HP Pavilion dv6900 series Specifications

Specifications HP Pavilion dv6900 Accessories
Processor Δ Intel ® Celeron ® Processor 560 (2.3 GHz, 533 MHz FSB, 1 MB L2 Cache)
Intel ® Pentium ® Dual Core Processor T2390 (1.86 GHz, 533 MHz FSB, 1 MB L2 Cache)
Intel ® Pentium ® Dual Core Processor T2410 (2.0 GHz, 533 MHz FSB, 1 MB L2 Cache)
Intel ® Centrino ® Duo mobile processor technology featuring:
—Intel ® Core ™ 2 Duo Processor T5750 (2.0 GHz, 667 MHz FSB, 2 MB L2 Cache)
—Intel ® Core ™ 2 Duo Processor T5850 (2.16 GHz, 667 MHz FSB, 2 MB L2 Cache)
—Intel ® Core ™ 2 Duo Processor T8100 (2.10 GHz, 800 MHz FSB, 3 MB L2 Cache)
—Intel ® Core ™ 2 Duo Processor T8300 (2.40 GHz, 800 MHz FSB, 3 MB L2 Cache)
—Intel ® Core ™ 2 Duo Processor T9300 (2.50 GHz, 800 MHz FSB, 6 MB L2 Cache)
Operating System Genuine Windows Vista ® Home Basic with Service Pack 1 (SP1) pre-installed
Genuine Windows Vista ® Home Premium with Service Pack 1 (SP1) pre-installed
Chipset Mobile Intel ® GM965 (UMA) and PM965 (discrete) chipset
Graphics Intel Graphics Media Accelerator X3100 (UMA)
NVIDIA GeForce 8400M GS discrete 512 MB (discrete)
Display Panel 15.4" WXGA High-Definition* HP BrightView Widescreen Display (1280 x 800)
Two user-accessible SODIMM slots, DDR2 with dual channel support ø —upgradable to 4 GB
Standard Memory Ω :
—1024 MB
—2048 MB
—3072 MB
—4096 MB Ω
HP xb3000 Notebook Expansion Base
Hard Drive With hard drive up to 320 GB; 120, 160, 250, 320 GB—5400 rpm
Enjoy the comfort of a desktop experience with the
Optical Drive ** LightScribe SuperMulti 8X DVD+/–RW with Double Layer Support, SuperMulti 8X DVD+/–R/RW with
convenience of a notebook.
Double Layer Support, Blu-Ray ∑ ROM with SuperMulti DVD+/–R/RW Double Layer (discrete only)
External Card Expansion ExpressCard/54 slot (also supports ExpressCard/34)
Media Card Integrated 5-in- 1 Digital Media Reader (Secure Digital cards, MultiMedia cards, Memory Stick,
Memory Stick Pro, or xD Picture cards)
Networking/Wireless ** § # High speed 56K modem, Integrated 10/100BASE-T Ethernet LAN (RJ-45 connector), Intel ® PRO/Wireless
3945ABG Network Connection with/without Bluetooth ® , Intel ® PRO/Wireless 3945BG Network
Connection with/without Bluetooth ® , Intel ® PRO/Wireless 4965AGN Network Connection with/without
Bluetooth ® , 802.1 1 b/g with/without Bluetooth ®
Security Kensington ® MicroSaver lock slot; Power-on password; Accepts 3rd party security lock devices,
Integrated Fingerprint reader (selected models only)
I/O Ports ** HP Pavilion Webcam with Integrated Microphone (selected models only), 3 USB 2.0, HDMI (discrete only),
VGA, RJ- 1 1, RJ-45, TV-Out (S-video), Expansion Port 3, 2 headphone out, microphone in, IEEE 1394,
Consumer IR, AC adapter, ExpressCard slot, Kensington lock, Integrated Fingerprint Reader
(selected models only)
Audio Altec Lansing speakers
Keyboard/Touchpad 101 key compatible keyboard, 2 Quick Launch Buttons, Touch Pad with On/Off button and dedicated
vertical Scroll Up/Down pad
**
Battery 6-cell, 12-cell
HP Notebook QuickDock
Power AC adapter—65W, 90W (discrete only)
Stay connected to everything—power, peripherals,
Software Adobe ® Acrobat ® Reader ® , HP Games Powered by Wild Tangent (selected countries), HP Help & Support
entertainment and network—with a single cable
Center, HP Easy Setup, HP Photosmart Essential, HP QuickPlay Windows 3.6, HP Software Update,
Macromedia Flash Player, Muvee AutoProducer Basic Edition (with 20 day trial full version), Symantec ™ Say hi to a cleaner and neater work area with the
Norton Internet Security 2008—consumer (60 days live updates), Cyberlink DVD Suite, Sun Java VM,
Symantec Norton AntiVirus Definition Files Update, User Guide Documentation, HP Wireless Assistant, HP QuickDock that works right out of the box.
