2 - OPERATION
Configuration parameters per functional blocks
OHA : OverHead Access
EOW interface operating mode :
CO (codirectional) or CT (contra-directional master)
"EOW configuration"
Selection of E1/E2"
AUX interface operating mode (F1);
CO (codirectional) or CT (contra-directional master)
"AUX configuration"
MCF : Message Communications Function
MNGT interface operating mode ;
CO (codirectional) or CT (contra-directional master)
"P port configuration"
Equipment
Session
Selection of clearance level :
Administrator
Operator
Observer
One password by clearance level
(Only the administrator may modify password)
Equipment date and time
Status of slots A, B, C, D (slot configured with an expected card)
Monitoring
Monitoring of modules
A no-monitored card is indicated in the equipment view; not monitoring a
card inhibits the entire management of the faults related to this card (card
and port)
Subrack Monitoring
Monitoring of ports
Not monitoring a port inhibits the entire management of the faults related to
this port
Putting a card into/out of service
(The card is ignored by the management function)
Installation and User Guide - N56717020101
Page A2-6
No reproduction or communication without the written consent of SAGEM SA
Table 2-5 – Configuration parameters (5/6)
Default
value
CT
E1
CT
CO
Admin
No password
"01/01/1970"
A, C:ADR21E120
B, D : ADRIC1.x
No Monitoring
Monitoring
Monitoring
for physical port
No Monitoring
for performance
Service
