Page 1
• Please refer to the Setup Guide for basic information ranging from connection of the monitor to a PC or external device to using the monitor. • The latest User’s Manual is available for download from our web site: http://www.eizo.com...
Page 2
EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
The backlight of the LCD panel has a fixed lifetime. When the screen becomes dark or begins to flicker, please contact your EIZO representative. Do not press on the panel or edge of the frame strongly, as this may result in display malfunctions, such as interference patterns, etc.
Cleaning Attention • Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet or panel, and also quality deterioration of the image. • Never use any thinner, benzene, wax, and abrasive cleaner, which may damage the cabinet or panel. Note •...
To adjust the sound level ......28 3-4. Locking Operation Buttons ....... 29 Cleaning ..............4 3-5. Showing and hiding the EIZO logo ... 29 To use the monitor comfortably ......4 3-6. Setting Language ........29 CONTENTS ............. 5 3-7.
Page 6
8-4. Making Use of USB (Universal Serial Bus) ........51 ● Required System Environment ......51 ● Connection procedure (Setup of USB function) ........51 8-5. Displaying Monitor Information ....52 8-6. Specifications ..........53 Chapter 9 Glossary .......... 56 Appendix .............. 58 Trademark ...............
Chapter 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1-1. Features • 23.8″ wide format LCD • Supports a resolution of 1920 × 1080 • Panel with a wide field of view adopted IPS panel with 178 º horizontal and vertical viewing angles.
1-2. Controls and Functions ● Front Setting menu 4 5 6 Detects ambient brightness (Auto EcoView function (page 37), EcoView Optimizer 1. Auto EcoView sensor function (page 38)). Switches input signals for display (page 40). button PC (DVI) → HDMI1 → HDMI2 button Displays the volume adjustment menu to volume up or down.
● Rear 8. Main power switch Turns the main power on or off. 9. Power connector Connects the power cord. (Left: HDMI connector (HDMI1) / Center: HDMI connector (HDMI2) / 10. Input signal connector Right: DVI-D connector) Connects external devices such as a PC. 11.
Remote Control 1. PC Switches to PC signal input. Switches to HDMI signal input. 2. HDMI Each time you press , the system toggles between HDMI1 and HDMI2. 3. MODE Changes the color mode. 4. MENU Displays/Exits the Setting menu. 5.
● Before Using Remote Control How to install battery 1. On the back of the remote control, slide the battery cover off in the direction of an arrow. 2. Insert a battery with the positive side up. (Battery model number: CR2025) 3.
1-3. Basic Operations and Functions ● Basic operation of the Setting menu Displaying the Setting menu 1. Press on the remote control. The Setting menu appears. Adjusting/Setting 1. Choose a menu to adjust/set with , and then press . The Sub menu appears. 2.
“5-1. Setting Power Saving” (page Monitor Settings Key Lock “3-4. Locking Operation Buttons” (page 29) Logo “3-5. Showing and hiding the EIZO logo” (page 29) Power Indicator “5-2. Setting Power Indicator” (page Language “3-6. Setting Language” (page 29) USB Power Save “USB”...
2-2. Setting the Resolution When you connect the monitor to the PC and find that the resolution is improper, or when you want to change the resolution, follow the procedure below. Windows 8.1 / Windows 8 / Windows 7 1. For Windows 8.1 / Windows 8, click the “Desktop” tile on the Start Screen to display the desktop. 2.
• When “G-Ignition” is used, the Color Mode automatically switches to the corresponding setting for the software being used. (“G-Ignition” is a software that can be used to adjust the screen via mouse or keyboard. It is available for download on our website (http://www.eizo.com).) Chapter 2 Adjusting Screens...
● To perform advanced adjustments The “Color” menu of the Setting menu allows you to set and save the independent color adjustment for each mode. Attention • The monitor will take about 30 minutes before its internal electric components stabilize. Wait 30 minutes or more after turning the monitor power on before starting adjustment.
