Husqvarna K 3600 MKII Operator's Manual

Husqvarna concrete ring saw operator's manual.
Operator's manual
K 3600 MKII
Please read the operator's manual carefully and make sure you understand the
E E E E n n n n g g g g l l l l i i i i s s s s h h h h
instructions before using the machine.

   Related Manuals for Husqvarna K 3600 MKII

   Summary of Contents for Husqvarna K 3600 MKII

  • Page 1

    Operator′s manual K 3600 MKII Please read the operator’s manual carefully and make sure you understand the E E E E n n n n g g g g l l l l i i i i s s s s h h h h...

  • Page 2: Key To Symbols

    Key to symbols WARNING! The machine can be a dangerous tool if used incorrectly or carelessly, which can cause serious or fatal injury to the operator or others. Please read the operator’s manual carefully and make sure you understand the instructions before using the machine. Always wear: •...

  • Page 3: Table Of Contents

    Contents KEY TO SYMBOLS Key to symbols ... CONTENTS Contents ... WHAT IS WHAT? What is what on the power cutter? ... SAFETY INSTRUCTIONS Steps before using a new power cutter..Personal protective equipment ... Machine′s safety equipment ... Checking, maintaining and servicing the machine′s safety equipment ...

  • Page 4: What Is What On The Power Cutter

    What is what on the power cutter? 1 Diamond blade 2 Blade guard/spray guard 3 Hydraulic motor 4 Locking button for the drive wheel 5 Grease nipples 6 Control for the guide rollers 7 Front handle (adjustable) 8 Water adjustment control 9 Switch 10 Water connector 11 Couplings for hydraulic hoses...

  • Page 5: Steps Before Using A New Power Cutter, Personal Protective Equipment, Machine's Safety Equipment

    Please read the operator’s manual carefully. • Check the cutting blade’s mounting, see the chapter ”Assembly”. Let your Husqvarna dealer check the power cutter and make essential adjustments and repairs. WARNING! Under no circumstances may the design of the machine be modified without the permission of the manufacturer.

  • Page 6: Checking, Maintaining And Servicing The Machine's Safety Equipment

    SAFETY INSTRUCTIONS Switch lock and ON/OFF valve for the water The switch lock is designed to prevent accidental operation of the switch. The ON/OFF valve for the water supply is also controlled with the switch lock. When the switch lock (A) is pressed in this opens the water valve and releases the switch (B).

  • Page 7: General Safety Precautions, General Working Instructions

    SAFETY INSTRUCTIONS Checking the blade guard WARNING! Always check that the guard is correctly fitted before starting the machine. Also check that the blade is fitted correctly and is not damaged in anyway. A damaged blade can cause personal injuries. See instructions under the heading Assembly.

  • Page 8

    This means the water disc can penetrate into the workpiece and help control the machine. Attempting to saw the entire depth in one run takes longer. Working with several runs, 3 to 4 when the cut is 260 mm (10...

  • Page 9

    SAFETY INSTRUCTIONS Large work Cuts exceeding 1 m - secure a batten along the line to be cut. The batten acts as a guide. Use this guide to make a marking cut along the entire length of the cut, 50-70 mm (2-3 inches) in depth.

  • Page 10

    SAFETY INSTRUCTIONS • Be alert to movement of the work piece or anything else that can occur, which could cause the cut to close and pinch the blade. WARNING! Cutting plastics with a diamond blade can cause kickback when the material melts due to the heat produced when cutting and sticks to the blade.

  • Page 11: Drive, Fitting The Blade

    Unexpected blade movements can cause serious injuries. We offers a number of blades for different materials in its range. Check with your Husqvarna dealer to see which blades are best suited for your usage. WARNING! It is forbidden to reconstruct a used blade.

  • Page 12

    SETTINGS AND ADJUSTMENTS • Loosen the knob to offload the springs. • Pull out the lock for the front handle and move the handle to the service position. • Remove the three screws holding the support roller guard using a 6 mm hex key and lift off the cover. •...

  • Page 13: Hydraulic Hoses, Water Hose, Water Supply, Water Dosage

    SETTINGS AND ADJUSTMENTS CAUTION! The machine should be upright. If the machine lies on its side the weight of the blade makes it difficult to make a correct adjustment. • Tighten the knobs fully and the machine is ready to use. Hydraulic hoses WARNING! The power cutter must not be connected to a hydraulic pressure...

  • Page 14: Starting And Stopping

    STARTING AND STOPPING Starting and stopping WARNING! Note the following before starting: Make sure you are standing properly and that the blade can not come into contact with anything. Keep people and animals well away from the working area. Check that the power source (the hydraulic unit) supplies the correct oil flow and oil pressure.

  • Page 15: Maintenance, Dismantling The Complete Guide Roller, Assembling The Complete Guide Roller

    Maintenance WARNING! Inspection and/or maintenance should be carried out with the hydraulic hoses disconnected. Dismantling the complete guide roller • Remove the support roller cover. • Lift off the blade. • Unscrew the knob. First turn the knob a few turns until you feel a resistance.

  • Page 16: Drive Wheel, Replacing The Support Rollers/guide Rollers

    Drive wheel 1 Lock the axle using the locking button. See the instructions under the heading What is what?. 2 Loosen the centre screw and remove the washer. You can now lift off the drive wheel. CAUTION! Replace the drive wheel when fitting a new blade. A worn drive wheel can result in the blade slipping and becoming damaged.

  • Page 17: Reconstructing The Blade, Couplings, Hydraulic Hoses

    A shattered blade can cause serious personal injuries to the user or other persons. For this reason Husqvarna does not approve ring cutting blades that have been reconstructed. Contact your Husqvarna dealer for instructions.

  • Page 18: Maintenance Schedule, Blades Conforming To En13236

    Check that the controls work. Blade Check the condition of the blade guard. Check the water disc. Blades conforming to EN13236 Husqvarna K3600 MKII only conforms to 98/37/EC and EN13236 together with the blades listed below: Type Diameter, mm Husqvarna PXR XX...

  • Page 19: Mechanics

    Mechanics Symptom Probable cause The blade does not rotate. Roller knobs not tightened fully. The blade not fitted on guide rollers correctly. Rollers tensioned too much. Possible faulty hose connection to the hydraulic system. Possible faulty hose connection to the drive source or other hydraulic problem. The blade rotates too slowly.

  • Page 20: Extending The Hydraulic Hoses

    Technical data Blade diameter, mm/inches Cutting depth, mm/inches Max. peripheral speed, m/s / r/min Max.motor speed, r/min Hydraulic motor Max. hydraulic pressure, bar/ (psi) Oil flow, min-max, l/min Height, mm/inches Length, mm/inches Width, mm/inches Weight, excl. blade, kg Weight ring blade, kg Specifications hydraulic oil* Oil temperature (operational), °C Water consumption, l/min...

  • Page 21: Ec-declaration Of Conformity

    Husqvarna AB, SE-433 81 Göteborg, Sweden, tel: +46-31-949000, declares under sole responsibility that the power cutter Husqvarna K 3600 dating from 2010 serial numbers and onwards (the year is clearly stated on the rating plate, followed by the serial number), complies with the requirements of the COUNCILíS DIRECTIVE: •...

  • Page 22

    ´®z+UBT¶6A¨ ´®z+UBT¶6A¨...

  • Page 24

    Original instructions 1153345-26 ´®z+UBT¶6A¨ ´®z+UBT¶6A¨ 2010-01-13...
