sealed using the TIREFIT service kit.
  • Page 95 WHAT TO DO IN EMERGENCIES WARNING! • Do not attempt to seal a tire on the side of the vehicle closest to traffic. Pull far enough off the road to avoid the danger of being hit when using the TIREFIT kit. •...

  • Page 96: Battery Location

    WHAT TO DO IN EMERGENCIES BATTERY LOCATION • The battery is stored under an access cover in the trunk. Remote battery posts are located on the right side of the engine compartment for jump-starting. JUMP-STARTING • If your vehicle has a discharged battery it can be jump-started using a set of jumper cables and a battery in another vehicle or by using a portable battery booster pack.
  • Page 97 WHAT TO DO IN EMERGENCIES • Once the engine is started, remove the jumper cables in the reverse sequence: • Disconnect the negative (-) jumper cable from the remote negative (-) post of the vehicle with the discharged battery. • Disconnect the negative end (-) of the jumper cable from the negative (-) post of the booster battery.

  • Page 98: Shift Lever Override- 5 Speed Transmission

    WHAT TO DO IN EMERGENCIES SHIFT LEVER OVERRIDE- 5 SPEED TRANSMISSION • If a malfunction occurs and the shift lever cannot be moved out of the PARK posi- tion, you can use the following procedure to temporarily move the shift lever: •...
  • Page 99 WHAT TO DO IN EMERGENCIES • In order to push or tow the vehicle in cases where the transmission will not shift out of PARK (such as a dead battery), a Manual Park Release is available. Follow these steps to use the Manual Park Release: •...

  • Page 100: Towing A Disabled Vehicle

    WHAT TO DO IN EMERGENCIES...

  • Page 101: Freeing A Stuck Vehicle

    WHAT TO DO IN EMERGENCIES FREEING A STUCK VEHICLE • If your vehicle becomes stuck in mud, sand or snow, it can often be moved using a rocking motion. Turn the steering wheel right and left to clear the area around the front wheels.

  • Page 102: Event Data Recorder (Edr)

    WHAT TO DO IN EMERGENCIES EVENT DATA RECORDER (EDR) • This vehicle is equipped with an Event Data Recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.

  • Page 103: Maintaining Your Vehicle

    MAINTAINING YOUR VEHICLE OPENING THE HOOD • Pull the hood release lever located on the instrument panel, below the headlight switch. • Raise the hood and locate the safety catch lever, in the middle of the hood opening. • Push the safety catch lever to the left while lifting the hood at the same time.

  • Page 104: Fuel Door Release

    MAINTAINING YOUR VEHICLE FUEL DOOR RELEASE • The fuel door release button is located in the driver's door map pocket. • Push the button once and release to open the fuel door. Fuel Door Emergency Release • To manually open the fuel door, remove the cover and pull the release cable lo- cated in the trunk.
  • Page 105 MAINTAINING YOUR VEHICLE Emergency Refueling • A funnel is provided (located in the trunk in the spare tire area) to open the flapper door to allow for emergency refueling with a gas can. CAUTION! To avoid fuel spillage and overfilling, do not “top off” the fuel tank after filling. WARNING! •...

  • Page 106: Engine Compartment

    MAINTAINING YOUR VEHICLE...
  • Page 107 MAINTAINING YOUR VEHICLE...
  • Page 108 MAINTAINING YOUR VEHICLE...

  • Page 109: Fluids And Capacities

    MAINTAINING YOUR VEHICLE FLUIDS AND CAPACITIES Non-SRT Component Fluid, Lubricant, or Genuine Part Capacities We recommend you use MOPAR® 10 Quarts (9.5 Liters) Engine Coolant – Antifreeze/Coolant Ten Year/ Includes heater and 3.6L Engine 150,000 Mile Formula OAT coolant recovery bottle (Organic Additive Technology).
  • Page 110 MAINTAINING YOUR VEHICLE Component Fluid, Lubricant, or Genuine Part Capacities Use only MOPAR® ZF 8&9 Speed ATF™ Automatic Transmission Automatic Transmission – Fluid or equivalent. Failure to use — 8 Speed Transmission the correct fluid may affect the function or performance of your transmission.
  • Page 111 MAINTAINING YOUR VEHICLE Component Fluid, Lubricant, or Genuine Part Capacities We recommend you use MOPAR® 15.2 Quarts (14.4 Liters) Engine Coolant – Antifreeze/Coolant Ten Year/ Includes heater and 6.4L Engine 150,000 Mile Formula OAT coolant recovery bottle (Organic Additive Technology). filled to MAX level.

  • Page 112: Maintenance Schedule

    MAINTAINING YOUR VEHICLE CAUTION! • Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion protection. Organic Additive Technology (OAT) engine coolant is different and should not be mixed with Hybrid Organic Additive Technology (HOAT) engine coolant (antifreeze) or any “globally compatible”...
  • Page 113 MAINTAINING YOUR VEHICLE Your authorized dealer will reset the oil change indicator message after completing the scheduled oil change. If a scheduled oil change is performed by someone other than your authorized dealer, the message can be reset by referring to the steps described under “Electronic Vehicle Information Center (EVIC)/Oil Change Required”...
  • Page 114 MAINTAINING YOUR VEHICLE...
  • Page 115 MAINTAINING YOUR VEHICLE...
  • Page 116 MAINTAINING YOUR VEHICLE...

