813 VKR/CHIN/DIP GYM SYSTEM
CLASS H
PART # 7303601
REV. A
USER'S GUIDE
1
WARNING:
Read and follow all directions
for each step to insure proper
assembly of this product.
Version: 813108
Revision: 06/18/02

Advertisement

Table of Contents
loading

Related Manuals for ParaBody 813

Summary of Contents for ParaBody 813

  • Page 1 813 VKR/CHIN/DIP GYM SYSTEM WARNING: Read and follow all directions for each step to insure proper assembly of this product. USER’S GUIDE CLASS H Version: 813108 PART # 7303601 Revision: 06/18/02 REV. A...

  • Page 2: Important Safety Information

    Supervise teenagers. unsure, call your authorized ParaBody dealer. NOTE: In a continual effort to improve our products, specifications are subject to change 2001 Life Fitness, a division of Brunswick Corporation. All rights reserved. © ParaBody is a trademark of Brunswick Corporation...

  • Page 3: Important Notes

    IMPORTANT NOTES Please note: * Thank you for purchasing the ParaBody 813 Gym System. Please read these instructions thoroughly and keep them for future reference. This product must be assembled on a flat, level surface to assure its proper function.
  • Page 4 1’ 2’ 4’ 5’ 6’ 7’ 3’ 1’ 2’ 3’ 4’ 5’ 1 Square = 1’ X 1’...

  • Page 5: Parts List

    PARTS LIST DESCRIPTION PART # PART # DESCRIPTION 6102309 3/8” LOCK NUT 3114702 BASE CONNECTOR 6480009 3/8 X 3” BOLT 3235212 CHIN BAR 6480509 1-1/4 X 5” GRIP 3103101 VKR SIDE 6480909 1-1/4 X 7” GRIP 3103103 UPPER BACK SUPPORT 6665921 1-3/4”...
  • Page 6 10 3/8 X 3” 10 3/8 X 3” FIGURE 2 STEP 2: • LOOSELY assemble the UPPER BACK SUPPORT (4) to the VKR SIDES (3) using four 3/8 X 3” BOLTS (10), eight 3/8” FLAT WASHERS (7), and four 3/8” LOCK NUTS (9) as shown in FIGURE 2. •...
  • Page 7 10 3/8 X 3” FIGURE 3 STEP 3: • LOOSELY assemble the CHIN BAR (2) to the VKR SIDES (3) using two 3/8 X 3” BOLTS (10), four 3/8” FLAT WASHERS (7), and two 3/8” LOCK NUTS (9). • SECURELY tigten all connections made up to this point.
  • Page 8 3/8 X 3” 10 FIGURE 4 STEP 4: • SECURELY attach two ARM PADS (6) to the VKR SIDES (3) using four 3/8 X 3” BOLTS (10), four 3/8” LOCK WASHERS (8), and four 3/8” FLAT WASHERS (7) as shown in FIGURE 4. (NOTE: Place the high side of ARM PAD toward the outside.)
  • Page 9 3/8 X 3” FIGURE 5 STEP 5: • SECURELY assemble the BACK PAD (5) to the UPPER BACK SUPPORT (4) using two 3/8 X 3” BOLTS (10), two 3/8” LOCK WASHERS (8), two 3/8” FLAT WASHERS (7) as shown in FIGURE 5.
  • Page 10 FIGURE 6 STEP 6: • Slide six 1-1/4 X 7” HANDLES (12) over the HANDLES of the VKR SIDES (3) and the CHIN BAR (2) as shown in FIGURE 6. • Slide two 1-1/4 X 5” HANDLES (11) over the ARM PAD HANDLES of the VKR SIDES (3) as shown in FIGURE 6.

  • Page 11: Maintenance

    YOU MAY NEED SERVICE YOU WILL BE ASKED FOR THIS INFORMATION. REMEMBER TO FILL OUT YOUR WARRANTY REGISTRATION CARD AND MAIL BACK. MODEL #________________________ SERIAL #_________________________ DATE OF PURCHASE: _____________ DEALERS NAME: _________________ DEALERS PHONE #_______________ SERAIL NUMBER Thank you for purchasing the ParaBody 813 Gym System.

  • Page 12: Limited Warranty

    LIMITED WARRANTY ParaBody extends the following LIMITED WARRANTY to the original owner of the ParaBody products. The Warranty terms apply to IN HOME USE ONLY. 1. LIMITED WARRANTY ON FRAME AND WELDS. If the frame of the ParaBody product or a weld should crack or break, it will be repaired or replaced by ParaBody.
  • Page 13 Phone: 39 (472) 835-470 Phone: 81 (3) 3359-4309 Fax: 39 (472) 833-150 Fax: 81 (3) 3359-4307 Life Fitness Do Brazil Life Fitness Asia Pacific Limited Al. Rio Negro, 433-Predio 2-Sala 2 Room 2610, Miramar Tower andar (Confab) º 132 Nathan Road, Tsimshatsui...
