HP Surestore Tape Library 20/700

A5605A Expansion Frame Installation Guide

CAUTION: The HP tape library Expansion Frame is not customer installable or

replaceable. Any servicing, adjustment, maintenance or repair must be performed only

by authorized HP service-trained personnel.

Note to Customer Engineer: This installation may add new technology to the library

that older user's guides do not address. Please remind the customer that the latest user

documentation is available from the HP Customer Care website:

support.

Materials Included

Table 1. Materials List

Installation Notes

• Confirm with the customer System Administrator that the tape library can be powered

off.

• Observe proper power down and power on procedures, as described in the

Installation or Service Manual.

• If you install or replace an Expansion Module you must check mark the appropriate

box on the Drive Location Label. The Drive Location Label is located on the inside of

the library door, just below the UL label.

• Heavy Load. At least three people are required to remove the Expansion Frame from

packaging and push it into position.

Tools Required

Prior to beginning the installation process, obtain the following tools:

• 1/4-inch Ratchet Wrench

(for HP field service use only)

Part

I/I Expansion Frame

Expansion Frame Assembly

1/4-20 x 1/2-in. Torx Screws

Lock Down Latch Tool

62108

http://www.hp.com/go/

Quantity

Summary of Contents for HP Surestore Tape Library Model 20/700

Page 1: Installation Notes
HP Surestore Tape Library 20/700 A5605A Expansion Frame Installation Guide (for HP field service use only) CAUTION: The HP tape library Expansion Frame is not customer installable or replaceable. Any servicing, adjustment, maintenance or repair must be performed only by authorized HP service-trained personnel. Note to Customer Engineer: This installation may add new technology to the library that older user’s guides do not address.
Page 2 Expansion Frame Install Have the operator take the library and all drives offline and power off the tape library. 2. Obtain key and open cartridge area door. CAUTION: Lifting hazard. Two people are required to remove the rear cover. 3. Remove the right rear cover (cover with window) by inserting the lock-down latch tool (see “Special Tools”) between rear cover and the tape library frame on the lower right-hand side of cover to release cover lock-down latch (see Figure 1).
Page 3 Figure 1. Removing Right Rear Cover (Continued) Removing Right Rear Cover (a5605a_01) 1. Rear Cover 2. Mushroom (6x) 3. Lock-Down Latch Tool 4. Lock-Down Latch 5. Mushroom (Ref) 6. Mushroom (Ref) 4. Slide cover up and set aside. 5. Using a T30 Torx driver, remove the mushrooms from the tape library frame (6 places) in the area where the cover was removed (see Figure 1).
Page 4 Figure 2. Theta Stop and Mounting Holes Theta Stop and Mounting Holes (a5605a_02) 1. Mounting Hole Locations 2. Remove Theta Stop 3. Mounting Hole Locations 4. Measure the distance from the floor to the inside floor of library 5. Front Left Plate 62108...
Page 5 CAUTION: Heavy Load. At least three people are required to remove the Expansion Frame from packaging and push it into position. 12. Remove the expansion frame from its package and place it flat on the floor. 13. Measure the distance from the floor of the room to the inside floor of the tape library (see Figure 2).
Page 6 Figure 3. Expansion Frame Alignment Expansion Frame Alignment (a5605a_03) 1. Top Locating Pin 2. 1/4-20 x 1/2-in. Torx Screw (6x) 3. Expansion Frame 4. Leveling Bolt (4x) 5. Bottom Locating Pin CAUTION: Be careful not to hit your head on the theta lock down bracket mounted to the top inside surface of the tape library frame.
Page 7 20. Replace the arrays, the array retainer clips, and cartridges removed in Step 7 back to Panel 2, Column 3 and 4. 21. Close the tape library doors and lock. 22. Power the tape library on and verify that it initializes and audits properly. 23.
