For Your Records and
Warranty Assistance
For reference, also attach your receipt or a copy
of your receipt to the manual.
Vancouver
__________________________________________
Model Name
21321, 21328
__________________________________________
Model No.
__________________________________________
Date Purchased
__________________________________________
Where Purchased
Form# 42856-01
20090130
©2009 Hunter Fan Co.
Type A Models
Type A Models
Type A Models
Owner's Guide and Installation Manual
Advertisement
Table of Contents
Related Manuals for Hunter 42856-01
Summary of Contents for Hunter 42856-01
- Page 1 Vancouver __________________________________________ Model Name 21321, 21328 __________________________________________ Model No. __________________________________________ Date Purchased __________________________________________ Where Purchased Form# 42856-01 20090130 ©2009 Hunter Fan Co. Type A Models Type A Models Type A Models Owner’s Guide and Installation Manual...
-
Page 2: Table Of Contents
4 • Wiring the Fan . . . . . . . . . . . . . . . . . . - Page 3 To install and use the accessories, follow the instructions included with each product. For quiet and optimum performance of your Hunter fan, use only Hunter speed controls. CAUTION: To reduce the risk of personal injury, attach the fan directly...
-
Page 4: Getting Ready
• Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: •... -
Page 5: Installing The Hanger Bracket
Tighten the screws into the 9/64” pilot holes; do not use lubricants on the screws. Do not over tighten. Flat Washer 42856-01 • 01/30/09 • Hunter Fan Company Ceiling Plate 3” Wood Screw Steps 2-4 – 2-6... -
Page 6: Assembling And Hanging The Fan
WARNING: Fan may fall if not assembled as directed in these installation instructions. 3-1. Lift the motor assembly and hook the three tabs over the handles, one at a time. Handle Step 3-1 42856-01 • 01/30/09 • Hunter Fan Company... -
Page 7: Wiring The Fan
4-7. Spread the wires apart, with the grounded wires on one side of the outlet box and the ungrounded wires on the other side of the outlet box. 42856-01 • 01/30/09 • Hunter Fan Company... -
Page 8: Installing The Motor Housing
5-3. Align the holes in the fan housing with the holes in the ceiling plate. 5-4. Partially install each canopy screw into the holes in the fan housing and into the ceiling plate until all holes are aligned. -
Page 9: Assembling The Blades
Hunter fans use several styles of fan blade irons (brackets that hold the blade to the fan). 6-1. Your fan may include blade grommets. If your fan has grommets, insert them by hand into the holes on the blades. 6-2. Attach each blade to a blade iron using three blade assembly screws. -
Page 10: Completing Your Installation With Or Without A Bowl Light Fixture
7 • Completing Your Installation With or Without a Bowl Light Fixture Your Hunter fan comes with an integrated light fixture assembly and an optional switch housing cap and plug button. This feature gives you the option of installing the fan with OR without the included light fixture. - Page 11 Align the side screw holes in the upper and lower switch housings. Attach the lower switch housing to the upper switch housing with three housing assembly screws. 42856-01 • 01/30/09 • Hunter Fan Company Steps 7-6 – 7-7 Lower Switch...
- Page 12 (You may find the plastic breakaway connector on the end of the extra chain.) 7-11. Thread the fan pull chain through the hole in the metal disc. Then, thread the fan pull chain through the hole in the center of the glass bowl.
- Page 13 7-23. Once you have uninstalled the light fixture, continue with step 7-6 Male Dummy Terminal Female Dummy Terminal 42856-01 • 01/30/09 • Hunter Fan Company Lower Switch Housing Threaded Rod Steps 7-17 – 7-20 Plug Button Step 7-22...
-
Page 14: Fan
8 • Operating and Cleaning Your Ceiling Fan 8-1. Turn on electrical power to the fan. 8-2. The fan pull chain controls power to the fan. The pull chain has four settings in sequence: High, Medium, Low and Off. • Pull the chain slowly to change settings. -
Page 15: Troubleshooting
Problem: Lights dim when turned on or do not turn on 1. Check to make sure wattage of light bulbs installed match the specifications on the light socket. 42856-01 • 01/30/09 • Hunter Fan Company 9 • Troubleshooting If you need parts or service assistance, please call 888-830-1326 or visit us at our Web site at http://www.hunterfan.com.