™
Microsoft ® Works^, Office Trial: Microsoft ® Office 2007 Home/Student (60 day Trial)^, Office Ready:
Microsoft ® Office 2007 Pro (60 day Trial)^^
* When using a notebook that requires the Expansion Accessory adapter,
Approximate Weight 2.78 kg with 6-cell battery; 3.09 kg with 12-cell battery (varies with configuration)
the monitor must be connected directly to the notebook's VGA port.
Dimension (L x W x H) 35.7 x 25.7 x 2.54 cm (min. height)/4.3 cm (max. height)
(with 6-cell battery)
Δ Intel's numbering is not a measurement of higher performance. GHz refers to internal clock speed of the processor. Other factors besides clock
speed may impact system and application performance.
* High-Definition content (e.g. WMV HD files) is required to view high-definition images. Most current DVDs do not provide high-definition images.
** Some models may not feature all the listed components and may vary depending on configuration.
ø
Dual Channel is only supported when the system is configured with DDR2 symmetric memory (i.e. 2 x 512).
Ω
Supports up to 4 GB DDR2 memory (Dual Channel Memory Support; for 4 GB memory configuration, up to 1 GB may not be available with
32-bit operating systems due to system resource requirements).
∑ For some HD-DVD or Blu-ray titles to play on an external display, an HDMI digital connection may be required with HDCP supported by the
external display. This PC can produce up to 1080p resolution on an external display. This requires a 1080p capable HD TV or monitor.
§ Wireless regulatory differ from country to country.
# Maximum achievable download speeds are currently unknown, may not reach 56Kbps and will vary with line conditions. Upload speeds are
less and also will vary.
^ Only available in Taiwan and Hong Kong.
^^ Available in all countries except Taiwan, Hong Kong and Japan.
Note: Images in this brochure are approximate guides only. Information published may refer to products, programs or services that may not be
available in your country. Please consult your local HP business contact for more information. HP 12-cell and 6-cell battery
Double your battery life and do more on the go.
With the extended battery performance in your bag,
you will always be prepared for anything.
HP QuickPlay 3.6
Certain Windows Vista ® product features require advanced or additional hardware. Windows Vista ® Upgrade Advisor can help you determine
which features of Windows Vista ® will run on your computer. To download the tool, visit www.windowsvista.com/upgradeadvisor.
For Windows Vista ® system requirements, visit www.windowsvista.com/systemrequirements.
© 2008 Hewlett-Packard Development Company, L.P. All rights reserved. Intel, the Intel logo, Intel Core and Core Inside are trademarks of Intel
Corporation in the U.S. and other countries. Microsoft, Windows and the Windows Logo are trademarks or registered trademarks of Microsoft
Corporation in the United States and/or other countries. Windows Vista is either a registered trademark or trademark of Microsoft Corporation
in the United States and/or other countries.
Printed in Singapore, May 2008
HP recommends Windows Vista ® Home Premium.
Great entertainment.
* .
any way, anywhere.
HP Pavilion dv6900 series
Entertainment Notebook PC
Make waves in fashion and technology.
High-definition entertainment now comes wrapped in style and impressive technology.
Outside, the HP Pavilion dv6900 series Entertainment Notebook PC showcases a motif of swirls
to reflect the precision and fluidity that's HP. And inside, cutting-edge technology with optional
NVIDIA discrete graphics, packing an entertainment experience that's superior on every sensory level.
Built on a platform more advanced than ever, housing larger hard disk space, more robust memory
and high-definition support makes the HP Pavilion dv6900 series Notebook PC a premium
entertainment hub, on the go.