● To adjust brightness The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD back panel). Adjustable range 0 to 100 Procedure 1. Press The Brightness menu appears. 2. Use for adjustment. 3. Press to exit.
● To adjust the color saturation This function allows you to adjust color saturation. Adjustable range -50 to 50 Procedure 1. Choose “Color” in the Setting menu, and press 2. Choose “Saturation” in the “Color” menu, and press The “Saturation” menu appears. 3.
● To adjust color temperature Color temperature can be adjusted. The color temperature is normally used to express the hue of “White” and/or “Black” by a numerical value. The value is expressed in degrees “K” (Kelvin). The screen becomes reddish at a low color temperature, and bluish at a high color temperature, like the flame temperature.
● To adjust gain The brightness of each color component red, green, and blue is called “Gain”. You can change the hue of “white” by adjusting gain. Adjustable range 0 to 100 Procedure 1. Choose “Color” in the Setting menu, and press 2.
● To set the enhancement ratio of ContrastEnhancer This function allows you to automatically adjust the contrast according to the darkness or brightness of an image and change in scenes. You can set the level of the adjustment. Adjustable range Enhanced, Standard, Off Procedure 1.
2-4. Setting the Color Space for the HDMI input signal You can specify the Color Space for the HDMI input signal. If the correct color is not displayed, change the setting to other than “Auto”. √: Can be set -: Cannot be set Video Settings Function...
2-5. Screen Size Changing ● DVI-D Input and HDMI Input (PC signal) The image with the resolution other than the recommended resolution is displayed in full screen automatically. You can change the screen size by using the “Screen Size” function. Setting Function Full Screen...
● HDMI Input (video signal) The screen size can be changed with the “Screen Size” function. Setting Function Screen Display Auto The monitor automatically changes the screen size according to the aspect ratio and resolution information from the external device. This can be set only for HDMI (SD Signal) input.
● To modify blurred characters/lines When an image is displayed with a resolution other than recommended, the characters or lines of the displayed image may blur. Attention • Smoothing setting may not be required depending on the display resolution. (You cannot choose the smoothing icon.) Adjustable range 1 to 5...
Chapter 3 Setting Monitor 3-1. Switching sound source for HDMI signal input This function allows you to switch sound source for HDMI signal input. You can select the HDMI or stereo mini jack. Procedure 1. Choose “Sound” in the Setting menu, and press 2.
● To mute the sound temporarily Procedure 1. Press on the remote control. Mute sound temporarily. By pressing the button again or pressing , the sound comes back. Note • The mute setting can also be released by pressing on the monitor. •...
• Does not lock the remote control operation. 3-5. Showing and hiding the EIZO logo When the monitor is turned on, the EIZO logo appears on the screen. You can choose to show or hide the display of the EIZO logo.
3-7. Changing the authentication method for HDMI signal input The external device cannot be authenticated successfully according to your external device and the screen cannot be displayed. In this case, follow the procedures below to change the authentication method. Procedure 1.
● To reset all adjustments to the default settings This function resets all adjustments to the default settings. Attention • The reset operation cannot return the authentication method for HDMI signal input (“3-7. Changing the authentication method for HDMI signal input” (page 30)) and the exiting method from the power saving mode (“To change the exiting method from the power saving mode”...
Chapter 4 Using Smart Function 4-1. Setting “Smart Detection” This function allows you to select the area on the screen to which the “Smart Resolution” or “Smart Insight 2” setting is applied (only animated images or whole screen). Setting Function Video Detects the animated images on the screen, and applies the setting only to the detected area.
4-2. Setting “Smart Resolution” This function adjusts the perceived resolution of the images so that the blurs are reduced and images are displayed vividly and clearly. In addition, you can correct the color of skin and text affected by the “Smart Resolution”...
4-3. Setting “Smart Insight 2” This function analyzes the image and corrects the brightness for each pixel to make dark area of images visible. It also increases the color saturation. It is effective for images with dark area that are less visible and for bright environments. Attention •...