  • Page 117: Srt Maintenance Schedule

    MAINTAINING YOUR VEHICLE...
  • Page 118 MAINTAINING YOUR VEHICLE...
  • Page 119 MAINTAINING YOUR VEHICLE...

  • Page 120: Fuses

    MAINTAINING YOUR VEHICLE FUSES Front Integrated Power Module (Fuses) • The Front Integrated Power Module (fuses) is located in the engine compartment on the right hand side near the Washer Fluid Reservoir. This module contains fuses and relays. Front Integrated Power Module Cavity Cartridge Fuse Mini-Fuse...
  • Page 121 MAINTAINING YOUR VEHICLE Cavity Cartridge Fuse Mini-Fuse Description 50 Amp Red Power Steering #2 30 Amp Pink Wiper Motor 30 Amp Pink Headlamp Washers 25 Amp Neutral Fuel Pump 15 Amp Blue Transmission Shifter 25 Amp Neutral Engine Module 25 Amp Neutral Powertrain #1 20 Amp Yellow Powertrain #2...
  • Page 122 MAINTAINING YOUR VEHICLE Cavity Cartridge Fuse Mini-Fuse Description 10 Amp Red Tire Pressure Monitor 25 Amp Neutral Amplifier 25 Amp Neutral Power Seats 15 Amp Blue HVAC Module/Cluster 15 Amp Blue Ignition Switch/Wireless Module 10 Amp Red Steering Column Module/Clock 10 Amp Red Battery Sensor 15 Amp Blue...
  • Page 123 MAINTAINING YOUR VEHICLE...

  • Page 124: Tire Pressures

    MAINTAINING YOUR VEHICLE TIRE PRESSURES • Check the inflation pressure of each tire, including the spare tire, at least monthly and inflate to the recommended pressure for your vehicle. • The tire pressures recommended for your vehicle are found on the “Tire and Loading Information”...

  • Page 125: Wheel And Wheel Trim Care

    MAINTAINING YOUR VEHICLE WHEEL AND WHEEL TRIM CARE • All wheels and wheel trim, especially aluminum and chrome plated wheels, should be cleaned regularly with a mild soap and water to prevent corrosion. • To remove heavy soil and/or excessive brake dust, use MOPAR® Wheel Cleaner or equivalent or select a non-abrasive, non-acidic cleaner.

  • Page 126: Consumer Assistance

    • A street address is required when ordering manuals (no P.O. Boxes). • The Owner's Manual and User Guide electronic files are also available on the Chrysler, Jeep, Ram Truck, Dodge and SRT websites. • Click on the “For Owners” tab, select “Owner/Service Manuals”, then select your desired...

  • Page 127: Reporting Safety Defects In The United States

    CONSUMER ASSISTANCE REPORTING SAFETY DEFECTS IN THE UNITED STATES • If you believe that your vehicle has a defect that could cause a collision or cause injury or death, you should immediately inform the National Highway Traffic Safety Administra- tion (NHTSA) in addition to notifying the manufacturer. •...

  • Page 128: Mopar® Accessories

    • For the full line of Authentic Dodge Accessories by Mopar®, visit your local Dodge dealership or online at mopar.com for U.S. residents and mopar.ca for Canadian residents.

  • Page 129: Index

    INDEX Adaptive Cruise Control (ACC) Electronic Speed Control (Cruise Control) ... .29 (Cruise Control) ... .29 Adjustable Pedals ... .24 Electronic Vehicle Information Airbag .
  • Page 130 INDEX Instrument Cluster ... . .7 Outlet Indicators ....7 Power ....70 Interior and Instrument Lights .
  • Page 131 INDEX Tether Anchor, Child Restraint ..19 Trailer Weight ....71 Tilt Steering Column ...25 Transmission Tilt/Telescoping Steering Column Fluid .

  • Page 132: Faq (How To?)

    • How do I configure my Universal Garage Door Opener (HomeLink)? pg. 67 UTILITY • How do I know how much I can tow with my Dodge Charger? pg. 71 WHAT TO DO IN EMERGENCIES • What do I do if my TPMS warning light is blinking? pg. 77 •...
  • Page 133 NOTES...
  • Page 134 NOTES...
  • Page 135 NOTES...
  • Page 136 NOTES...
  • Page 137 NOTES...
  • Page 138 NOTES...

  • Page 139: Driving And Alcohol

    DoDge.coM This guide has been prepared to help you get quickly acquainted with your new dodge and to provide a convenient reference source for common questions. However, it is not a substitute for your Owner’s Manual. For complete operational instructions, maintenance procedures and important safety messages, please consult your Owner’s Manual, Navigation/Uconnect...
  • Page 140 DownloaD a Free electronic copy oF the owner’s Manual or warranty Booklet by visiting the Owners tab at: www.dodge.com (U.s.) www.dodge.ca (Canada) 14d481-926-AA second edition charger User Guide...

This manual is also suitable for:

2014 charger2014 charger srt

Table of Contents
