Copyright 1997 Carrier Corporation
Product
Data
SYNERGY 2000
38YDA (60 Hz)
Two-Speed Electric
Heat Pump
Sizes 036, 048, and 060
Model 38YDA Heat Pumps
incorporate innovative 2-speed
compressor technology to provide
quiet, efficient summer cooling and
winter heating performance. Built into
these units are features most desired by
homeowners today, including SEER
ratings up to 16.1 and HSPF of 8.8
when used with the components
designated by the manufacturer. All
models are UL, c-UL, and CSA-EEV
approved. Performance ratings are ARI
and CEC listed.
FEATURES/BENEFITS
Electrical Range — All units are
offered in 208/230v single phase.
Simplified field-stripped lead wire
connections facilitate ease of
installation.
Range of Sizes — Available in
3 nominal sizes 036, 048, and 060 to
meet the needs of residential
applications.
Weather-Armor II Cabinet — Steel
is galvanized and coated with a layer of
zinc phosphate. A coat of modified
polyester powder coating is then
applied and baked on providing each
unit with a hard, smooth finish that will
last for many years.
All screws on the cabinet exterior are
ceramic coated for a long-lasting, rust-
resistant, high-quality appearance.
Unit Design — The coil incorporates
copper tubing and enhanced,
aluminum fins for optimum heat
transfer. Hot condenser air and sound
are discharged vertically and away
from adjacent patio areas and foliage
through the top. Polymer spacers raise
the coil in a deep draw-style basepan
for easy removal of water, dirt, and
debris.
Form 38YDA-3PD
Advertisement
Table of Contents
Related Manuals for Carrier SYNERGY 2000 38YDA
Summary of Contents for Carrier SYNERGY 2000 38YDA
-
Page 1: Heat Pump
Hot condenser air and sound are discharged vertically and away from adjacent patio areas and foliage through the top. Polymer spacers raise the coil in a deep draw-style basepan for easy removal of water, dirt, and debris. Copyright 1997 Carrier Corporation Form 38YDA-3PD... -
Page 2: Model Number Nomenclature
060 — 60,000 Btuh ® CERTIFICATION OF MANUFACTURING SITE. CERTIFICATION APPLIES ONLY WHEN THE COMPLETE SYSTEM IS LISTED WITH ARI. As an ENERGY STAR Partner, Carrier Corporation has determined that this product meets the ENERGY STAR guidelines for energy efficiency. -
Page 3: Physical Data
Carrier Thermostat, Auto Changeover, Non-Programmable, ° F/ ° C, 2-stage heat/2-stage cool in AC mode, TSTATCCN2S01-A 3-stage heat/2 stage cool in HP mode Carrier Thermostat, Auto Changeover, 7-Day Programmable, ° F/ ° C, 2-stage heat/2-stage cool in AC mode, TSTATCCP2S01-A 3-stage heat/ 2-stage cool in HP mode... -
Page 4: Electrical Data
Electrical data MAX FUSE† OPER VOLTS* COMPRESSOR MIN WIRE LENGTH HACR TYPE UNIT SIZE- SIZE (Ft)‡ CKT BKR 60 ° C/75 ° C** 60 ° C/75 ° C** SERIES V/PH AMPS 036-30 90.0 17.6 23.5 12/12 52/50 048-30 208/230/1 120.0 23.6 31.0 8/10... - Page 5 Dimensions ⁄ -IN. DIA VAPOR LINE CONN ⁄ -IN. DIA TIEDOWN KNOCKOUTS (2) PLACES IN BASEPAN FIELD POWER SUPPLY CONN ″ ⁄ ⁄ -IN. DIA HOLE WITH ″ ⁄ ⁄ -IN. DIA KNOCKOUT AIR DISCHARGE AIR IN ″ ⁄ AIR DISCHARGE ⁄...
- Page 6 BUILDING HEAT LOSS, 1000 BTU/HR UNIT INTEGRATED HEATING CAPACITY, 1000 BTU/HR A96084...
