QuickSpecs
Overview
Standard Features
Options
Memory
Storage
TechSpecs
QuickSpecs
Compaq Deskpro EN Series Small Form Factor
1.
TFT5000 Flat Panel Color
Monitor (optional)
2.
Power Button
3.
Microphone Jack
4.
Headphone Jack
5.
Easy Access Power Supply
6.
SMART III Ultra ATA Hard Drive
7.
Drive Release Latch
What's New
Windows 2000
At A Glance
66-, 100- or 133-MHz Front Side Bus models
®
Intel Pentium
III processor (133 MHz) 733-, 667-, 600E- or 533E- MHz
Intel Pentium III processor
(100 MHz) 500, 550, 600, 650 or 700 MHz
Intel Celeron™ processors
(66 MHz) 466 or 500 MHz
Compact form factor enables easy deployment in small office space
environments.
Compaq Premier Sound™
Compaq Intelligent Manageability
Service-friendly design, including Quick Release Cover Latches, Tilt
Drive Cage and Slide-Out System Board
Energy Star compliant with energy-saving features
Dual Installation Windows 95/98, Windows 95,Windows 98, or Windows
DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000
Compaq Deskpro EN Series Small Form Factor
8.
24X Max Slimline CD-ROM
Drive (optional)
9.
Mouse
10.
Keyboard
11.
1.44-MB Diskette Drive
12.
Tilt Drive Cage
13.
Slide-Out System Board
14.
Removable Expansion Card
Cage
15.
Quick Release Cover Latch
Page 1

Advertisement

loading

Related Manuals for HP EN Series

Summary of Contents for HP EN Series

  • Page 1 QuickSpecs QuickSpecs Overview Standard Features Compaq Deskpro EN Series Small Form Factor Options Memory Storage TechSpecs What's New At A Glance DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor TFT5000 Flat Panel Color...

  • Page 2: Standard Features

    Embedded ATI RAGE PRO TURBO AGP 2X 64-bit Graphics Controller with 4- DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor NT 4.0 pre-installed (model dependent) Protected by Compaq Services, including a three-year, Limited Warranty - Terms and conditions vary by country.
  • Page 3 QuickSpecs Compaq Deskpro EN Series Small Form Factor MB SGRAM upgradable to 8 MB, providing maximum resolution of 1280 x 1024 x 16.7M colors at 85 Hz Audio – One of the following: AC97 (integrated) with Compaq Premier Sound, input/output jacks, internal...
  • Page 4 Processor Cache Memory Memory Standard Maximum DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor 133-MHz Optical Drive 24X Max Slimline CD- ROM Drive Intel Pentium Hard Drive 13.5-GB Ultra ATA 66...
  • Page 5 P667/810e/13.5/64/9 Front Side Bus Processor Cache Memory Memory DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor 133-MHz Optical Drive 24X Max Slimline CD- ROM Drive Intel Pentium Hard Drive 13.5-GB Ultra ATA 66...
  • Page 6 Standard Maximum P650/10+/64/9 Front Side Bus Processor Cache Memory DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor 64 MB Software Windows 95/98 512 MB 100-MHz Optical Drive 24X Max Slimline CD-...
  • Page 7 Cache Memory Memory Standard Maximum P600E/810e/13.5/64/C/4 Front Side Bus Processor DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor Audio Integrated Compaq Premier Sound 64 MB Software Windows 95/98 512 MB 133-MHz...
  • Page 8 Front Side Bus Processor Cache Memory Memory Standard Maximum P600/10+/64/4 DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor 256-KB ECC Graphics Integrated Intel 3D Graphics Audio AC97 with Compaq Premier Sound...
  • Page 9 Front Side Bus Processor Cache Memory Memory Standard Maximum DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor 100-MHz Optical Drive None Intel Pentium Hard Drive 10.0-GB Ultra ATA 66 III 600-MHz...
  • Page 10 P550/6.4/64/C/8 Front Side Bus Processor Cache Memory Memory DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor 100-MHz Optical Drive 24X Max Slimline CD- ROM Drive Intel Pentium Hard Drive 10.0-GB Ultra ATA 66...
  • Page 11 Standard Maximum C500/810/6.4/64/4 Front Side Bus Processor Cache Memory DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor 64 MB Software Windows 98 512 MB 100-MHz Optical Drive 24X Max Slimline CD-...
  • Page 12 Cache Memory Memory Standard Maximum C500/810/4.3/32/5 Front Side Bus Processor DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor Audio AC97 with Compaq Premier Sound 64 MB Software Windows NT 4.0 512 MB...
  • Page 13 Processor Cache Memory Memory Standard Maximum C466/810/6.4/64/5 Front Side Bus DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor 128-KB ECC Graphics Integrated Intel 3D Graphics Audio AC97 with Compaq Premier Sound...
  • Page 14 TechSpecs Bulk 128-MB Memory Kit (bulk) (1 x 128-MB RDRAM 45ns RIMM) DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor Intel Celeron Hard Drive 6.4-GB Ultra ATA 66 466-MHz 128-KB ECC...
  • Page 15 TFT8000 Flat Panel TFT5000 Flat Panel P1610 Color P110 Color P75 Color V1000 Color V900 Color DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor 117670-B21 103994-B21 103993-B21 117676-B21 117675-B21 270812-B21 242805-B21...
  • Page 16 Compaq Microcom 415 56K External Fax Modem w/ Speakerphone Compaq 56K ISA Fax Modem Compaq 56K PCI Fax Modem Compaq Microcom 705 Corporate Communicator DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor 325800-001 325900-001 360562-001 360512-001 154499-002...
  • Page 17 32-MB DIMM and the installation of optional SDRAM Memory Kits. Standard Memory 64-MB DIMM Standard DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor BX chipset and 810 chipset (32-MB) Standard 32 MB Up to...
  • Page 18 This chart does not represent all possible memory configurations. Standard Memory 128-MB RIMM Memory Installed DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor Up to 320 MB Up to 512 MB...
  • Page 19 RDRAM can only support a total of 32 devices. Each memory module contains a different number of devices. Note: All Deskpro EN Series Small Form Factor models come standard with 100-MHz DIMMs. 350-MHz or faster processors can use only 100-MHz DIMMs.

  • Page 20: Drive Support

    Maximum Altitude Operating Non-operating Enhanced Keyboard Dimensions (HxWxD) Weight DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor Drive Support Quantity Supported Removable Media 1.44-MB Diskette Drive Compaq SuperDisk (LS-120 Drive) 2X High-Capacity Floppy...
  • Page 21 Interface Transfer Rate Synchronous (Maximum) 4.3 GB Capacity Height DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor 3.5 in Green 1.44 MB/720 KB 1 in 300 rpm 500/250 Kb/s 18/9 80/80...
  • Page 22 Output Power Operating Conditions Temperature Humidity Dimensions (HxWxD, maximum) Weight DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor 3.5 in/88.9 mm Average Ultra ATA 66 Full-Stroke Rotational Speed 66.6 MB/s Physical...
  • Page 23 Matrox Millennium G400-SD AGP Resolution (maximum) 2048 x 1536 Acceleration Memory DA - 10023 Worldwide QuickSpecs — Version 17 — 5-18-2000 Compaq Deskpro EN Series Small Form Factor 10/100 Base TX PCI 2.2 10 Mb/s 20 Mb/s 100 Mb/s 200 Mb/s RJ-45 IEEE 802.3...
