Sharp AR-155 Operation Manual

Digital laser copier
Hide thumbs Also See for AR-155:
Table of Contents

Advertisement

Quick Links

Download this manual
MODEL
AR-155
AR-155N
DIGITAL LASER COPIER
OPERATION MANUAL
Page
3
12
20
23
29
38
42

Advertisement

Table of Contents
loading

Related Manuals for Sharp AR-155

Summary of Contents for Sharp AR-155

  • Page 1: Table Of Contents

    MODEL AR-155 AR-155N DIGITAL LASER COPIER OPERATION MANUAL Page • GETTING STARTED • MAKING COPIES • SPECIAL FUNCTIONS • SUPPLIES AND USER MAINTENANCE • COPIER TROUBLE? • APPENDIX • OPTIONAL EQUIPMENT...
  • Page 2 VAROITUS! CLASS 1 LASER PRODUCT LAITTEEN KÄYTTÄMINEN MUULLA KUIN TÄSSÄ KÄYTTÖOHJEESSA MAINITULLA LASER KLASSE 1 TAVALLA SAATTAA ALTISTAA KÄYTTÄJÄN TURVALLISUUSLUOKAN 1 LUOKAN 1 LASERLAITE YLITTÄVÄLLE NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE. KLASS 1 LASERAPPARAT VARNING OM APPARATEN ANVÄNDS PÅ ANNAT SÄTT ÄN I DENNA BRUKSANVISNING SPECIFICERATS, KAN ANVÄNDAREN UTSÄTTAS FÖR...
  • Page 3 CONTENTS GETTING STARTED INTRODUCTION CAUTIONS MAIN FEATURES PART NAMES OPERATION PANEL COPIER INSTALLATION CAUTIONS ON HANDLING LOADING COPY PAPER MAKING COPIES NORMAL COPYING – Stream feeding mode EXPOSURE ADJUSTMENT/PHOTO COPYING REDUCTION/ENLARGEMENT/ZOOM BYPASS FEED (including special paper) SPECIAL FUNCTIONS DESCRIPTION OF SPECIAL FUNCTIONS TONER SAVE MODE USER PROGRAMS (power save modes, auto clear time, stream feeding mode)
  • Page 4 CONTENTS SUPPLIES AND USER MAINTENANCE TD CARTRIDGE REPLACEMENT DRUM CARTRIDGE REPLACEMENT USER MAINTENANCE – Cabinet – Original table and original cover – Transfer charger – When copier is not in use COPIER TROUBLE? MISFEED REMOVAL – A Misfeed in the paper feed area –...

  • Page 5: Getting Started

    GETTING STARTED This chapter provides basic information for using the copier. INTRODUCTION This copier has been designed to provide intuitive operating ease while requiring a minimum amount of space. To get full use of all copier features, be sure to familiarise yourself with this manual and the copier.

  • Page 6: Cautions

    CAUTIONS Follow the cautions below when using this copier. The fusing area is hot. Exercise care in this area when removing misfed paper. Do not look directly at the light source. Doing so may damage your eyes. Do not switch the copier rapidly on and off. After turning the copier off, wait 10 to 15 seconds before turning it back on.

  • Page 7: Main Features

    MAIN FEATURES High-speed laser copying Since warm-up time is zero, copying can be started immediately after the power switch is turned on. First-copy time is only 9.6 seconds (normal mode). Copying speed is 15 copies/min., which adapts to business use, allowing improvement of working efficiency.

  • Page 8: Part Names

    PART NAMES RSPF exit area Original guides Document feeder tray Original table Feeding roller cover Original cover Operation Side cover panel Bypass tray Bypass tray guides Paper tray Handle Cover for optional printer interface Side cover Front cover open button * A printer expansion kit is optional.

  • Page 9: Operation Panel

    OPERATION PANEL Inch system Original to copy key and indicators ON LINE indicator Lights up when the machine is used as a printer. : Two-sided copies from one-sided originals. To use the copier as a printer, an optional printer expansion kit is needed. Turn on Long Edge or Turn on Short Edge can be selected.

  • Page 10: Copier Installation

    COPIER INSTALLATION Improper installation may damage the copier. Please note the following during initial installation and whenever the copier is moved. If the copier is moved from a cool place to a warm place, condensation may form inside the copier. Operation in this condition will cause poor copy quality and malfunctions.

