Summary of Contents for Zenoah BC4301FW
- Page 1 115 79 80-26 (1511) OWNER’S MANUAL BRUSH CUTTERS WARNING BC4301FW • Before using our products, please read this manual carefully to understand the proper use of your unit. Original Language • Keep this manual handy.
-
Page 3: Table Of Contents
Contents SAFETY FIRST 1. Warning labels on the machine ………3 Instructions contained in warnings within this manual 2. Symbols on the machine ………………4 marked with a symbol concern critical points which 3. Specifications ……………………………4 must be taken into consideration to prevent possible serious 4. -
Page 4: Symbols On The Machine
Position: FUEL TANK CAP (b) The direction to close the choke Position: AIR CLEANER COVER (c) The direction to open the choke Position: AIR CLEANER COVER 3. Specifications MODEL CODE Unit BC4301FW Overall size Length 1720 (❈1) Width Height Dry weight 7.4 (❈1) -
Page 5: Safety Precautions
4. Safety precautions 2. Never use the product, 1. Read this manual carefully until you (1) When the ground is slippery or when completely understand and follow all you can’t maintain a steady posture. safety and operating instructions. (2) At night, at times of heavy fog, or at 2. - Page 6 ZENOAH 2. Check the condition of working area to servicing dealer for repair. avoid any accident by hitting hidden obstacles such as stumps, stones, ■...
- Page 7 4. Safety precautions ■ HANDLING FUEL serious burns or electrical shock. 1. The engine of the ZENOAH product is ■ IF SOMEONE COMES designed to run on a mixed fuel, which 1. Guard against hazardous situations at contains highly flammable gasoline.
- Page 8 4. Safety precautions This contact causes the blade to stop for an instant and then suddenly move or ”bounce” away from the object that was hit. The operator can lose control of the unit and the blade can cause serious personal injury to the operator or any person nearby if the blade contacts any part of the body.
-
Page 9: Set Up
5. Set up ■ ENGINE and MAIN PIPE 1. Hook the cable end into the hole of the throttle lever. Align the hanger and the fuel tank, using attached 4 And set the cable in the lever as shown in the picture. socket screws, secure the connection firmly with equal (F4) force. - Page 10 5. Set up ■ INSTALLING THE ANTI-CAUGHT UP COVER FOR ■ INSTALLING THE METAL BLADE (OPTION) (F9) METAL BLADE (F7) 1. Set the inner holder to the gear shaft, and turn to fix 1. Match the inside ditch of the anti-caught up cover to with the attached L-shaped bar.
-
Page 11: Fuel
Mixing ratios: When using Zenoah genuine 2-cycle oil (FC grade): 50:1 (100 ml of oil for every 5 liters of gasoline) When using commercially available 2-cycle oil (FB... -
Page 12: Operation
7. Operation ■ STARTING THE ENGINE NOTE WARNING When restarting immediately after stopping the engine, move the throttle lever to the idling position. • Before starting the engine, inspect the entire unit for loose fittings or fuel leaks, and the cutting 5. - Page 13 7. Operation ■ HOW TO OPERATE EMERGENCY UNBUCKLING KNOB IMPORTANT In case of getting the body away from the machine immediately in emergency, pull up the red knob on the Operating at low speed makes it easier for grass, top of the hanging part. You can be separated from the weeds, or twigs to become caught up in the blades, and machine with the shawl band equipped.
-
Page 14: Maintenance
8. Maintenance ■ REFILLING TRIMMING LINE 5. Hook each end of the line in the slot on the edge of For safety reasons, do not use metalreinforced line. the cord holder. (F21) 1. For replacement line, use a diameter of .095 in (2.4 mm). - Page 15 (3) Screen (4) Body When replacing spark plug, use only products which IMPORTANT have been designated by ZENOAH. A clogged air filter may increase fuel consumption while ■ INTAKE AIR COOLING VENT cutting down the engine power. And operate the brushcutter without the air filter or with •...
- Page 16 8. Maintenance IMPORTANT (1) Float cabin • Note that failing to do so could cause the muffler to become overheated, and that this in turn could cause the brushcutter to catch on fire. ■ GEAR CASE Supply multi-purpose grease at every 25 hours of use. Remove the cutter holders to arrange for old grease to exit.
-
Page 17: Storage
• When the symptoms in the left column do not improve after taking the measures in the right column, please contact the shop where you bought this product. • For the measures marked with ✩, please buy ZENOAH’s genuine parts at the shop where you bought this product. WARNING •... - Page 18 AND MAINTENANCE OF THE UNITS ACCIDENT warranty period, the failed part will be replaced or MISHANDLING, ALTERATION, ABUSE, IMPROPER repaired free of charge by a ZENOAH authorized LUBRICATION, USE OF ANY PARTS OR dealer. ACCESSORIES OTHER THAN THOSE SPECIFIED BY...
- Page 20 To Dealer: Please complete the following form at time of sale. Equipment No.: Product Model: ZENOAH BC4301FW Engine No.: Date of Purchase: D / M / Y Use: Private Professional Rental Name: Purchaser: Address/Phone: Name: Dealer: Address/Phone: To Purchaser: When your unit requires any repair, please bring or send it to the dealer with this sheet attached.
