- Page 1 Important Please read this User’s Manual carefully to familiarize yourself with safe and effective usage. Please retain this manual for future reference. Wichtig Bitte lesen Sie diese Bedienungsanleitung sorgfältig durch, um sich mit dem sicheren und rationellen Betrieb dieses Produkts vertraut zu machen. Bewahren Sie das vorliegende Handbuch zu Referenzzwecken auf.
-
Page 2: Canadian Notice
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class A digital device. AC Cord Canadian Notice This Class A digital apparatus complies with Canadian ICES-003. -
Page 4: Safety Symbols
NEC is a registered trademark of NEC Corporation. PC-9801 and PC-9821 are trademarks of NEC Corporation. EIZO, EIZO Logo and DuraVision are registered trademarks of EIZO NANAO CORPORATION in Japan and other countries. All other trademarks are the properties of their respective owners. -
Page 5: Precautions
PRECAUTIONS IMPORTANT • To ensure personal safety and proper maintenance, please read this section and the caution statements on the unit (refer to the figure below). [Location of Caution Statement] WARNING If the unit begins to emit smoke, smells like something is burning, or makes strange noises, disconnect all power connections immediately and contact your dealer for advice. - Page 6 WARNING Use the unit in an appropriate location. Not doing so may result in fire, electric shock, or equipment damage. • Do not place outdoors. • Do not place in a transportation system (ship, aircraft, train, automobile, etc.) where it may be affected by strong vibration or shock.
- Page 7 WARNING Do not touch a damaged LCD panel directly with bare hands. The liquid crystal that may leak from the panel is poisonous if it enters the eyes or mouth. If any part of the skin or body comes in direct contact with the panel, please wash thoroughly. If some physical symptoms result, please consult your doctor.
-
Page 8: Notice For This Monitor
Notice for this monitor This product is suited for displaying surveillance camera images. This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specified in the specifications. This product may not be covered by warranty for uses other than those described in this manual. -
Page 9: Lcd Panel
Cleaning ATTENTION • Never use any solvents or chemicals, such as thinner, benzene, wax, alcohol, and abrasive cleaner, which may damage the cabinet or LCD panel. NOTE • Optional ScreenCleaner is recommended for cleaning the panel surface. ● LCD Panel •... -
Page 10: Table Of Contents
CONTENTS Cover ............. 1 PRECAUTIONS ..........3 Notice for this monitor ..........6 CONTENTS ............. 8 Chapter 1 Introduction ........9 1-1. Features .............. 9 1-2. Package Contents ..........9 1-3. Controls and Functions ........10 Chapter 2 Connecting Cables ......11 2-1. -
Page 11: Chapter 1 Introduction
Chapter 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1-1. Features • 17-inch screen • SXGA (1280 × 1024) display compliant • Analog signal support PC signal: D-Sub mini 15-pin connector × 1 - Horizontal scanning frequency 24.8 kHz - 74.8 kHz - Vertical scanning frequency 56.2 Hz - 75.1 Hz... -
Page 12: Controls And Functions
1-3. Controls and Functions POWER INPUT D-SUB MAINTENANCE VIDEO Displays the volume adjustment menu to volume up or down. button • Displays/Exits the OSD menu. • Pressing the button while the OSD menu is displayed returns you to the button previous menu status. -
Page 13: Chapter 2 Connecting Cables
Chapter 2 Connecting Cables 2-1. Connection Procedures Connects to external equipment compatible with the monitor. • When used as a PC monitor ............ page 11 • When using video equipment..........page 12 ● When used as a PC monitor ATTENTION •... -
Page 14: When Using Video Equipment
(1) Connect the monitor to the PC with a signal cable that matches the connectors. After connecting the cable connectors, tighten the screws of the connectors to secure the coupling. Monitor D-Sub mini 15-pin D-Sub mini 15-pin connector connector Signal cable MD-C87 (optional) DVI connector Signal cable FD-C16 (optional) Audio input... -
Page 15: Adjusting The Screen Height And Angle
Plug the power cord of the monitor into a power outlet. Plug the power cord into a power outlet and the Power connector on the monitor. ATTENTION • For the maximum power saving, it is recommended that the Power button be turned off. Unplugging the power cord completely shuts off power supply to the monitor. -
Page 16: Chapter 3 Settings And Adjustments
Chapter 3 Settings and Adjustments Setting and adjustment of the monitor can be performed using the OSD menu. The Quick-OSD menu is also available to directly operate frequently used functions without starting the OSD menu. 3-1. Using Quick-OSD menu Basic operation of Quick-OSD menu Displaying Quick-OSD Menu Press Setting/adjustment items are switched each time... -
Page 17: Using Osd Menu
3-2. Using OSD menu Basic operation of OSD menu Displaying OSD menu Press to select the menu tab. Setting/Adjusting to select the set/adjust items. for setting/adjustment. Storing/Exiting After completing the setting/adjustment, selecting allows you to store the setting. Selecting repeatedly closes the OSD menu. Functions The settings adjustable in the OSD menu are as shown below. - Page 18 Menu tab Setting / adjustable item Video Setting / adjustable content Setup Backlight 0 to 100 √ √ Adjusts the brightness of the backlight. DPMS On/Off √ √ Switches the power saving setting (DPMS) on or off. The backlight turns off when the synchronized input signal is no longer detected.
-
Page 19: Chapter 4 Troubleshooting
Chapter 4 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local dealer. Common Problems Possible cause and remedy No picture • Check whether the power cord is connected correctly. • Power indicator does not light. •... -
Page 20: Chapter 5 Reference
Chapter 5 Reference 5-1. Attaching an Arm The stand can be removed and replaced with an arm (or another stand) to be attached to the monitor. Use an arm or stand of EIZO option. ATTENTION • When attaching an arm or stand, follow the instructions of their user’s manual. -
Page 21: Specifications
5-2. Specifications LCD Panel Size 17-inch (430 mm) TFT color LCD Surface treatment Anti-glare Surface hardness Viewing angle Horizontal 160°, Vertical 160° (CR : 10 or more) Dot Pitch 0.264 mm Display Area (H × V) 337.9 mm × 270.3 mm Resolution 1280 dots ×... -
Page 22: Outside Dimensions
Main default settings (factory settings) Function PC input Video input Volume Brightness Contrast Sharpness Image size FILL ALL Fill All Color ― Tint ― Backlight DPMS OSD Settings Transparency OSD Timeout Gamma table Light Source scan Video aspect Normal Language English Outside Dimensions unit : mm (inch) -
Page 23: Connector Pin Assignment
Connector Pin Assignment • D-Sub mini 15-pin connector Pin No. Signal Pin No. Signal Pin No. Signal Red video Red video ground Green video Green video ground Data (SDA) Blue video Blue video ground H. Sync V. Sync Ground Ground Clock (SCL) (NC*: No Connection) •... -
Page 24: Preset Timing
5-3. Preset Timing The following table shows the factory preset video timing of the PC. ATTENTION • Display position may be deviated depending on the PC connected, which may require screen adjustment using Setting menu. • If a signal other than those listed in the table is input, adjust the screen using the Setting menu. However, screen display may still be incorrect even after the adjustment. -
Page 25: Limited Warranty
