Maintenance & Adjustments
Maintenance
General Recommendations
• Always observe safety rules when performing any
maintenance.
• The warranty on this lawn mower does not cover items that
have been subjected to operator abuse or negligence. To
receive full value from warranty, operator must maintain
the lawn mower as instructed here.
• Changing of engine-governed speed will void engine
warranty.
• All adjustments should be checked at least once each
season.
• Periodically check all fasteners and make sure these are
tight.
WARNING:
plug, and ground against engine before performing
any type of maintenance on your machine.
Lubrication
1. Lubricate pivot points on the blade control at least once a
season with light oil. The blade control must operate freely
in both directions. See Fig. 6-1.
14
Always stop engine, disconnect spark
Figure 6-1
2. Lubricate the wheels at least once a season with light oil (or
motor oil). If wheels are removed for any reason, lubricate
the axle bolt and inner surface of the wheel with light oil.
See Fig. 6-1.
3. Lubricate the torsion spring and pivot point on each end of
the grass catcher adapter door at least once a season with
light oil to prevent rust. See Fig. 6-1.
4. The transmission is pre-lubricated and sealed at the factory
and does not require lubrication.
5. Follow the Engine Maintenance section for lubrication
schedule and instruction for engine lubrication.
Deck Care
Clean underside of the mower deck after each use to prevent
build-up of grass clippings or other debris. Follow steps below
for this job.
1. Disconnect spark plug wire. Drain gasoline from lawn
mower or place a piece of plastic under the gas cap.
2. Tip mower so that it rests on the housing. Keep the side
with the air cleaner facing up. Hold mower firmly.
WARNING:
Never tip the mower more than 90º in
any direction and do not leave the mower tipped for
any length of time. Oil can drain into the upper part
of the engine causing a starting problem.
3. Scrape and clean the underside of the deck with a suitable
tool. Do not spray with water.
IMPORTANT: Do not use a pressure washer or garden hose
to clean your unit. These may cause damage to bearings,
or the engine. The use of water will result in shortened life
and reduce serviceability.
4. Put the mower back on its wheels on the ground. If you
had put plastic under the gas cap earlier, make sure to
remove it now.
