- Page 1 115 44 10-38 (107) OWNER’S MANUAL BRUSHCUTTERS BC4350FW Caution • Before using our brushcutter, please read this manual carefully to understand the proper use of your unit. • Keep this manual handy.
-
Page 2: Table Of Contents
Contents SAFETY FIRST 1. Warning labels on the machine ………2 Instructions contained in warnings within this manual 2. Symbols on the machine ………………3 marked with a symbol concern critical points which 3. Specifications ……………………………3 must be taken into consideration to prevent possible serious 4. -
Page 3: Symbols On The Machine
Position: FUEL TANK CAP (b) The direction to close the choke Position: AIR CLEANER COVER (c) The direction to open the choke Position: AIR CLEANER COVER 3. Specifications MODEL CODE Unit BC4350FW Overall size Length 1845 Width Height Dry weight ✽... -
Page 4: Safety Precautions
4. Safety precautions 2. Never use the product, 1. Read this manual carefully until you (1) When the ground is slippery or when completely understand and follow all you can’t maintain a steady posture. safety and operating instructions. (2) At night, at times of heavy fog, or at 2. - Page 5 ZENOAH 2. Check the condition of working area to servicing dealer for repair. avoid any accident by hitting hidden obstacles such as stumps, stones, ■...
- Page 6 4. Safety precautions ■ HANDLING FUEL serious burns or electrical shock. 1. The engine of the ZENOAH product is ■ IF SOMEONE COMES designed to run on a mixed fuel, which 1. Guard against hazardous situations at contains highly flammable gasoline.
- Page 7 4. Safety precautions This contact causes the blade to stop for an instant and then suddenly move or ”bounce” away from the object that was hit. The operator can lose control of the unit and the blade can cause serious personal injury to the operator or any person nearby if the blade contacts any part of the body.
-
Page 8: Set Up
5. Set up ■ ENGINE ■ INSTALLING BLADE • Using attached 4 socket screws, secure the Remove the guard skirt of debris guard, when using connection firmly with equal force. metal blade. 1. Put the angled bar(1) into the side holes of the inner holder and the gearcase. -
Page 9: Fuel
Mixing ratios: When using Zenoah genuine 2-cycle oil (FC grade): 50:1 (100 ml of oil for every 5 liters of gasoline) When using commercially available 2-cycle oil (FB... -
Page 10: Operation
7. Operation ■ STARTING ENGINE WARNING WARNING The product is equipped with a centrifugal clutch mechanism, so the cutting attachment begins to The cutting head will start rotating upon the engine rotate as soon as the engine is started by putting starts. - Page 11 ■ ADJUSTING THROTTLE CABLE according to the object to be cut. Never use other • The normal play is 1 or 2 mm when measured at the cutting attachment not approved by ZENOAH. carburetor side end. Readjust with the cable adjuster as required.
-
Page 12: Maintenance
Starting failure and misfiring are often caused by a fouled spark plug. Clean the spark plug and check that the plug gap is in the correct range. For a replacement plug, use the correct type specified by ZENOAH. REPLACEMENT PLUG IS A CHAMPION RCJ6Y. - Page 13 8. Maintenance ■ INTAKE AIR COOLING VENT ■ MUFFLER WARNING WARNING • Never touch the cylinder, muffler, or spark plugs • Inspect periodically, the muffler for loose with your bare hands immediately after stopping fasteners, any damage or corrosion. If any sign of the engine.
-
Page 14: Trouble Shooting
• When the symptoms in the left column do not improve after taking the measures in the right column, please contact the shop where you bought this product. • For the measures marked with ✩, please buy ZENOAH’s genuine parts at the shop where you bought this product. WARNING •... -
Page 15: Limited Warranty
AND MAINTENANCE OF THE UNITS ACCIDENT warranty period, the failed part will be replaced or MISHANDLING, ALTERATION, ABUSE, IMPROPER repaired free of charge by a ZENOAH authorized LUBRICATION, USE OF ANY PARTS OR dealer. ACCESSORIES OTHER THAN THOSE SPECIFIED BY...