Chapter 5 Power Saving Functions 5-1. Setting Power Saving ● Monitor This function allows you to specify whether to set the monitor into the power saving mode, depending on the state of an external device connected to it. When the monitor has shifted to the power saving mode, the images on the screen are not displayed.
● To change the exiting method from the power saving mode Change the method of exiting from the power saving mode in the following cases. • To reduce the time for exiting from the power saving mode • The screen is not displayed when a signal is input to the monitor. Procedure 1.
● In case you do not use the “G-Ignition” software for screen adjustment, this function allows you to save power consumption while the screen is turned off or in power saving mode. Attention • When “G-Ignition” is installed, the “USB Power Save” setting will automatically switch to “Disable”. •...
5-4. Reducing Glare “EcoView Optimizer” Using EcoView Optimizer adjusts the screen brightness according to the environment brightness and white level of the input signal. Using this function with Auto EcoView can create a more comfortable level of brightness and reduce glare. Procedure 1.
5-6. Enabling/Disabling Auto Power-OFF “Off Timer” This function allows you to set the time to power off the monitor automatically. Adjustable range Disable, 30, 60, 90, 120, 150, 180 min Procedure 1. Press on the remote control. Each time you press , the set time changes.
Chapter 6 Connecting Cables 6-1. Connecting Multiple External Devices The product has multiple connections to external devices and allows you to switch to one of the connections for display. Attention • Do not use dual link cables. Connection examples HDMI connector DVI-D connector Digital Digital...
6-2. Connecting External Speaker A speaker with built-in amplifier can be connected to this product to output sound from external devices such as PCs and game players. Connection examples Line output connector To a speaker with built-in amplifier Stereo mini jack cable (Commercially available product) Attention •...
Chapter 7 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local EIZO representative. 7-1. No picture Problem Possible cause and remedy 1. No picture • Check whether the power cord is connected properly. • Power indicator does not light.
“To perform advanced adjustments” (page 17)). (The LCD monitor backlight has a limited life span. When the screen becomes dark or begins to flicker, contact your local EIZO representative.) • If the screen is too bright, turn on Auto EcoView and EcoView Optimizer (see “5-3.
7-3. Other problems Problem Possible cause and remedy 1. The “Smoothing” on the Setting menu • You cannot choose “smoothing” when the screen is “Screen” cannot be selected. displayed in the following resolutions or settings. - The resolution is 1920 × 1080 - Screen Size is “Normal”...
Page 45
51)). • Change the USB port to another one. If the PC or peripheral devices works correctly by changing the USB port, contact your local EIZO representative. (Refer to the manual of the PC for details.) • Reboot the PC.
An optional arm (or an optional stand) can be attached by removing the stand section. Please refer to our web site for the corresponding optional arm (or optional stand). http://www.eizo.com Attention • When attaching an arm or stand, follow the instructions of their user’s manual.
Page 47
Remove the caps (two) on the screw holes using the tip of a pen. Attach the arm or stand to the monitor. Secure the monitor to the arm or stand using the screws specified in the user’s manual of the arm or stand.
8-2. Detaching/Attaching Stand Base Detaching procedure The Stand base that was attached during setup can be detached using the following procedures. Lay the LCD monitor on a soft cloth spread over on a stable surface with the panel surface facing down. Turn the fixing screw for the Stand base in the “RELEASE” direction to detach the base.
Page 49
Attaching procedure The once removed the Stand base can be attached to the monitor again with the following procedures. Lay the LCD monitor on a soft cloth spread over on a stable surface with the panel surface facing down. Hold the Stand base with the “REAR” side facing upward, align the hole (a) of the Stand base with the tab (b) at the bottom of the monitor, and snap the tab into the hole.
8-3. Attaching/Detaching Cable Holder A cable holder is supplied with this product. Use the holder to organize the cables connected to the monitor. Attaching procedure Pass the cables through the cable holder. Shut the bottom of the cable holder. While holding the shut section, insert the cable holder into the Stand base. Note •...
