- Page 1 ® MultiConnect rCell 100 Series Router User Guide...
- Page 2 Contacting Multi-Tech Knowledge Base The Knowledge Base provides immediate access to support information and resolutions for all Multi-Tech products. Visit http://www.multitech.com/kb.go. Support Portal To create an account and submit a support case directly to our technical support team, visit: https://support.multitech.com.
-
Page 3: Table Of Contents
CONTENTS Contents Product Overview ..............................5 About MultiConnect rCell 100 Series Router........................ 5 Documentation ................................5 Descriptions of LEDs..............................6 Side Panels ..................................7 Ethernet LED Descriptions ............................7 Specifications ................................8 Dimensions.................................. 10 Power Draw ................................11 RF Specifications ................................. 11 Safety Warnings.............................. - Page 4 CONTENTS Restriction of the Use of Hazardous Substances (RoHS) .................... 20 REACH Statement ............................... 21 Registration of Substances............................21 Substances of Very High Concern (SVHC) ........................ 21 Waste Electrical and Electronic Equipment Statement ....................21 WEEE Directive................................21 Instructions for Disposal of WEEE by Users in the European Union ................ 21 Information on HS/TS Substances According to Chinese Standards .................
-
Page 5: Product Overview
The router has an integrated cellular modem and includes 10/100BaseT Ethernet and RS-232 serial connectivity. An image of the device follows: Documentation The following table describes additional documentation for your device. The documentation is available on the Multi-Tech Installation Resources website at www.multitech.com/setup/product.go. Document Description User Guide This document. -
Page 6: Descriptions Of Leds
PRODUCT OVERVIEW Descriptions of LEDs The top panel contains the following LEDs: ■ Power and Status LEDs—The Power LED indicates that DC power is present and the Status LED blinks when the unit is functioning normally. ■ Modem LEDs—Two modem LEDs indicate carrier detection and link status. ■... -
Page 7: Side Panels
PRODUCT OVERVIEW Side Panels A side panel of the device follows: Not all models have a GPS connector. The figure that follows shows the other side of the device. Ethernet LED Descriptions Two Ethernet LEDs are physically on the RJ-45 connector(s). The table that follows describes these LEDs. Ethernet Link Right LED on Ethernet connector. -
Page 8: Specifications
PRODUCT OVERVIEW Ethernet Speed Left LED on Ethernet connector. Lit when the Ethernet is linked at 100 Mbps. If it is not lit, the Ethernet is linked at 10 Mbps. Specifications MTR-H6 Category Description General Performance HSPA GPRS/EDGE Frequency Tri-Band 850/900/2100 MHz... - Page 9 PRODUCT OVERVIEW Category Description EN55022 Class B Compliance EN55024 Safety UL 60950-1 Compliance IEC 60950-1 Network Compliance Warranty Two years *UL Listed @ 40° C, limited by power supply. UL Certification does not apply or extend to an ambient above 40° C and has not been evaluated by UL for ambient greater than 40°...
