The Novus Plus is designed to be used with the HRV200PLUS only! The Novus Plus will not vent correctly unless it is
connected to the HRV200PLUS. Refer to the HRV200PLUS installation manual for additional installation and venting in-
structions.
Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to this
manual. For assistance or additional information, consult a qualified installer, service agency or the gas supplier.
11/04
INSTALLATION &
OPERATING INSTRUCTIONS
Do not expose this appliance to the elements (such as rain, etc.).
4031-478 Rev i
NOVUS PLUS
WARNING:
is not followed exactly, a fire or explosion may
result causing property damage, personal in-
jury or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
— What to do if you smell gas
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
— Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
CAUTION:
WARNING!
WARNING!
If the information in this manual
1
Advertisement
Table of Contents
Related Manuals for Heatilator Novus Plus
Summary of Contents for Heatilator Novus Plus
-
Page 1: Operating Instructions
Do not expose this appliance to the elements (such as rain, etc.). WARNING! The Novus Plus is designed to be used with the HRV200PLUS only! The Novus Plus will not vent correctly unless it is connected to the HRV200PLUS. Refer to the HRV200PLUS installation manual for additional installation and venting in- structions. -
Page 2: Table Of Contents
NEVER leave children unattended when there is a fire burning beginning installation procedures. Failure to follow them could in the FAF. cause the Novus Plus Fresh Air Fireplace (FAF) to malfunction NEVER use gasoline, gasoline-type lantern fuel, kerosene, resulting in serious injury and/or property damage. -
Page 3: Gas Appliance Specifications
4. Glass Specifications/Certifications Heatilator gas appliances manufactured with tempered glass may be installed in hazardous locations such as bathtub enclosures as defined by the CPSC. The tempered glass has been tested and certified to the requirements of ANSI Z97.1-1984 and CPSC 16 CFR 1202. -
Page 4: Dimensions, Locations & Clearances
2. Appliance Locations and Space Requirements Figure 1 illustrates a variety of ways the appliance may be located in a room. The Novus Plus may be installed directly on the floor or raised on a hearth. These appliances are certified for installation in a bedroom, bed/sitting room or bathrooms in the U.S. -
Page 5: Framing
NOVUS PLUS INSTALLATION INSTRUCTIONS 3. Clearances Figure 2 shows all clearances that must be maintained around the appliance. See HRV200PLUS installation instructions for venting clearance requirements. CAUTION: Provide adequate clearances around the air openings into the combustion chamber and adequate accessi- bility clearances for servicing and proper operation. -
Page 6: Setting The Appliance
5/8 inch back from the front of the appliance to allow the addition of drywall. WARNING! The Novus Plus must be power vented with the HRV200PLUS and must not be connected to a chimney flue. E. VENTING WARNING! Refer to the HRV200PLUS installation manual for proper venting configurations for the Novus Plus gas appli- ance. -
Page 7: Utilities
NOVUS PLUS INSTALLATION INSTRUCTIONS F. UTILITIES 1. High Altitude Installation The Novus Plus is power vented. High altitude gas appliance considerations are no longer of concern, as long as the gas Note: Have the gas supply line installed in accordance with build-... - Page 8 NOVUS PLUS INSTALLATION INSTRUCTIONS 5. Wiring Note: This appliance must be electrically wired and grounded in accordance with local codes or, in the absence of local codes, with National Electric Code ANSI/NFPA 70-latest edition or the Canadian Electric Code CSA C22.1.
- Page 9 HRV200PLUS Control Wiring The Novus Plus is designed to operate as a system with the HRV200PLUS. Four low-voltage wires are required to electrically connect the two appliances. Common 24 gauge solid conductor thermostat wire, or equivalent may be used. The connections are illustrated in Figure 8.
-
Page 10: Finishing
NOVUS PLUS INSTALLATION INSTRUCTIONS Connect a second two-wire or thermostat wire from the HRV to a wall switch or thermostat to operate the system. This is the recommended way to operate the system. If a remote is added, connect it to the black wire (male connector) and to the white wire (female connector) supplied wired to the terminal block. -
Page 11: Appliance Preparation
NOVUS PLUS INSTALLATION INSTRUCTIONS H. APPLIANCE PREPARATION 1. Attach the Hood 5. Prepare the Appliance The hood is to be located above the glass panel. The hood Log Set must be attached or a fire hazard may result. Locate the four The log set should look similar to that in Figure 14. -
Page 12: Sequence Of Operation
I. SEQUENCE OF OPERATION The Novus Plus must be installed with an HRV200PLUS. The appliance and ventilator operate as a system. The HRV200PLUS controls many of the operational sequences for the system, and the Novus Plus gas appliance maintains safety control for the combustion process. - Page 13 The Novus Plus does the following: The Novus Plus awaits the signal from the HRV200PLUS to light the burners. When the contact between R1 and R2 closes in the HRV200PLUS, the intermittent pilot ignition (IPI) system activates and lights the burners.
