QuickSpecs
Product Configuration Wizard
Step 4 - add external storage disk array for additional capacity
NOTE: The latest version of the HP All-in-One Storage Manager (ASM) does support management of both internal storage on the
All-in-One Storage System as well as direct attached MSA storage enclosures. ASM also supports management of tiered storage
environments where both SCSI/SAS or SATA hard drives are attached to the All-in-One Storage System.
External storage enclosure support matrix for HP All-in-One Storage Systems
System Enclosure
AiO600 MSA20
MSA30
AiO600 MSA50
MSA70
AiO600 MSA60
NOTE: For more information on storage enclosures from HP, including product QuickSpecs, please visit
http://h18006.www1.hp.com/storage/disk_storage/msa_diskarrays/drive_enclosures/index.html
HP StorageWorks HP StorageWorks Modular Smart Array 20 (SATA)
Modular Smart Array 20 NOTE: Rack-mountable 12 (SATA) drive enclosure with U320 Host connectivity and
redundant power supplies.
HP StorageWorks Modular Smart Array 20 Starter Kit
NOTE: Rack-mountable 12 (SATA) drive enclosure with U320 Host connectivity and
redundant power supplies. Includes Smart Array 6402/128 Controller.
NOTE: The Modular Smart Array Enclosure 20 Family supports the SATA 1.5Gb/s
3.5" Hot Plug Hard Drives.
HP StorageWorks HP StorageWorks Modular Smart Array 30 SB (SCSI)
Modular Smart Array 30 NOTE: Rack-mountable 14 (SCSI) drive enclosure with single bus and redundant
power supplies
HP StorageWorks Modular Smart Array 30 DB (SCSI)
NOTE: Rack-mountable 14 (SCSI) drive enclosure with dual bus and redundant
power supplies
NOTE: The Modular Smart Array Enclosure 30 Family supports the Wide Ultra3 or
Ultra320 Hot Plug Hard Drives.
HP StorageWorks HP StorageWorks Modular Smart Array 50 (SAS)
Modular Smart Array 50
NOTE: 1U Serial Attach SCSI(SAS) disk drive storage enclosure supporting Small
Form Factor(SFF) SAS or Serial ATA(SATA) drives.
HP StorageWorks HP StorageWorks Modular Smart Array 60 (SAS)
Modular Smart Array 60
NOTE: High capacity 2U disk drive storage enclosure supporting 12 3.5" SAS or
Serial ATA (SATA) drives.
HP StorageWorks HP StorageWorks 70 Modular Smart Array
Modular Smart Array 70
NOTE: Rack-mountable 25 drive (2.5" SAS/SATA) enclosure with 3Gb/s SAS host
connectivity and redundant power supplies.
DA - 12786
HP StorageWorks 600 All-in-One Storage System
Quantity
Supported
1 per SCSI VHDCI connector
2 per connector (supports 1+1
cascading)
4 per connector (supports 1+3
cascading)
Worldwide QuickSpecs — Version 3 — 9.12.2007
(AiO600)
Host Controller or Adapter
Smart Array 642 Controller
Smart Array 6402/128 Controller
Smart Array 6404/256 Controller
HP Smart Array P600/256 BBWC
Controller
HP Smart Array P800/512 BBWC
Controller
HP Smart Array P800/512 BBWC
Controller
335921-B21
366172-B21
302969-B21
302970-B21
364430-B21
418408-B21
418800-B21