  • Page 11: Cautions On Handling

    COPIER INSTALLATION 20cm (8") 20cm (8") Be sure to allow the required space around the machine for servicing and proper ventilation. 10cm 10cm (4") (4") CAUTIONS ON HANDLING Be careful in handling the copier as follows to maintain the performance of this copier. Do not drop the copier, subject it to shock or strike it against any object.

  • Page 12: Loading Copy Paper

    LOADING COPY PAPER Raise the handle of the paper tray and pull the paper tray out until it stops. Adjust the paper guides on the paper tray to the copy paper width and length. Squeeze the lever of paper guide and slide the guide to match with the width of the paper.
  • Page 13 LOADING COPY PAPER Gently push the paper tray back into the copier. After loading copy paper, to cancel the blinking “P” without restarting copying, press the clear ( ) key. The “P” in the display will go out and the ready ( indicator will light up.

  • Page 14: Making Copies

    MAKING COPIES This chapter describes basic copying functions and some other copying functions using the bypass tray. NORMAL COPYING This copier has two document input stations -reversing single pass feeder (RSPF) for automatic document feeding and an original table for manual handling of documents. The RSPF is designed to hold up to 30 originals measuring from A5 to B4 (5-1/2"...
  • Page 15 NORMAL COPYING Turn the power switch on. The ready ( ) indicator will light up. The copier will enter a power save mode once the set time has elapsed without any copier operation after the last copy of a run is made or power is turned on.
  • Page 16 NORMAL COPYING B. When using the original table: (1) Open the original cover. (2) Place an original face down on the original table. Align it with the original scale and the centring ( ) mark. Close the original cover. Original scale mark When copying a book or an original which has been folded or a crumpled original, press down the original cover lightly.
  • Page 17 NORMAL COPYING D. When copying in the two-sided to one-sided mode: Use the original to copy key to select the two-sided to one-sided copying mode. The originals must have been set in the RSPF in step 3. Ensure that the desired paper tray is selected. Paper sizes that can be used in the duplex mode are letter, legal, and invoice.

  • Page 18: Stream Feeding Mode

    NORMAL COPYING When making two-sided copies from the original table, place the second original on the original table and press the print ( ) key. To cancel two-sided copying after scanning the first original, press the clear ) key. Stream feeding mode The stream feeding mode allows easy operation of continuous copying from the RSPF.

  • Page 19: Reduction/Enlargement/Zoom

    NORMAL COPYING Set the number of copies using the copy quantity ( ) keys and press the print ) key. REDUCTION/ENLARGEMENT/ZOOM Three preset reduction ratios and two enlargement ratios can be selected. The zoom function enables copy ratio selection from 50% to 200% in 1% increments. Set the original and check the copy paper size.

  • Page 20: Bypass Feed (Including Special Paper)

    BYPASS FEED (including special paper) The bypass tray can automatically feed up to 50 sheets of standard copy paper and can also feed special papers such as transparency film and labels one sheet at a time. Copy paper measuring from A6 to A4 (3-1/2" x 5-1/2" to 8-1/2" x 14") and in the weight range of 52 to 130 (14 to 34.5 lbs.) can be used in this tray.
  • Page 21 BYPASS FEED Print face Press the tray select ( ) key to select the bypass tray. Set the number of copies if using standard copy paper. Press the print ( ) key.

  • Page 22: Special Functions

    SPECIAL FUNCTIONS DESCRIPTION OF SPECIAL FUNCTIONS This chapter describes the special functions of this copier. Use these functions as needed. Toner save mode Reduces toner consumption by approximately 10%. Power save modes (page 21) The copier has two power save modes of operation: preheat mode and auto power shut-off mode.

  • Page 23: User Programs (Power Save Modes, Auto Clear Time, Stream Feeding Mode)

    TONER SAVE MODE Press and hold down the exposure mode selector key for approximately 5 seconds. The manual ( ) indicator will go out and the photo ( ) indicator will begin to blink. The exposure indicator marked “5” will light up, indicating the standard toner mode is active.

  • Page 24: Displaying Total Number Of Copies

    USER PROGRAMS Press the print ( ) key. The entered program number will be steadily lit and the currently selected parameter number for the program will blink on the right side of the display. Select the desired parameter using the right copy quantity ( ) key.