-
Page 14: Lighting Instructions
NOVUS PLUS INSTALLATION INSTRUCTIONS J. LIGHTING INSTRUCTIONS 4031-478 Rev i 11/04... -
Page 15: Seasonal Check List
NOVUS PLUS INSTALLATION INSTRUCTIONS K. SEASONAL CHECK LIST WARNING! Children and adults should be alerted to the hazards of high surface temperatures and should stay away to avoid burns or clothing ignition. Young children should be carefully supervised when they are in the same room as the appliance. -
Page 16: Start-Up Issues
NOVUS PLUS INSTALLATION INSTRUCTIONS L. START-UP ISSUES & a l f a l f o l l a i l a i l a i l r i f t n i s l i . f f l l i... -
Page 17: Maintenance Instructions
NOVUS PLUS INSTALLATION INSTRUCTIONS M. MAINTENANCE INSTRUCTIONS 1. Annual Maintenance To reduce the possibility of soot, we have provided your appliance with an adjustable air shutter. Your air shutter To ensure that your appliance operates in a safe and efficient is provided at 1/8 in. - Page 18 Vacuum all remaining glass pieces with a shop vac. DO NOT VACUUM IF THE PIECES ARE HOT! Replace glass with only a Heatilator Glass Panel Assembly ordered through your local distributor. Never use substitute material. Only fully tempered soda lime safety glass or ceramic glass may be used on this appliance.
-
Page 19: Optional Components
NOVUS PLUS INSTALLATION INSTRUCTIONS N. OPTIONAL COMPONENTS COLOR KEY Suffix Finish RC-SMART-HTL Remote Control none Black RC-BATT-HTL Battery-operated Remote Control Brass RCT-MLT-HTL Stainless Steel Multi-Function Remote Control Antique Copper SMART-STAT-HTL Brushed Nickel Remote Control with Thermostat Control Copper SMART-BATT-HTL Battery-operated Remote Control... - Page 20 NOVUS PLUS INSTALLATION INSTRUCTIONS OPTIONAL COMPONENTS (con’t) CABTRIM1 - 30 in. CABTRIM2 - 33 in. CABTRIM3 - 36 in. TKN02S - 30 in. Cabinet Trim TKN32S - 33 in. TKN62B - 36 in. TKN22B/S - 42 in. Full-Face Trim Kits TKN05B/S/PT/BN - 30 in.
- Page 21 NOVUS PLUS INSTALLATION INSTRUCTIONS OPTIONAL COMPONENTS (con’t) Dexen Intermittent Pilot Conversion Kits DCKVN Propane to Natural Gas Conversion Kit (Intermittent Pilot) DCKVP Natural Gas to Propane Conversion Kit (Intermittent Pilot) Includes: Dexen Valve Burner Orifices Plug Orifice (no hole) Pilot Orifice...
-
Page 22: Replacement Parts
O. REPLACEMENT PARTS NOVUS PLUS Service Parts Exploded Parts Diagram Beginning Manufacturing Date: 1/19/04 11/04 4031-478 Rev i 11/04... -
Page 23: Service Parts
NOVUS PLUS Service Parts Service Parts List Beginning Manufacturing Date: 1/19/04 De scription of Pa rt NB4236IPLUS NB4236ILPLUS Qty. Top Standoff 31779 31779 Collar Shield Assy 4031-040 4031-040 Glass Clip Support Assy 33858 33858 Nailing Flange 31190 31190 Grommet 25741... - Page 24 NOVUS PLUS Service Parts Exploded Parts Diagram Beginning Manufacturing Date: 1/19/04 11/04 4031-478 Rev i 11/04...
- Page 25 NOVUS PLUS Service Parts Service Parts List Beginning Manufacturing Date: 1/19/04 De scription of Pa rt NB4236IPLUS NB4236ILPLUS Qty. Valve Plate Gasket 4031-149 4031-149 Pilot As sembly 4021-025 4021-026 Pilot Gasket 4021-042 4021-042 Bulkhead 4031-192 4031-192 Bulkhead Gas ket 4021-043...
- Page 26 NOVUS PLUS INSTALLATION INSTRUCTIONS HOMEOWNER’S NOTES PAGE 4031-478 Rev i 11/04...
-
Page 27: Index
NOVUS PLUS INSTALLATION INSTRUCTIONS INDEX Access, Control Panel 11 Gas Codes 7 Replacement Parts 22 Accessories, Optional 8, 10 Gas Line 7 Rock Wool 12 Air Shutter 17 Gas Pressure 7 Altitude, High Installation 7 Glass Specifications/Certifications 3 Appliance Locations 4... -
Page 28: Warranty
4. Obtain HHT’s consent to any warranty work before the work is done. Additional Information If you would like information on current Heatilator products or want to locate a dealer in your area, call: 1-877-427-8368. 4031-478 Rev i 11/04...