- Page 7 Combination ratings SOUND UNIT RATING EVAP AIR CFM COOLING CAPACITY HEATING CAPACITY SIZE- INDOOR SEASONAL SEASONAL High/Low SERIES MODEL High High EFF (SEER) High† EFF (HSPF) (dBA) FK4CNB006* 1100 40,000 22,000 16.10 35,000 20,400 8.80 76/70 F(A,B)4AN(F,B)042 1230 1230 37,400 21,000 12.30 34,000...
-
Page 8: Combination Ratings Continued
Combination ratings continued SOUND UNIT RATING EVAP AIR CFM COOLING CAPACITY HEATING CAPACITY SIZE- INDOOR SEASONAL SEASONAL High/Low SERIES MODEL High High EFF (SEER) High† EFF (HSPF) (dBA) CC5A/CD5A/CD5BW042 1125 37,000 20,800 14.70 33,000 20,400 8.00 76/70 CD5A/CD5BW036 1130 37,000 20,800 14.70 33,000... - Page 9 Combination ratings continued SOUND UNIT RATING EVAP AIR CFM COOLING CAPACITY HEATING CAPACITY SIZE- INDOOR SEASONAL SEASONAL High/Low SERIES MODEL High High EFF (SEER) High† EFF (HSPF) (dBA) COILS + 58U(H,X)V080-16 VARIABLE-SPEED FURNACE CC5A/CD5A/CD5BA060 1505 47,000 26,400 13.00 48,000 25,800 7.70 78/72 CC5A/CD5A/CD5BC048...
- Page 10 Combination ratings continued SOUND UNIT RATING EVAP AIR CFM COOLING CAPACITY HEATING CAPACITY SIZE- INDOOR SEASONAL SEASONAL High/Low SERIES MODEL High High EFF (SEER) High† EFF (HSPF) (dBA) COILS + 58U(H,X)V120-20 VARIABLE-SPEED FURNACE CC5A/CD5A/CD5BA060 1840 1135 53,000 30,000 13.00 53,000 29,000 7.80 80/72...
- Page 11 Detailed cooling capacities* CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† System System System System Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** 38YDA036-30 Outdoor Section in High-Speed With FK4CNB006 Indoor Section 43.6 20.8 3.29...
- Page 12 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† System System System System Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** 38YDA036-30 Outdoor Section in High-Speed With FK4CNB006 Indoor Section continued 43.6 20.8 3.29...
- Page 13 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† System System System System Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** 38YDA036-30 Outdoor Section in Low-Speed With FK4CNB006 Indoor Section 25.4 13.1 1.45...
- Page 14 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† System System System System Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** Total Sens‡ Kw** 38YDA036-30 Outdoor Section in Low-Speed With FK4CNB006 Indoor Section continued 25.4 13.1 1.45...
- Page 15 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† System System System System Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Kw** Kw** Kw** Kw** 38YDA048-30 Outdoor Section in High-Speed With FK4CNB006 Indoor Section 55.5 26.6 4.69...
- Page 16 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† System System System System Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Kw** Kw** Kw** Kw** 38YDA048-30 Outdoor Section in High-Speed With FK4CNB006 Indoor Section continued 55.5 26.6 4.69...
- Page 17 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† System System System System Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Kw** Kw** Kw** Kw** 38YDA048-30 Outdoor Section in Low-Speed With FK4CNB006 Indoor Section 33.0 17.3 1.97...
- Page 18 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† System System System System Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Kw** Kw** Kw** Kw** 38YDA048-30 Outdoor Section in Low-Speed With FK4CNB006 Indoor Section continued 33.0 17.3 1.97...
- Page 19 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† System System System System Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Kw** Kw** Kw** Kw** 38YDA060-30 Outdoor Section in High-Speed With FK4CNB006 Indoor Section 62.6 30.2 5.51...
- Page 20 Detailed cooling capacities* continued CONDENSER ENTERING AIR TEMPERATURES °F EVAPORATOR Capacity Capacity Capacity Capacity Total Total Total Total MBtuh† MBtuh† MBtuh† MBtuh† System System System System Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Kw** Kw** Kw** Kw** 38YDA060-30 Outdoor Section in Low-Speed With FK4CNB006 Indoor Section 36.5 19.6 2.05...