• A PC equipped with a USB port. • Windows 8.1 / Windows 8 / Windows 7 / Windows Vista or Mac OS X 10.2 or later and Mac OS 9.2.2 • EIZO USB cable (UU200SS (USB 3.0)) Attention • This monitor may fail to work depending on the PC, OS or peripheral devices to be used. For the USB compatibility of peripheral devices, contact their manufacturers.
8-5. Displaying Monitor Information This function allows you to display the model name, serial number, usage time, resolution, and input signal. Procedure 1. Choose “Information” in the Setting menu, and press The “Information” menu appears. Attention • When you turn on the monitor for the first time, the usage time may be more than 0 due to a factory inspection.
Operating Temperature 5°C to 35°C (41°F to 95°F) Environmental Humidity 20% to 80% R.H. (no condensation) Requirements Air pressure 540 hPa to 1,060 hPa Transportation/ Temperature -20°C to 60°C (-4°F to 140°F) Storage Humidity 10% to 90% R.H. (no condensation) Environmental Air pressure 200 hPa to 1,060 hPa...
Outside Dimensions Unit: mm 344° SWIVEL 52.5 49.4 (219.7) (219.7) 20.4 539.4 527.04 TILT 50.5 Accessories Cleaning Kit EIZO “ScreenCleaner” For the latest information about the accessories, refer to our web site. http://www.eizo.com Chapter 8 Reference...
Chapter 9 Glossary Color Space YUV and RGB, etc. are available. YUV expresses the color by using the luminance (Y), the color difference of Blue (U), and the color difference of Red (V). RGB does this by using the gradation of the 3 colors, Red (R), Green (G), and Blue (B).
Page 57
Overdrive This technology enhances response speed by increasing the potential difference at the time of motion of liquid-crystal pixels, and it is used for liquid-crystal TV sets and others in general. It provides clear-cut three-dimensional display with little afterimage, by improving response speed of the intermediate graduation range that frequently appears in moving images.
ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. ColorNavigator, EcoView NET, EIZO EasyPIX, EIZO Monitor Configurator, EIZO ScreenSlicer, G-Ignition, i • Sound, Re/Vue, Screen Administrator, and UniColor Pro are trademarks of EIZO Corporation. All other company and product names are trademarks or registered trademarks of their respective owners.
ENERGY STAR As an ENERGY STAR Partner, EIZO Corporation has determined that this product meets the ENERGY STAR guidelines for energy efficiency. Appendix...
Changes or modifi cations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specifi ed cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord...
Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor Dieser Monitor ist für Bildschirmarbeitsplätze vorgesehen. Wenn nicht der zum Standardzubehör gehörige Schwenkarm verwendet wird, muss statt dessen ein geeigneter anderer Schwenkarm installiert werden. Bei der Auswahl des Schwenkarms sind die nachstehenden Hinweise zu berücksichtigen: Der Standfuß...
Warranty. EIZO and Distributors will cease to hold or store any parts of the Product upon expiration of seven (7) years after the production of such parts is discontinued. In repairing the monitor, EIZO and Distributors will use renewal parts which comply with our QC standards.
Page 63
Rahmen dieser Garantie hinaus hinsichtlich des Produkts keinerlei Haftung oder Verpfl ichtung dem Erstkäufer oder Dritten gegenüber. EIZO und die Vertriebe verpfl ichten sich, Ersatzteile für das Produkt über einen Zeitraum von sieben (7) Jahren nach Einstellung der Produktion der Ersatzteile zu lagern bzw. anzubieten. EIZO und seine Vertriebspartner verpfl ichten sich, bei einer etwaigen Reparatur des Monitors ausschließlich Produkte gemäß...
