- Page 2 Please carefully consider the following before installing your transducer. TRANSDUCER MOUNTING OPTIONS A. Transom Mount- The Humminbird high speed transducer allows the transducer element to be mounted below the bottom of the boat hull keeping the transducer out of turbulent water and...
- Page 3 B. Inside Hull Mount- The high speed transducer can be mounted inside the hull (without pivot assembly) using the proper two-part epoxy, such as Humminbird’s epoxy kit. Even though there is some loss of signal in shooting through the hull, your LCR will perform well with this type of installation.
- Page 4 Once the location is determined mark and drill three 7/64” dia.. holes noted on the template. Attach the metal bracket using three #10 self threading screws supplied. Be sure to align holes in the center of the Bracket slots. On some aluminum boats it may be necessary to use a wood back-up plate. It is important to use a silicone sealant between the screwhead and bracket in order to prevent leaking.
- Page 5 NOTE: On boats with more than 15 degree deadrise angle it may be necessary to mount the transducer slightly off parallel with the water level. (See Figure E) Mark and drill the three 9/64” dia. holes as shown on the template. Attach the metal bracket using the three #10 self threading screws supplied.
- Page 6 Step 4 TRANSDUCER ASSEMBLY- Insert the transducer assembly into the metal bracket from the bottom. Push up until the holes in the plastic pivot align with the uppermost holes in the bracket. Slide the O-ring on to the headed pin and insert it through the two parts. Assemble by screwing the ¼”x3/8”...
- Page 7 Techsonic Industries, Inc. will not be responsible for any damage due to the mounting of your transducer in this manner. NOTE: An Epoxy Kit (Part N. EPK) is available from Humminbird. This Epoxy Kit has been formulated for Inside Hull Transducer Installation.
- Page 8 Position the swivel base and drill four ¼” diameter holes. Note: The LCR hole pattern Is the same as for all Humminbird flasher units. Use hardware provided to mount this base to the boat. Next place the gimbal bracket on the swivel base and attach with four small machine screws, provided.
- Page 9 Install the mounting knobs and tighten snugly. The unit can now be swiveled and tilted to any desired position.
- Page 10 INSTALLING THE CABLES Your LCR comes equipped with Humminbird’s new Angle-Lock power and transducer connectors. The power connector is identified with the letter P on the back of the plug.
- Page 11 It plugs into the outlet on the back of the unit marked “Power”. The transducer connector is identified with the letter T and plugs into the outlet on the back of the unit marked “Transducer”. Note: An adapter (AD-4) is available to allow use of an old waterproof (BNC) transducer with the LCR, but be sure that the transducer is a 16degree.
- Page 13 Increase your boat speed to ensure that you get a continuous bottom reading as the boat moves. Your TCR ID-10 and its Transducer are designed to operate at up to 75 mph so feel free to test them at very high speeds.
- Page 14 The TCR ID-10 uses Humminbird's exclusive double-layer LCD. Ordinary LCD units have 2 colors-black and white. But the TCR ID-10 adds a third color-red-by using a second layer on the display. This double - layer display gives you more information than ordinary black and white units: 1.
- Page 15 60' scale and it changes to the 0-30' scale, the entire screen will look as if you had been in the 0-30' range all along. 2. Using zoom and bottom-lock. Through Pixel Memory Capacity, the memory in the TCR ID-10 stores readings in much finer detail than is displayed in the "regular mode. So when you activate the zoom or bottom-lock functions, the entire screen changes to display the up-close detail that is stored in memory.
- Page 16 Of course, the best way to learn to read your TCR ID-10 is to use it, especially in familiar locations. If you know what's underwater and can see it displayed on the screen, then you're on your way to being an experienced TCR user.
- Page 17 OPERATING THE TCR ID-10 Your new TCR ID-10 offers unique automatic features, as well as many adjustable ones. If you're learning to operate the TCR ID-10 with its simulator, follow the directions listed at "Built-In Simulator" on page 16, and then come back to this page. If you're learning to use your TCR ID10 using actual, on-the-water readings, proceed with the following instructions.
- Page 18 The following describes the functions and how to use them, in order of appearance after you turn the unit on. Sensitivity Automatic setting: on, "O" or normal As conditions change, the computer will automatically increase or decrease the sensitivity setting. You can manually increase or decrease the automatic setting from a range of "+5"...
- Page 19 buttons, you can move the zoom window while the zoom is activated, without having to press Select again. Bottom-Lock Automatic setting: off You can easily turn on the bottom-lock with the On/Off button. When on, this function shows up-close zoom readings in reference to the bottom.
