Operating instructions
EN
English,1
LFF 8M5
Contents
Disposal
Installation, 4-5
Loading the racks, 7-8
Adjusting upper rack
Cutlery Tray*
Wash cycles, 10
Table of wash cycles
Shutting off the water and electricity supplies
Cleaning the dishwasher
Preventing unpleasant odours
Cleaning the sprayer arms
Cleaning the water inlet filter
Troubleshooting, 14
Assistance, 15
DISHWASHER
EN
1
Advertisement
Table of Contents
Related Manuals for Ariston LFF 8M5
Summary of Contents for Ariston LFF 8M5
-
Page 1: Table Of Contents
Advice regarding the first wash cycle Technical data Description of the appliance, 6 Overall view Control panel Loading the racks, 7-8 Lower rack LFF 8M5 Cutlery basket Upper rack Adjusting upper rack Cutlery Tray* Start-up and use, 9 Starting the dishwasher... -
Page 2: Precautions And Advice
Precautions and advice a dangerous obstacle. T h i s a p p l i a n c e w a s d e s i g n e d a n d • Keep detergent and rinse aid out of reach of manufactured in compliance with international children. - Page 3 Phosphate-free and chlorine-free detergents containing enzymes • We strongly recommend that you use detergents that do not contain phosphates or chlorine, as these products are harmful to the environment. • Enzymes provide a particularly effective action at temperatures around 50°C. As a result detergents containing enzymes can be used in conjunction with low-temperature wash cycles in order to achieve the same results as a normal 65°C wash cycle.
-
Page 4: Installation
Installation The hose should not be bent or compressed. If the appliance must be moved at any time, keep it in an upright position; if absolutely necessary, it may be tilted onto its Connecting the water outlet hose back. Connect the outlet hose (without bending it) to a drain duct with a minimum diameter of 4 cm. -
Page 5: Advice Regarding The First Wash Cycle
Anti-condensation strip (depending on the The machine has a buzzer/set of tones After installing the dishwasher, open the door and stick the dishwasher model ) to inform the user that a command has adhesive transparent strip under the wooden shelf in order been implemented: power on, cycle end etc. -
Page 6: Description Of The Appliance
Description of the appliance Overall view Upper rack Upper sprayer arm Tip-up dispensers Rack height adjuster Lower rack Lower sprayer arm Cutlery basket Washing filter Salt dispenser Detergent and rinse-aid dispensers Data plate **** Control panel Control panel Half load button Time remaining and indicator light light-up display Low salt... -
Page 7: Loading The Racks
Loading the racks Tips Several dishwasher models are fitted with tip-up sectors Before loading the racks, remove all food residues from the They can be used in a vertical position when arranging dishes crockery and empty liquids from glasses and containers. No or in a horizontal position (lower) to load pans and salad bowls preventive rinsing is needed under running water. - Page 8 Adjustable position tip-up compartments Unsuitable crockery The tip-up compartments can be positioned at different heights, to • Wooden crockery and cutlery. optimise the arrangement of crockery throughout the rack. Wine • Delicate decorated glasses, artistic handicraft and antique glasses can be placed safely in the tip-up compartments, by crockery. Their decorations are not resistant. inserting the stem of each glass into the corresponding slots. • Parts in synthetic material which do not withstand high temperatures.
-
Page 9: Start-Up And Use
Start-up and use Measuring out the detergent Starting the dishwasher 1. Turn the water tap on. Dishwasher detergents are strongly alkaline. They can be 2. Press the ON/OFF button. extremely dangerous if swallowed. Avoid contact with the skin and eyes and keep children away from the dishwasher 3. Open the door and pour in a suitable amount of detergent when the door is open. -
Page 10: Wash Cycles
Wash cycles The number and type of wash cycles and options may vary depending on the dishwasher model. Wash cycles Approximate Instructions on wash-cycle selection and Wash cycle with Options duration of detergent dosage drying wash cycles Heavily soiled dishes and pans (not to be used for Delayed start –... -
Page 11: Special Wash Cycles And Options
Special wash cycles and Options Wash options* Half load using the upper rack If there are not many dishes to be washed, a half load cycle The OPTIONS may only be set, modified or reset after the may be used in order to save water, electricity and detergent. wash cycle has been selected and before the Start/Pause Select the wash cycle and press the HALF LOAD button: the button has been pressed. -
Page 12: Rinse Aid And Refined Salt
Rinse aid and refined salt cycle indicator light flashes) Only use products which have been specifically designed Hardness level 3 (1 and 2 wash cycle indicator lights on, for dishwashers. wash cycle indicator light flashes etc.) up to a maximum of Do not use table/industrial salt or washing-up liquid. -
Page 13: Care And Maintenance
Care and maintenance Cleaning the filters The filter assembly consists of three filters which remove food residues from the washing water and then recirculate the water. They should be cleaned if you wish to achieve the best results in every wash. Clean the filters regularly. -
Page 14: Troubleshooting
Troubleshooting Whenever the appliance fails to work, check for a solution from the following list before calling for Assistance. Problem: Possible causes / Solutions: The dishwasher does not start or • Switch off the appliance by pressing the ON/OFF button, switch it back on after cannot be controlled approximately one minute and reset the program. • The appliance has not been plugged in properly. • The dishwasher door has not been shut properly. The door won’t close • The lock was released. Strongly push the door until a “clacking” noise is heard. No water drains out from the • The dishwasher cycle has not yet finished. -
Page 15: Assistance
Please have the following information to hand: • The type of malfunction. • The appliance model (Mod.). • The serial number (S/N). This information can be found on the appliance data plate (see Description of the appliance) . ARISTON GENUINE ACCESSORIES PRIORITY SERVICE & SPARE PARTS If you are not completely satisfi ed... - Page 16 195111817.00 03/2013 pb - Xerox Fabriano...
