Table Of Contents

Table of Contents

DO NOT

use or place the transceiver in areas with tem-

peratures below -25°C or above +55°C or, in areas subject

to direct sunlight, such as the dashboard.

AVOID

operating the transceiver without running the vehi-

cle's engine. The vehicle's battery will quickly run out if the

transceiver is in transmission while the vehicle's engine OFF.

AVOID

placing the transceiver in excessively dusty envi-

ronments.

AVOID

placing the transceiver against walls. This will

obstruct heat dissipation.

AVOID

the use of chemical agents such as benzine or

alcohol when cleaning, as they damage the transceiver sur-

faces.

BE CAREFUL!

The transceiver will become hot when

operating continuously for long periods.

For U.S.A. only

CAUTION: Changes or modifications to this transceiver, not ex-

pressly approved by Icom Inc., could void your authority to operate

this transceiver under FCC regulations.

IMPORTANT .................................................................................... i

EXPLICIT DEFINITIONS ................................................................. i

CAUTIONS ....................................................................................... i

TABLE OF CONTENTS .................................................................. ii

1 PANEL DESCRIPTION ........................................................... 1-5

I Front panel ............................................................................... 1

I Function LED ........................................................................... 2

I Programmable function keys .................................................... 3

2 OPERATION ............................................................................ 6-8

I Turning power ON .................................................................... 6

I Channel selection ..................................................................... 6

I Receiving and transmitting ....................................................... 7

D Transmitting notes ................................................................. 7

D Scrambler function ................................................................ 8

D User set mode ....................................................................... 8

3 CONNECTION AND MAINTENANCE .................................. 9-13

I Rear panel and connection ...................................................... 9

I Supplied Accessories ............................................................. 10

I Mounting the transceiver ......................................................... 11

I Optional UT-108 installation ................................................... 11

I Optional UT-109/UT-110 installation ...................................... 12

I Optional OPC-617 installation................................................. 12

I Antenna ................................................................................... 13

I Fuse replacement .................................................................. 13

I Cleaning ................................................................................. 13

4 OPTIONS ................................................................................... 14

5 CE .............................................................................................. 15

Table of Contents

This manual is also suitable for:

If210s Ic-f110s Ic-f210s
