Carrier 58CMA Product Data

Multipoise oil furnace input capacities: 70,000 thru 154,000 btuh series 130
Hide thumbs Also See for 58CMA:
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation, Start-up, and Operating Instructions, User's Information Manual
58CMA
Multipoise Oil Furnace
Input Capacities: 70,000 thru 154,000 Btuh
Series 130
THE LATEST IN OIL FURNACE
TECHNOLOGY
The model 58CMA combines high efficiency and quiet operation
with oil heating technology. The 58CMA is available in 2 sizes.
Each size can be fired at 3 different rates by a simple nozzle and
pump pressure change. Unit 58CMA105 covers input ranges
from 70,000 to 105,000 Btuh. Unit 58CMA120 covers input
ranges from 119,000 to 154,000 Btuh. The furnace design is a
multipoise style for upflow, downflow, and horizontal
applications.
The components of the 58CMA are the finest in the industry. The
unit uses a Beckett oil burner with a "clean- -cut" oil pump, UTEC
ignition controller, and fan cycle timer.
The 58CMA is a standard part of a quality- -built home. This
energy efficient furnace will provide years of quality service to
home builders and homeowners alike.
As with other Carrier furnaces, this model is designed to work as
part of a total home comfort system which includes elements for
cooling, air cleaning, humidification, ventilation, and zoning.
Product Data
58CMA FEATURES/BENEFITS
Beckett Oil Burner and UTEC Controls
S
S
Casing
S
S
Insulation and Soundproofing
S
Combustion Products Venting
S
S
S
A06625
Adjustable Blower Speed
S
Constant Low- -Speed Blower Switch
S
S
S
Combustion Chamber/Heat Exchanger
S
S
S
Certifications
S
S
1
High quality Beckett oil burner allows safe and
efficient combustion of oil.
UTEC ignition control and fan timer board provide
reliable operation and easy connection of thermostat
and accessory wiring.
Made of 20- -gauge, powder- -painted steel for years of
durability and attractiveness.
Cabinet features a reversible door, ensuring ease of
service access even in downflow applications.
Unique silencer baffle, insulated walls and rubber
blower mounts capture most combustion noise and
vibration and make this unit one of the quietest on the
market.
Top or side flue outlet.
Unit may be vented using Type L vent material and a
factory- -built metal or masonry chimney.
Unit may also be sidewall vented with an approved
power venter.
4- -speed blower for precise airflow selection of heating
or cooling operation.
Allows continual low- -speed air circulation through the
home to
maximize comfort while maintaining
efficiency.
Air is constantly filtered and stagnant air is avoided.
This option can be controlled by the homeowner.
Composed mainly of stainless and aluminized steel, the
unique
combination
combustion
exchanger
resists
corrosion,
deterioration.
Heat transfer properties make it energy efficient.
All seams are tightly welded for leak- -free operation.
58CMA unit is CSA certified.
The efficiency is GAMA efficiency rating certified.
chamber/heat
overheating,
and

Advertisement

Table of Contents
loading

Related Manuals for Carrier 58CMA

Summary of Contents for Carrier 58CMA

  • Page 1 Composed mainly of stainless and aluminized steel, the unique combination combustion chamber/heat The components of the 58CMA are the finest in the industry. The exchanger resists corrosion, overheating, unit uses a Beckett oil burner with a “clean- -cut” oil pump, UTEC deterioration.

  • Page 2: Model Number Nomenclature

    LEADS A03172 A97246 A96370 OIL BURNER COMBUSTION CHAMBER/ CONTROL CENTER HEAT EXCHANGER MODEL NUMBER NOMENCLATURE 58CMA Cooling Size Airflow (Nominal 400 CFM per 12,000 Btuh Cooling) Beckett Burner 12 --- 1200 CFM Multipoise Oil Furnace Series Input Capacity 105 --- 70,000 Btuh with 0.50 gph nozzle @ 100 psi 91,000 Btuh with 0.55 gph nozzle @ 140 psi...
  • Page 3 13, 14 SEE NOTES: Left side, right side, or bottom. A97244 1. Heavy- -duty blower circulates air across the heat exchanger to transfer heat into the home. 2. Stainless steel combustion chamber/primary heat exchanger. 3. Unique silencer system reduces combustion noise. 4.

  • Page 4: Clearance To Combustibles

    CLEARANCE TO COMBUSTIBLES UNIT APPLICATION UPFLOW DOWNFLOW HORIZONTAL Furnace SIDES Supply Plenum and Warm--- Air Duct Within 6 Ft of Furnace BACK Furnace Furnace Casing or Plenum Horizontal Warm--- Air Duct Within 6 Ft of Furnace BOTTOM Furnace Horizontally or Below Pipe FLUE PIPE Vertically Above Pipe FRONT...

  • Page 5: Performance Data

    PERFORMANCE DATA UNIT SIZE 105---12 120---20 DIRECT ---DRIVE MOTOR Hp (PSC) MOTOR FULL LOAD AMPS RPM (Nominal) --- SPEEDS 1075--- 4 1075--- 4 BLOWER WHEEL DIAMETER X WIDTH (In.) 10 x 10 12 x 10 FILTER SIZE (In.) --- (Disposable, Field Supplied) 16 x 24 or 25 x 1 20 x 30 x 1 AIR DELIVERY - -CFM (WITH FILTER)
  • Page 6 DIMENSIONS TOP KNOCK-OUT FOR J DIAM VENT 20″ 19″ 3″ KNOCK-OUT BOTH SIDES 19″ FOR J DIAM VENT PULL VENT CONN OIL INLET (BOTH SIDES) 2″ ELECTRICAL CONNECTIONS (BOTH SIDES) .88 DIAM TYP 20″ A98037 DIMENSIONS (IN.) UNIT SIZE 105---12 48--- 3/4 31--- 1/4 16--- 5/8...
  • Page 7 For the ultimate in home com- and humidity level. Especial- often improve comfort and found. Saves decorating and fort, Carrier’s 2, 4, and 8 ---zone ly useful for today’s tighter keeps woodwork, wallpaper, cleaning expenses by keeping systems allow temperature con- constructed houses.

  • Page 8: Typical Installation

    DRAFT DAMPER OIL FURNACE AIR FLOW A98026 Copyright 2009 Carrier Corp. S 7310 W. Morris St. S Indianapolis, IN 46231 Printed in U.S.A. Edition Date: 09/09 Catalog No: 58CMA ---7PD Replaces: 58CMA--- 6PD Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