  • Page 25: Supplies And User Maintenance

    SUPPLIES AND USER MAINTENANCE This chapter describes how to replace the TD cartridge and the drum cartridge. Be sure to use only genuine SHARP parts and supplies. TD CARTRIDGE REPLACEMENT The TD cartridge replacement required ( ) indicator will light up when toner is needed. If...
  • Page 26 TD CARTRIDGE REPLACEMENT Remove the TD cartridge from the bag. Remove the protective paper. Hold the cartridge on both sides and shake it horizontally four or five times. Hold the tab of the protective cover and pull the tab to your side to remove the cover. 4 or 5 times Gently insert the TD cartridge until it locks in place.

  • Page 27: Drum Cartridge Replacement

    DRUM CARTRIDGE REPLACEMENT The useful life of the drum cartridge is approximately 18,000 copies. When the internal counter reaches approximately 18,000 copies, the drum replacement required ( ) indicator will light up. When the indicator light up, replace the drum cartridge by following the procedure givien below.
  • Page 28 DRUM CARTRIDGE REPLACEMENT Gently install the TD cartridge. To install the TD cartridge, see page 23, TD CARTRIDGE REPLACEMENT. Close the front cover and then the side cover by pressing the round projections near the side cover open button. The drum replacement required ( ) indicator will go out and the ready ( ) indicator will light up.

  • Page 29: User Maintenance

    USER MAINTENANCE Proper care is essential in order to get clean, sharp copies. Be sure to take a few minutes to regularly clean the copier. Before cleaning, be sure to turn the power switch off and remove the power cord from the outlet.

  • Page 30: When Copier Is Not In Use

    USER MAINTENANCE Take the charger cleaner out by holding the tab. Set the charger cleaner onto the right end of the transfer charger, gently slide the cleaner to the left end, and then remove it. Repeat this operation two or three times. Slide the charger cleaner from the right end to the left end along the groove of the transfer charger.

  • Page 31: Copier Trouble

    COPIER TROUBLE? This chapter describes misfeed removal and troubleshooting. MISFEED REMOVAL When the misfeed ( ) indicator blinks or blinks in the display, the copier will stop because of a misfeed. If a misfeed occurs when using the RSPF, a number may appear in the display after a minus sign.

  • Page 32: A Misfeed In The Paper Feed Area

    MISFEED REMOVAL A Misfeed in the paper feed area Gently remove the misfed paper from the paper feed area as shown in the illustration. When blinks in the display and the misfed paper is not seen from the paper feed area, pull out the paper tray and remove the misfed paper.

  • Page 33: C Misfeed In The Transport Area

    MISFEED REMOVAL Do not touch the surface of the drum (green portion) of the drum cartridge when removing the misfed paper. Doing so may cause smudges on copies. Do not remove the misfed paper from above the fusing unit. Unfixed toner on the paper may stain the paper transport area, resulting in smudges on copies.

  • Page 34: D Misfeed In The Rspf

    MISFEED REMOVAL Rotate the feeding roller in the direction of the arrow and gently remove the misfed paper from the exit area. Feeding roller Raise the fusing unit release lever, close the front cover and then close the side cover by pressing the round projections near the side cover open button.
  • Page 35 MISFEED REMOVAL Roller rotating knob With the RSPF, pull out the reversing tray to remove the misfed original. With the RSPF, after removing the misfed original from the exit area, be sure to insert the reversing tray into the exit area until it locks in place. (C) If the original does not move easily into the exit area remove it in the direction of the arrow while rotating the knob.

  • Page 36: Maintenance Required

    MAINTENANCE REQUIRED When indicator lights up, service by an authorised SHARP service technician is required. Contact your SHARP dealer as soon as possible.

  • Page 37: Troubleshooting

    TROUBLESHOOTING If any problem occurs, check the list below before contacting your SHARP dealer. Problem Possible cause Solution page: Copier plugged in? Plug the copier into a grounded outlet. Power switch on? Turn the power switch on. Copier does not Side cover closed Gently close the side cover.

  • Page 38: Status Indicators

    When the following indicators light up or blink on the operation panel or the following alphanumeric codes appear in the display, solve the problem immediately referring to both the table below and the relevant page. Be sure to use only genuine SHARP parts and supplies. Indication Cause and remedy...

  • Page 39: Automatic Exposure Adjustment

    AUTOMATIC EXPOSURE ADJUSTMENT The automatic exposure level can be adjusted to suit your copying needs. This level is set for copying from the original table and copying from the RSPF respectively. When adjusting the automatic exposure level for copying from the RSPF, place an original in the document feeder tray and make sure that the RSPF ( ) indicator lights When adjusting the level for copying from the original table, make sure that no original is left in the document feeder tray.

