X6DVA-4G/X6DVA-EG User's Manual
Auto-Switching Voltage Regulator for the CPU Core
The auto-switching voltage regulator for the CPU core can support up to
20A current and auto-sense voltage IDs ranging from .8375V to 1.6V. This
will allow the regulator to run cooler and thus make the system more stable.

1-5 ACPI Features

ACPI stands for Advanced Configuration and Power Interface.
specification defines a flexible and abstract hardware interface that pro-
vides a standard way to integrate power management features throughout
a PC system, including its hardware, operating system and application soft-
ware. This enables the system to automatically turn on and off peripherals
such as CD-ROMs, network cards, hard disk drives and printers. This also
includes consumer devices connected to the PC such as VCRs, TVs, tele-
phones and stereos.
In addition to enabling operating system-directed power management, ACPI
provides a generic system event mechanism for Plug and Play and an oper-
ating system-independent interface for configuration control.
ages the Plug and Play BIOS data structures while providing a processor
architecture-independent implementation that is compatible with Windows
2000, Windows NT 5.0, Windows XP, and Windows Server 2003 .
Microsoft OnNow
The OnNow design initiative is a comprehensive, system-wide approach to
system and device power control. OnNow is a term for a PC that is always
on but appears to be off and responds immediately to user or other re-
quests.
Slow Blinking LED for Suspend-State Indicator
When the CPU goes into a suspend state, the chassis power LED will start
blinking to indicate that the CPU is in suspend mode. When the user presses
any key, the CPU will wake-up and the LED will automatically stop blinking
and remain on.
1-12
The ACPI
ACPI lever-
