RCA RCR6473R Owner's Manual

RCR6473R
Universal Remote Control
Owner's Manual
Manual del Propietario (parte posterior)
FCC Statement:
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any Changes or modifi cations not expressly approved by the
party responsible for compliance could void the user's authority to
operate this equipment.
Industry Canada Regulatory Information
This class B digital apparatus complies with Canadian ICES-003
Avis d'Industrie Canada
Cet appareil numérique de la classe B est conforme a la nome
NMB-003du Canada
Step 1: Install your batteries
Your universal remote requires two AAA alkaline batteries (not
included).
To install the batteries:
1.
Remove the battery
compartment cover.
2.
Insert the batteries, matching
the (+) and (–) marks inside the
battery compartment.
3.
Push the battery cover back into
place.
Battery Precautions:
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc) or
rechargeable (nickel-cadmium) batteries.
• Always remove old, weak or worn-out batteries promptly
and recycle or dispose of them in accordance with Local
and National Regulations.

Battery Saver

Your universal remote control saves battery power by
automatically turning off if any key is pressed for more than
60 seconds. This saves your battery life should your remote
get stuck in a place where the keys remain depressed, such as
between sofa cushions.
Step 2: Program your remote
To use this universal remote with your home entertainment
system, fi rst you need to program it to control your devices.
There are four ways you can program the universal remote to
operate your devices:
• The Auto Code Search goes automatically through all the
codes for the device you're trying to control. It's the easiest
method, but it can sometimes take longer than some of the
other programming methods.
• The Brand Code Search searches through the codes for
select brands of devices. It's not as easy as the auto code
search, but it can be faster.
• The Direct Code Entry lets you enter a code from the
accompanying code list for your brand of device. It's not as
easy as the other methods, but it's potentially the fastest
method.
• The Manual Code Search lets you manually go through
all the codes for the device you're trying to

Auto Code Search

The Auto Code Search goes automatically through all the
codes for the device you're trying to control. When you fi nd
the one that operates your device, you can stop the search and
store that code.
TIPS: Each device key is associated with a type of device—
the TV is preset to search for TVs, SAT•CBL•STRM
satellite receivers, digital TV converters,
or cable boxes, DVD for DVD players, and DVR•AUX1 for
DVRs, AUDIO for audio receivers, and VCR•AUX2 for VCRs.
To program a device key for a different type of device, see
the Reassigning the DVR•AUX1 and VCR•AUX2 Keys section.
To control combo devices, like TV/DVDs and TV/VCRs, you
need to program each key separately. Each key will control
that part of the combo device.
If the original remote control that came with your device has
separate ON and OFF keys (instead of a single POWER key),
the Auto Code Search might not work with that device. Try
the Direct Code Entry method described later in this manual.
To exit without saving a new code at any point in the Auto
Code Search, press the CLEAR key.
Note: To program for a DVD player, you must fi rst press and
hold the DVD key. While you're holding the DVD key, press
the number 3 key. Then release both keys.
1.
Manually turn on the device you
want to control.
2.
Press and hold the device key you want to program. While
you're holding down the device key, use your other hand
to press and hold the remote's POWER key at the same
time.
3.
Wait until the remote's indicator
LED comes on and stays on.
Then release both keys.
4.
Point the remote directly at the
front panel of the device you
want to control. Press
the remote and wait 5 seconds.
The remote is testing a batch of
10 codes on your device.
Did your device turn off?
YES: Go to step 5.
NO: Press
10 codes.
Keep pressing
turns off.
5.
When your device turns off, press
the SKIP BACK
and wait at least 2 seconds.
The remote tries the last of the
previous ten codes.
control.
Did your device turn on?
YES: Press the
done! You've programmed this
device key.
NO: Press
code in the batch.
Keep pressing
device turns back on. When it does, press OK.
Note: If you accidentally press the
for
device turns on, press the
streaming players,
seconds to see if your device turns off again.
NOTES
Throughout the programming of each key, be sure to keep
the remote pointed at the IR sensor of the device you are
currently programming the remote to control.
Test the remote with the device to make sure the
device key is programmed with the correct code for
maximum functionality. If some features don't work, try
a different code. See the "Testing the Code for Maximum
Functionality" section below for more information.
During the Auto Code Search, the remote ignores
keypresses that aren't part of the search.
The search times out after two minutes (the LED blinks four
times and turns off, and the last programmed code under
that device key is retained).
The indicator light blinks four times and turns off when the
remote has gone through all the codes. The remote exits
the Auto Code Search. If your device hasn't turned off yet,
try a different search method.
Testing the Code for Maximum Functionality
1. Try a variety of the device's functions with the remote. If
some device features don't work, go to the next step to try
a different code.
2. Repeat the Auto Code Search Method from the beginning.
When your device turns off, do not stop searching.
Instead, with the unit now off, continue to press the
key every 5 seconds until the unit turns back on.
3. Once the unit turns back on, press the
the remote every 2 seconds until your device turns off
again. When your device turns off again, press the
4. Test the key's functionality again by attempting to control
a variety of the device's functions. If the code that has
been stored controls the majority of the device's functions,
programming is complete. If the code stored does not give
maximum functionality, try another code.
SLOW on
SLOW again. The remote tests the next batch of
SLOW every 5 seconds until your device
key on the remote
OK key. You're
SKIP BACK again. The remote tests the next
SKIP BACK every 2 seconds until your
SKIP BACK key after your
SKIP FWD key. Then, wait two
SKIP BACK key on
OK
Bra
The
the s
bran
TIP
the
rece
box
AU
pro
Rea
To c
nee
tha
If th
sep
the
the
To e
Cod
No
hol
the
1.
2.
3.
4.
5.
Not
exa
6.
SLOW
key.