-
Page 10: Dimensions
PRODUCT OVERVIEW Dimensions ® MultiConnect rCell 100 Series Router User Guide... -
Page 11: Power Draw
PRODUCT OVERVIEW Power Draw GPRS Typical Maximum Peak TX Peak Rst (Inrush Current) 7 volts 0.305A, 2.14W 0.495A, 3.47W 1.74A 2.30A 9 volts 0.230A, 2.12W 0.332, 3.05W 1.28A 4.12A 20 volts 0.111A, 2.22W 0.164A, 3.28W .520A 3.03A 32 volts 0.075A, 2.40W 0.112A, 3.58W 0.337A 2.50A... -
Page 12: Safety Warnings
SAFETY WARNINGS Safety Warnings Lithium Battery ■ A lithium battery located within the product provides backup power for the timekeeping. This battery has an estimated life expectancy of ten years. ■ When this battery starts to weaken, the date and time may be incorrect. If the battery fails, the board must be sent back to Multi-Tech Systems for battery replacement. -
Page 13: Precautions For Pacemaker Wearers
SAFETY WARNINGS pacemakers and defibrillators from cellular devices. This test method is part of the Association for the Advancement of Medical Instrumentation (AAMI) standard. This standard allows manufacturers to ensure that cardiac pacemakers and defibrillators are safe from cellular device EMI. The FDA continues to monitor cellular devices for interactions with other medical devices. -
Page 14: Cellular Information
CELLULAR INFORMATION Cellular Information Antenna System Cellular Devices The cellular/wireless performance depends on the implementation and antenna design. The integration of the antenna system into the product is a critical part of the design process; therefore, it is essential to consider it early so the performance is not compromised. - Page 15 CELLULAR INFORMATION Category Description Typical Radiated Gain 850 MHz 3.17 dBi 950 MHz 3.51 dBi 1800 MHz 3.55 dBi 1900 MHz 3.0 dBi 2100 MHz 3.93 dBi Radiation Omni-directional Polarization Linear Vertical ® MultiConnect rCell 100 Series Router User Guide...
-
Page 16: Installing And Using The Router
The dimensions illustration in this guide shows the mounting rod, as well as the dimensions for placement of the screws. Activating the Account for Wireless Devices Refer to Multi-Tech’s Cellular Activation Web site at http://www.multitech.com/activation.go for information on activating your cellular modem. Note:... -
Page 17: Installing The Sim Card
INSTALLING AND USING THE ROUTER Installing the SIM Card If you want to operate the router on a GSM/HSPA network, install a SIM card (Subscriber Identity Module). To install the SIM: Locate the SIM card slot on the side of the router. The slot is labeled SIM. Push the SIM card into the slot until it snaps into place. -
Page 18: Regulatory Information
REGULATORY INFORMATION Regulatory Information 47 CFR Part 15 Regulation Class B Devices This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 19: Emc, Safety, And R&Tte Directive Compliance
REGULATORY INFORMATION l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. EMC, Safety, and R&TTE Directive Compliance The CE mark is affixed to this product to confirm compliance with the following European Community Directives: Council Directive 2004/108/EC of 15 December 2004 on the approximation of the laws of Member States relating to electromagnetic compatibility;... -
Page 20: Restriction Of The Use Of Hazardous Substances (Rohs)
REGULATORY INFORMATION Restriction of the Use of Hazardous Substances (RoHS) Multi-Tech Systems, Inc Certificate of Compliance 2011/65/EU Multi-Tech Systems confirms that its embedded products comply with the chemical concentration limitations set forth in the directive 2011/65/EU of the European Parliament (Restriction of the use of certain Hazardous Substances in electrical and electronic equipment - RoHS). -
Page 21: Reach Statement
REGULATORY INFORMATION REACH Statement Registration of Substances After careful review of the legislation and specifically the definition of an “article” as defined in EC Regulation 1907/2006, Title II, Chapter 1, Article 7.1(a)(b), it is our current view Multi-Tech Systems, Inc. products would be considered as “articles”. -
Page 22: Information On Hs/Ts Substances According To Chinese Standards
REGULATORY INFORMATION Information on HS/TS Substances According to Chinese Standards In accordance with China's Administrative Measures on the Control of Pollution Caused by Electronic Information Products (EIP) # 39, also known as China RoHS, the following information is provided regarding the names and concentration levels of Toxic Substances (TS) or Hazardous Substances (HS) which may be contained in Multi-Tech Systems Inc. -
Page 23: Information On Hs/Ts Substances According To Chinese Standards (In Chinese)
REGULATORY INFORMATION Information on HS/TS Substances According to Chinese Standards (in Chinese) 依 依 照 照 中 中 国 国 标 标 准 准 的 的 有 有 毒 毒 有 有 害 害 物 物 质 质 信 信 息 息 根据中华人民共和国信息产业部...