- Page 21 Heat pump heating performance OUTDOOR COIL ENTERING AIR TEMPERATURES °F INDOOR –3 Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total MBtuh MBtuh MBtuh MBtuh MBtuh Power Power Power Power Power Total Integ† Total Integ† Total Integ† Total Integ† Total Integ†...
- Page 22 Heat pump heating performance continued OUTDOOR COIL ENTERING AIR TEMPERATURES °F INDOOR –3 Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total MBtuh MBtuh MBtuh MBtuh MBtuh Power Power Power Power Power Total Integ† Total Integ† Total Integ† Total Integ†...
- Page 23 Heat pump heating performance continued OUTDOOR COIL ENTERING AIR TEMPERATURES °F INDOOR Capacity Capacity Capacity Capacity Total Total Total Total MBtuh MBtuh MBtuh MBtuh Power Power Power Power Total Integ† Total Integ† Total Integ† Total Integ† 38YDA036-30 Outdoor Section in Low-Speed With FK4CNB006 Indoor Section 15.4 13.5 1.33...
- Page 24 Heat pump heating performance continued OUTDOOR COIL ENTERING AIR TEMPERATURES °F INDOOR Capacity Capacity Capacity Capacity Total Total Total Total MBtuh MBtuh MBtuh MBtuh Power Power Power Power Total Integ† Total Integ† Total Integ† Total Integ† 38YDA036-30 Outdoor Section in Low-Speed With FK4CNB006 Indoor Section continued 15.4 13.5 1.33...
- Page 25 Heat pump heating performance continued OUTDOOR COIL ENTERING AIR TEMPERATURES °F INDOOR –3 Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total MBtuh MBtuh MBtuh MBtuh MBtuh Power Power Power Power Power Total Integ† Total Integ† Total Integ† Total Integ†...
- Page 26 Heat pump heating performance continued OUTDOOR COIL ENTERING AIR TEMPERATURES °F INDOOR –3 Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total MBtuh MBtuh MBtuh MBtuh MBtuh Power Power Power Power Power Total Integ† Total Integ† Total Integ† Total Integ†...
- Page 27 Heat pump heating performance continued OUTDOOR COIL ENTERING AIR TEMPERATURES °F INDOOR Capacity Capacity Capacity Capacity Total Total Total Total MBtuh MBtuh MBtuh MBtuh Power Power Power Power Total Integ† Total Integ† Total Integ† Total Integ† 38YDA048-30 Outdoor Section in Low-Speed With FK4CNB006 Indoor Section 21.4 18.4 1.81...
- Page 28 Heat pump heating performance continued OUTDOOR COIL ENTERING AIR TEMPERATURES °F INDOOR Capacity Capacity Capacity Capacity Total Total Total Total MBtuh MBtuh MBtuh MBtuh Power Power Power Power Total Integ† Total Integ† Total Integ† Total Integ† 38YDA048-30 Outdoor Section in Low-Speed With FK4CNB006 Indoor Section continued 21.4 18.4 1.81...
- Page 29 Heat pump heating performance continued OUTDOOR COIL ENTERING AIR TEMPERATURES °F INDOOR –3 Capacity Capacity Capacity Capacity Capacity Total Total Total Total Total MBtuh MBtuh MBtuh MBtuh MBtuh Power Power Power Power Power Total Integ† Total Integ† Total Integ† Total Integ†...
- Page 30 Heat pump heating performance continued OUTDOOR COIL ENTERING AIR TEMPERATURES °F INDOOR Capacity Capacity Capacity Total Total Total MBtuh MBtuh MBtuh Power Power Power Total Integ† Total Integ† Total Integ† 38YDA060-30 Outdoor Section in Low-Speed With FK4CNB006 Indoor Section 1115 28.9 28.9 2.08...
-
Page 31: System Design
Matched system HEAT PUMP COMFORT VENTILATOR COMFORT ZONE II CONTROL CENTER FAN COIL HUMIDIFIER AIR CLEANER A97114 System Design 1. Intended for outdoor installation with free-air inlet and outlet. Outdoor fan external static pressure available is less than 0.01-in. wc. 2. - Page 32 [ ] Packaged Service Training [ ] Classroom Service Training A94328 • Copyright 1997 Carrier Corporation Indianapolis., IN 46231 5-97 Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
