MODEL PG8HAA
HORIZONTAL
a
WARNING: If the information in this manual is
not followed exactly, a fire or explosion may
result causing property damage, personal
injury or loss of life.
— Do not store or use gasoline or other flammable va-
pors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
Gas Furnace
USER'S INFORMATION MANUAL
FOR THE OPERATION AND
MAINTENANCE OF YOUR NEW
GAS-FIRED FURNACE
NOTE TO INSTALLER:
THIS MANUAL MUST BE LEFT
WITH THE EQUIPMENT USER.
Advertisement
Table of Contents
Related Manuals for Payne PG8HAA
Summary of Contents for Payne PG8HAA
-
Page 1: Gas Furnace
MAINTENANCE OF YOUR NEW GAS-FIRED FURNACE NOTE TO INSTALLER: THIS MANUAL MUST BE LEFT WITH THE EQUIPMENT USER. MODEL PG8HAA HORIZONTAL WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 2: Welcome To A New Generation Of Comfort
Take a little time now to assure its most efficient operation for years to come. * The output capacity and any representations of efficiency for this furnace are based on standard Department of Energy test procedures. PG8HAA HORIZONTAL FURNACE COMPONENTS (shown in horizontal-left configuration) Primary serpentine heat exchanger. -
Page 3: Important Facts
IMPORTANT FACTS Your furnace must have adequate airflow for efficient combustion and safe ventilation. Do not enclose it in an airtight room or “seal” it behind solid doors. carefully follow these safety To minimize the possibility of serious personal injury, fire, damage to your furnace, or improper operation, rules •... -
Page 4: Steps For Starting Your Furnace
• Read and follow the operating instructions on the furnace, especially the item that reads as follows: STOP! Wait 5 minutes to clear out any gas. Then smell for gas, including near the floor. If you smell gas, Follow “B” in the safety infor- mation above on this furnace label. -
Page 5: Shutting Down Your Furnace
4. Turn the switch on the gas valve to the OFF position and wait 5 minutes. (See Fig. 8.) 5. After waiting 5 minutes, turn the switch on the gas valve to the ON position. (See Fig. 9.) 6. Turn on the electrical supply to the furnace. (See Fig. 10.) 7. -
Page 6: Performing Routine Maintenance
4. Turn the switch on the gas valve to the OFF position. (See Fig. 15.) 5. If the furnace is being shut down because of a malfunction, call your dealer as soon as possible. ® PERFORMING ROUTINE MAINTENANCE With proper maintenance and care, your furnace will operate economically and dependably. Instructions for basic maintenance are found on this and the following pages. -
Page 7: Combustion Area And Vent System
7. Wash the filter (if dirty) in a sink, bathtub, or outside with a garden hose. Always use cold tap water. A mild liquid detergent may be used if necessary. Spray water through the filter in the opposite direction of airflow through the cross-mesh binding side. Allow filter to dry. 8. -
Page 8: A Checkup Checklist
For your convenience, record the product and serial numbers on the form on page 2. Should you ever require service, you will have ready access to the information needed by the service representative. Cancels: OG-PG8H-01 OG-PG8H-02 Catalog No. 53PG-8H6 6-98 —8— © 1998 Payne Heating & Cooling P.O. Box 70, Indianapolis, IN 46206 Printed in U.S.A.
