- Page 1 Advanced/RH LPX Motherboard Technical Product Specification Order Number 281809-003 April 1996...
- Page 2 ARISING OUT OF ANY PROPOSAL, SPECIFICATION OR SAMPLE. No other license, express or implied, by estoppel or otherwise, to any other intellectual property rights is granted herein. Intel disclaims all liability, including liability for infringement of any proprietary rights, relating to implementation of information in this specification. Intel does not warrant or represent that such implementation(s) will not infringe such rights.
-
Page 3: Table Of Contents
Advanced/RH Technical Product Specification Table of Contents Introduction MOTHERBOARD MANUFACTURING OPTIONS BOARD LEVEL FEATURES LPX FORM FACTOR PROCESSOR UPGRADE SECOND LEVEL CACHE SYSTEM MEMORY PERIPHERAL COMPONENT INTERCONNECT (PCI) PCISET NATIONAL SEMICONDUCTOR PC87306B SUPER I/O CONTROLLER GRAPHICS SUBSYSTEM AUDIO SUBSYSTEM UNIVERSAL SERIAL BUS (USB) - Page 4 Appendix G − − Connectors POWER SUPPLY FRONT PANEL−J3A1 BACK PANEL I/O PERIPHERALS MULTIMEDIA Appendix-H Motherboard BIOS FLASH MEMORY IMPLEMENTATION BIOS UPGRADES SETUP UTILITY PCI AUTO-CONFIGURATION ISA PLUG ‘N’ PLAY ADVANCED POWER MANAGEMENT LANGUAGE SUPPORT PCI IDE BOOT OPTIONS FLASH LOGO AREA SECURITY FEATURES Appendix I −...
-
Page 5: Introduction
The Advanced/RH motherboard integrates the latest advances in processor, memory, and I/O technologies into a standard LPX form factor that provides leading edge technology. This combination of high integration and high performance makes the Advanced/RH motherboard the ideal platform for the increasing requirements of today's (and tomorrow's) desktop applications in the corporate workspace. -
Page 6: Motherboard Manufacturing Options
MOTHERBOARD MANUFACTURING OPTIONS The following manufacturing options are available. Details for each option are found in the corresponding section of this specification. AUDIO SUBSYSTEM Business audio Consumer audio No audio VIDEO SUBSYSTEM ATI VT graphic controller ATI CT graphic controller CACHE SUBSYSTEM Soldered SRAM CELP socket... -
Page 7: Board Level Features
BOARD LEVEL FEATURES E G H I OM04270 Figure 1. Advanced/RH Motherboard Features A − VGA S − PCI / ISA expansion connector † connector B − Parallel port connector T − National PC87306B I/O controller C − COM2 Header U −... -
Page 8: Lpx Form Factor
Advanced/RH. The Advanced/RH LPX form factor does adhere to the standard LPX guidelines in that the outer dimensions are 13” x 9”. Location of the I/O connectors, riser slot, and mounting holes are in strict compliance with the LPX specification. However, if business audio is selected by an OEM, a slight modification to the OEM’s chassis may be necessary to accept the audio jacks on the motherboard. -
Page 9: Processor Upgrade
CPU. SECOND LEVEL CACHE The Intel 82430HX PCIset supports a second level cache that uses high performance Synchronous Pipeline Burst SRAM. Asynchronous cache is not supported by the 82430HX controller. Pipeline Burst (PB) SRAM provides performance similar to expensive Synchronous Burst SRAMs for only a slight cost premium over slower performing asynchronous SRAMs. -
Page 10: Peripheral Component Interconnect (Pci) Pciset
Therefore, once SIMM memory is installed they should not be taller than 1.3”. PERIPHERAL COMPONENT INTERCONNECT (PCI) PCISET The Intel 82430HX PCIset is made up of two components: The 82439HX controller (TXC) and the 82371SB PCI ISA IDE Xcellerator (PIIX3) ISA bridge. The PCIset provides the following functions: •... -
Page 11: National Semiconductor Pc87306B Super I/O Controller
PCI bus master capable of supporting PIO Mode 4 devices with transfer rates up to 22 MB/sec while minimizing the system demands upon the processor. Detailed information on the PCIset is available in the Intel 82430HX PCIset data sheet. NATIONAL SEMICONDUCTOR PC87306B SUPER I/O CONTROLLER Control for the integrated serial ports, parallel port, floppy drive, RTC and keyboard controller is incorporated into a single component, the National Semiconductor PC87306B. -
Page 12: Graphics Subsystem
When the system is plugged in, power is supplied from the LPX power supply’s 5v standby current to extend the life of the battery. See Appendix A for information regarding replacement batteries. -
Page 13: Audio Subsystem
ATI-264VT RESOLUTIONS SUPPORTED BY THE MOTHERBOARD 1 MB 2 MB Max Vertical Resolution SGRAM SGRAM Refresh Rate 640x480x4bpp 100 Hz 640x480x8bpp 100 Hz 640x480x16bpp 100 Hz 640x480x24bpp 100 Hz 640x480x32bpp 60 Hz 800x600x4bpp 100 Hz 800x600x8bpp 100 Hz 800x600x16bpp 100 Hz 800x600x24bpp 100 Hz 1024x768x4bpp... -
Page 14: Universal Serial Bus (Usb)
AUDIO DRIVERS Audio software and utilities are provided for the Advanced/RH motherboard. A Windows setup program installs all of the software programs and utilities onto the system hard drive. Included in the Creative audio software are DOS utilities that allow the user to play a CD-ROM, control sound volume and mixer settings, run diagnostics, and switch between Sound Blaster Pro and Windows Sound System modes. - Page 15 Simm PCI/ISA Expansion Bank 0 (J2D1, J2D2) Socket(6) Connector (J6J2) Bank 1 (J2E1, J2F1) Bank 2 (J2E1, J2F1) CDROM J6N1 J9N2 Modem/Audio Connector J9N1 Floppy Drive J9K1 J9K2 Wave Table PS Remote Connector ATI Media Connector 3.3V (J1H1) Power MIDI Audio J9H1 CELP...