Page 64
EIZO et ses Distributeurs cesseront de tenir ou conserver en stock toute pièce de ce Produit après l’expiration de rpfl ichten sich, la période de sept (7) ans suivant l’arrêt de la production de telles pièces. Pour réparer le moniteur, EIZO et ses sstandards zu distributeurs utiliseront des pièces de rechange conformes à...
Page 65
(en lo sucesivo el “Comprador original”) que compró el producto especifi cado en este documento (en riferimento da lo sucesivo el “Producto”) a EIZO o a sus Distribuidores, que EIZO y sus Distribuidores, a su propio criterio, repararán originale”) ch o sustituirán el Producto de forma gratuita si el Comprador original detecta dentro del periodo de la Garantía (indicado...
GARANZIA LIMITATA EIZO Corporation (a cui si farà riferimento da qui in poi con “EIZO”) ed i Distributori autorizzati da EIZO (a cui si farà riferimento da qui in poi con “Distributori”) garantiscono, secondo i termini di questa garanzia limitata (a cui si farà...
Page 67
Garantin är endast giltig i de länder där det finns Distributörer. Garantin begränsar inte några av den Ursprunglige köparens lagstadgade rättigheter. Oavsett andra villkor i denna garanti ska inte EIZO Distributörer under några villkor ha något ansvar i något av de fall som beskrivs nedan: (a) När någon bristfällighet hos Produkten kan härledas till att ha uppstått vid frakt, modifiering, ändring, felaktigt...
Page 68
«Εγγύηση»), στον αρχικό αγοραστή (στο εξής «Αρχικός Αγοραστής») ο οποίος αγόρασε το προϊόν που καθορίζεται στο παρόν έγγραφο (στο εξής «Προϊόν») από την EIZO ή τους Διανομείς, η οποία εξασφαλίζει ότι η EIZO και οι Διανομείς, σύμφωνα με τη διακριτή ευχέρειά τους, είτε θα επισκευάσουν είτε θα αντικαταστήσουν το Προϊόν χωρίς χρέωση εάν ο...
Page 69
Гарантия действительна только в странах или регионах, где расположены Дистрибуторы. Гарантия не ограничивает никакие законные права Первоначального покупателя. Несмотря на другие условия этой Гарантии EIZO и Дистрибуторы не несут никаких обязательств согласно этой Гарантии в любом из перечисленных ниже случаев: (а) Любые...
Cuando desee deshacerse de este producto, póngase en contacto con un distribuidor o una fi lial de su país. Encontrará las direcciones de contacto en el sitio web de EIZO que se indica a continuación. http://www.eizo.com Informazioni sul riciclaggio Per lo smaltimento e il riciclaggio del presente prodotto, attenersi alle normative vigenti nel proprio paese per ridurre l’impatto ambientale.
Page 72
Ten produkt po zużyciu powinien być zbierany i przetwarzany zgodnie z krajowymi przepisami dotyczącymi ochrony środowiska. Wyrzucając ten produkt, należy skontaktować się z lokalnym dystrybutorem lub partnerem. Adresy kontaktowe można znaleźć we wskazanej poniżej witrynie internetowej fi rmy EIZO. http://www.eizo.com...
Page 73
Při likvidaci produktu musí být produkt vyzvednut a recyklován podle zákonů příslušné země, aby nedocházelo k zatěžování životního prostředí. Zbavujete-li se produktu, kontaktujte distributora nebo pobočku ve své zemi. Kontaktní adresy jsou uvedeny na následující webové stránce společnosti EIZO. http://www.eizo.com Ringlussevõtu alane teave...
Page 74
вашата страна за да се намали замърсяването на околната среда. Когато искате да се освободите от този продукт, моля свържете се с търговския му представител или със съответните органи отговарящи за това във вашата страна. Данните за връзка с нас са описани на следния Интернет сайт на EIZO: http://www.eizo.com Informaţie referitoare la reciclare Acest produs, când debarasat, trebuie colectat şi reciclat conform legislaţiei ţării rspective ca să...