  • Page 40: Appendix

    APPENDIX SPECIFICATIONS Type Digital laser copier, desk-top type Copy system Dry, electrostatic transfer Originals Sheets, bound documents Original size Max. B4 (257 mm x 364 mm) (10" x 14") ((A5 to B4 for RSPF) (5-1/2" x 8-1/2" to 10" x 14" for RSPF)) Copy sizes A6 to A4 (105 mm x 148.5 mm to 210 mm x 297 mm) (3-1/2"...
  • Page 41 First-copy time may differ depending on operating conditions, such as power-supply voltage and room temperature. As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units.

  • Page 42: Supplies

    Be sure to use only genuine SHARP parts and supplies. For best copying results, be sure to use only SHARP Genuine Supplies which are designed, engineered, and tested to maximize the life and performance of SHARP copiers. Look for the Genuine Supplies label on the toner package.
  • Page 43 SUPPLIES Proper storage 1. Store the supplies in a location that is: clean and dry, at a stable temperature, not exposed to direct sunlight. 2. Store copy paper in the wrapper and lying flat. Paper stored out of the wrapper or in packages standing on end may curl or get damp, resulting in paper misfeeds.

  • Page 44: Optional Equipment

    OPTIONAL EQUIPMENT SYSTEM CONFIGURATION A number of options are available for the copier which allow you to configure a copier system to meet your particular needs. The options include the following. GDI expansion kit (AR-PG1)* PCL expansion kit (AR-PB9)* * This option is not used for the copier operation.

  • Page 45: 250-Sheet Paper Feed Unit (Ar-De9)

    250-SHEET PAPER FEED UNIT (AR-DE9) The paper feed unit provides the convenience of increased paper capacity for the copier and a greater choice of paper sizes readily available for copying. Part names Side cover Tray Loading copy paper The method of loading copy paper for the paper tray of the paper feed unit is the same as for the paper tray in the copier.

  • Page 46: Specifications

    (19.6" (W) x 15.6" (D) x 3.5" (H)) Power supply Drawn from the copier As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units.

  • Page 47: Index

    INDEX Auto clear ....20, 21 Maintenance Automatic exposure adjustment ..37 – user maintenance ....27 Auto power shut-off mode .
  • Page 48 INDEX Ready indicator ....7 TD cartridge Reduction ..... . . 17 –...

  • Page 49: Material Safety Data Sheet

    (Name and Telephone Number) U.S.A. Sharp Electronics Corporation Telephone number for information: 1-800-237-4277 Emergency telephone number: 1-800-255-3924 Canada Sharp Electronics of Canada Ltd. Telephone number for information: 905-890-2100 Emergency telephone number: 1-800-255-3924 United Kingdom Sharp Electronics (U.K.) Ltd. Telephone number for information: 01923-474013 Section 3.
  • Page 50 Section 6. Physical Chemical Characteristics Boiling / Melting Point: Not applicable Specific Gravity: Vapor Pressure: Not applicable Solubility in Water: Negligible Vapor Density: Not applicable Not applicable Evaporation Rate: Not applicable Viscosity: Not applicable Appearance: Fine powder Color: Black Odor: Odorless Section 7.
  • Page 51 (Name and Telephone Number) U.S.A. Sharp Electronics Corporation Telephone number for information: 1-800-237-4277 Emergency telephone number: 1-800-255-3924 Canada Sharp Electronics of Canada Ltd. Telephone number for information: 905-890-2100 Emergency telephone number: 1-800-255-3924 United Kingdom Sharp Electronics (U.K.) Ltd. Telephone number for information: 01923-474013 Section 3.
  • Page 52 Section 6. Physical Chemical Characteristics Boiling / Melting Point: Not applicable Specific Gravity: about 7.3 Vapor Pressure: Not applicable Solubility in Water: Negligible Vapor Density: Not applicable Not applicable Evaporation Rate: Not applicable Viscosity: Not applicable Appearance: Fine powder Color: Black Odor: Odorless...
  • Page 53 MEMO...
  • Page 54 MEMO...
  • Page 55 In some areas, the "POWER" switch positions are marked "I" and " " on the copier instead of "ON" and "OFF". The symbol " " denotes the copier is not completely de-energized but in a stand-by condition at this "POWER" switch position. If your copier is so marked, please read "I"...
  • Page 56 AR-155/AR-155N SHARP CORPORATION 1999 SHARP CORPORATION PRINTED IN CHINA 2000C TINSE0369QSZZ...
