QuickSpecs
Overview
The HP StorageWorks SB40c is a half-height c-Class storage blade supporting up to six hot-plug Small Form Factor (SFF)
Serial Attached SCSI (SAS) or Serial ATA (SATA) hard disk drives. Using the onboard Smart Array P400, the SB40c
provides industry-leading performance, availability, and storage density, to meet customers' demanding and growing storage
needs. The SB40c supports direct attach storage to HP BladeSystem c-Class Servers.
1. Hard Drive Bay 1
2. Hard Drive Bay 2
3. Hard Drive Bay 3
What's New
Support for HP BladeSystem c3000 Enclosure
Support for 36GB and 72GB, 15K rpm, SFF Serial Attached SCSI (SAS) Hard Drives
At A Glance
Storage Controller:
Smart Array P400 RAID controller with 256MB cache, supports RAID 0/1/5/6 (ADG).
Internal Drive Support:
Supports up to six (6) SAS or SATA hot plug hard disk drives
Allows for the mix of SAS and SATA drives in the same enclosure at the same time
Form Factor:
4U c-Class storage blade
Warranty:
Protected by HP Services and a worldwide network of HP Authorized Channel Partners. Three-year parts, 3
Year Labor and 3 Year on-site limited global warranty. Certain restrictions and exclusions apply. SATA hard
drives have a one year warranty
Models
The SB40c allows for the mix of SAS and SATA drives in the same enclosure at the same time and is tailored to the needs
of HP server blade customers who require optimized direct attach storage.
HP StorageWorks SB40c storage blade
DA - 12587 Worldwide QuickSpecs — Version 7 — 9/12/2007
HP StorageWorks SB40c storage blade
4. Hard Drive Bay 4
5. Hard Drive Bay 5
6. Hard Drive Bay 6
411243-B21
Page 1

Advertisement

loading

Related Manuals for HP StorageWorks SB40c

Summary of Contents for HP StorageWorks SB40c

  • Page 1 Models The SB40c allows for the mix of SAS and SATA drives in the same enclosure at the same time and is tailored to the needs of HP server blade customers who require optimized direct attach storage.

  • Page 2: Product Highlights

    Front panel LEDs indicate drive activity and system health status. Density The SB40c fits into a half height bay on the BladeSystem c3000 and c7000 Enclosure. Fault Tolerance Using the internal Smart Array P400 controller with 256MB DDR2 BBWC, the SB40c can be...
  • Page 3 Intensive compatibility and performance testing with HP BladeSystem c-Class server blades for Integration Testing the highest level of integration available in the industry. Product Kit Contents 5 drive blanks, warranty card, mounting hardware, Enclosure user guide, HP SmartStart CD Kit, documentation CD Operating Systems Microsoft Windows Server 2003, Standard Edition...
  • Page 4 HP Array Configuration Utility (ACU) Powerful Web based configuration utility for all Smart Array controllers Provides a graphical view of HP drive array configurations Allows for management of multiple arrays over a secure internet connection from anywhere in the world Easy to use Wizards for configuration Runs offline for all supported Operating Systems and runs online for Windows and Linux.

  • Page 5: Service And Support, Hp Care Pack, And Warranty Information

    Deployment Services - HP Installation and Start Up services designed to take time, risk, and worry out of the deployment of HP BladeSystem servers - and free customers IT support staff to focus on what they do best, their business.
  • Page 6 Configuration Information - Factory Integrated Models (North America Only) NOTE: For Configure to Order requirements within EMEA region, please consult local Sales Contact. NOTE: HP does not allow factory integration of options into standard models listed above. Configure-to-order servers must start with a CTO Chassis.
  • Page 7 NOTE: Some of the options listed below may be discontinued. c-Class Mezzanines HP PCI Express Mezzanine pass-thru card for HP BladeSystem NOTE: Required to support the HP StorageWorks SB40c Storage Blade (P/N 411243-B21) with HP c-Class BladeSystem full-height server blades Hard Drives...

  • Page 8: Hp Storageworks Sb40C Storage Blade

    DA - 12587 Worldwide QuickSpecs — Version 7 — 9/12/2007 Position Supported Controller Smart Array P400 Controller Position Supported Controller Smart Array P400 Controller HP StorageWorks SB40c storage blade 6 x SFF SAS or SATA Hot Plug Hard Drives Page 8...

  • Page 9: Technical Specifications

    8 lb (3.63 kg) 11 lb (4.99 kg) 3Gb/s SAS 1.5Gb/s SATA Defined by specific HP array controller or SAS/SATA adapter used; please refer to the QuickSpecs and/or User Guide of the specific array controller or adapter System Health LED...
  • Page 10 The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
