1. Use KOMATSU ZENOAH genuine parts as specified in the parts list for repair and/or replacement. 2. KOMATSU ZENOAH does not warrant the machines, which have been damaged by the use of any parts other than those specified by the company.
Page 13
Fig.6 ENGINE GROUP Key# PART NUMBER DESCRIPTION 4500-12110 CYLINDER 1850-12130 BOLT 4500-13120 GASKET, base 4500-21101 CRANKCASE COMP. 2629-21130 • PIN 4500-21140 GASKET, case 06030-06201 BEARING 4810-21210 OIL SEAL 1650-21220 OIL SEAL 01252-30530 BOLT 04065-03212 SNAP RING 4500-41110 PISTON 1400-41220 RING 2850-41310 1300-41320 RING...
