Chauvet Rotating Moons CH-208 User Manual

Replacing Fuses
If the unit does not function at all when connected to the main power supply i.e. does not
illuminate after replacing the lamp. Then it is highly likely that the fuse has blown.
Disconnect from main power supply before attempting to replace either lamps or fuse.
In order to replace the fuse, disconnect from the main power supply first, and then unscrew the
fuseholder cover to reveal the fuse. The unit has a label attached which indicates the correct
fuse rating and you will also find this listed as part of the specifications for the unit later in this
guide. It is most important that replacement fuses are of the correct rating. Failure to use the
correct fuse could damage the lighting effect beyond economic repair.
The fuse should simply be placed inside the holder and the screw cap replaced, when this is
done connect to the main power supply to check. If the unit is still not working then please
contact your dealer or CHAUVET for servicing.
Caution
Do not touch unit or lamps while hot.
No user serviceable parts inside, please refer to CHAUVET for service.
Power Connections
The unit is supplied with a power plug appropriate to its voltage and destination. Should any
other connections be required they must be carried out with the following configuration.
Earth = Green/Yellow cable
Neutral = Blue cable
Live = Brown cable
In the USA & Europe, it is required that all plugs are 3-pin type i.e. with Earth/Ground
connection.
In the UK, it is required that all mains plugs are fitted with 5A fuses.
Packing List
Please check contents of your packaging carefully for the following items:
1 x CH-208 Rotating Moon (Master Head)
3 x CH-208 Rotating Moon (Linkable Heads)
4 x BRL Lamps
3 x 3m (10') linking cables
1 x Literature – user guide / warranty card
Technical Specifications
Power 120V~60Hz AC
Fuses 20mm Glass 3.15A Quick Blow
o
2 x 5-pin (180 ) DIN twistlock
Control In/Out
sockets
1 x 12V 50W
Lamps
Part No BRL
Dimensions 241mm x 127mm x 127mm / 9.5in x 5in x 5in
Weight
230V~50Hz AC
20mm Glass 1.6A Quick Blow
o
2 x 5-pin (180 ) DIN twistlock
sockets
1 x 12V 50W
Part No BRL
3.24kg / 7.15lbs
R R R R o o o o t t t t a a a a t t t t i i i i n n n n g g g g M M M M o o o o o o o o n n n n s s s s
CH-208
Users Guide
Please read these instructions carefully before use
World-wide Headquarters:
3000 North 29 th Ct., Hollywood, Florida, USA, FL 33020
Tel: +1-954-929-1115 Fax: +1-954-929-5560
European Office:
Unit 18, Hunslet Trading Estate, Leeds, UK
Tel: +44(0)113-276-0755 Fax: +44(0)113-277-6675
www.ChauvetLighting.com
LS10 1BL
