Polaris Vac-Sweep 480 PRO Owner's Manual page 10

Exploded Parts Diagram
1
13
14
15
12
No. Part# Description
1 48-135 All Purpose Bag*
2 48-133 Disposable Bag, 3 per pack*
3 48-130 Bag Clip Assembly
4 48-047 License Plate with Logo
5 C40 Screw, 10-32 x 3/8" SS
Pan Head
6 48-003 Upper Housing/Handle Assy
7 48-141 O-ring, Feed Hose Connector
8 9-100-5107 E-clip, Stainless Steel
9 48-020 Gearbox Assembly
10 48-004 Vacuum Tube/Feedpipe
with two O-rings
11 48-016 O-ring, WMS Upper to Feedpipe 1
12 48-033 Hubcap
13 48-032 WideTrax ® Tire*
14 48-036 Wheel Lock Screw
15 48-034 Bushing
16 48-031 Wheel
4
5
2
7
5
5
8
8
3
9
19
8
17
15
20
18
16
19
22
25
23 26
24
Qty No. Part# Description
1 17 48-006 Chain Kit
1 18 48-035 Wheel Sprocket Kit
2 19 48-060 Axle Block, Wheel
1 20 48-050 Idler Tensioner Assembly
21 48-045 Screw, 10-32 x 7/8" SS
23 Pan Head with Star Washer
1 22 9-100-3105 Sweep Hose Scrubber*
1 23 B25 Orifice Tip w/Orifice Tip Guard 1
3 24 B10 Sweep Hose Wear Ring*
1 25 B5 Sweep Hose Complete*
26 48-019 Nut, Sweep Hose
1 27 48-002 Lower Housing
28 48-010 WMS Assembly with 1 O-ring
3 29 48-008 Vacuum Plate Assembly
3 30 10-112-00 UWF Restrictor Disk, Red & Blue 2
3 31 10-108-00 UWF Restrictor Kit
7 32 6-500-00 UWF
3 33 6-505-00 O-ring, UWF
www.polarispool.com
36
30 32
Pool
Wall
5
31 33 34 35
Feed Hose
10-ft.
6
49
41 37 42
10
44
11
21
41
47
19
27
16 15
14
28
18
17
15
29
Qty No. Part#
1 34 6-503-00
3 35 D29
3 36 9-100-9001 UWF Connector Assembly
1 37 D15
38 **
8 39 48-080
4 40 48-222
41 D10
8 42 D20
1 43 D45
1 44 D50
1 45 G52
1 46 G53
1 47 48-136
48 48-140
1 49 48-070
1
1
39
37 38 40
Feed Hose
10-ft.
43
Leader
10-foot Hose
45
46
To The
Polaris
48
12
13
Description Qty
Pressure Relief Valve 1
Quick Disconnect, UWF 1
1
Nut, Feed Hose 10
Adapter Hose, 8-1/2" 1
In-line Filter Assembly 1
Screen, In-line Filter 2
Float, Feed Hose 11
Swivel Ball Bearing 2
Feed Hose, 10 ft. 2
Leader Hose, 10 ft. 1
Back-up Valve Kit 1
Mechanism for G52 1
Bag Clasp 1
Feed Hose Connector Assembly 1
Feed Hose Assembly 1
* Wear items not covered by warranty.