-
Page 16: Front Panel Connections (J3A1, J2A1)
POWER SUPPLY CONTROL (J9H1,J9K2) When used with a power supply that supports remote power on/off, the Advanced/RH motherboard can turn off the system power via software control (“soft-off”). The Powerman utility supplied for Windows 3.1x allows for soft-off as does the shutdown icon in Windows 95 Start menu. The system BIOS will turn the system power off when it receives the proper APM command from the OS. - Page 17 SPEAKER The external speaker provides error beep code information during the Power-On Self Test if the system cannot use the video interface. If no speakers are plugged into the audio output jack, the audio output is redirected to the external PC speaker. SLEEP / RESUME When Advanced Power Management (APM) is activated in the system BIOS and the operating system’s APM driver is loaded, Sleep mode (Stand-By) can be entered in one of three ways: an optional front panel...
-
Page 18: Audio Connectors
AUDIO CONNECTORS There are two methods of accessing the audio features on the Advanced/RH. The method installed depends on the audio option that has been selected. For business audio, audio is accessed using audio jacks provided on the motherboard. These two 1/8” jacks supply Line Out, and Mic In connections and are available through the back I/O panel. - Page 19 WAVE TABLE UPGRADE An eight pin header is provided as part of the consumer audio option to connect to a wave table upgrade card for richer sound quality in both DOS and Windows environments. The wave table upgrade module is simply installed into a standard ISA slot with a cable routed to the connector. Compatible wave table upgrade cards are available from several venders;...
-
Page 20: Back Panel Connectors
BACK PANEL CONNECTORS The back panel provides external access to PS/2 style keyboard and mouse connectors as well as two serial and one parallel port, which are integrated on the Advanced/RH motherboard. If a USB connector is present, COM2 can be routed to a back panel knockout from the COM2 header on the motherboard. -
Page 21: Power Consumption
Power Consumption Tables 3 and 4 list the measured current and voltage requirements for the Advanced/RH motherboard configured with 16 MB of DRAM. Table 5 lists the typical power consumed by the same configuration.. This information is preliminary and is provided only as a guide for calculating approximate total system power usage with additional resources added. -
Page 22: Appendix A − − User-Installable Upgrades
CPU UPGRADE A Type 7 Zero Insertion Force (ZIF) socket provides users with a performance upgrade path to the P54CTB OverDrive technology. LPX form factor makes it easier for the end user to replace the processor. GRAPHICS MEMORY UPGRADE The ATI-264VT graphics subsystem has either 1 or 2MB of SGRAM soldered down on the base board. -
Page 23: Hardware Mpeg Module
HARDWARE MPEG MODULE ATI provides a hardware MPEG module that will work with the Advanced/RH. This module mounts onto connector J1H1, and uses mounting holes provided on the motherboard. This modul is also known as the ATI Multimedia Controller, or AMC. For more information contact ATI Technologies at http://www.atitech.ca, or (905) 882-2626 . -
Page 24: Appendix B − − Configuration Jumper Settings
Appendix B − − Configuration Jumper Settings 13.00" J4L1 J4G1 Clock Speed, CMOS, Password Riser Jumpers J6C2 OverDrive Voltage Jumper Figure B-1. Configuration Jumper locations Advanced/RH Technical Product Specification • • Page 24... - Page 25 JUMPER FUNCTION BLOCK CONFIGURATION FREQ ** See table B-2 below (Note: These jumpers also set PCI, J4L1(C) and ISA clock speeds.) MULT J4L1(D) See table B-2 below (cpu clock multiplier) CMOS J4L1(A) * 4-5 Keep (normal) (resets CMOS settings to default) 5-6 CLR (reset to default) PSWD J4L1(A)
-
Page 26: Cpu Configuration - Jumper Block J4L1(C&D)
CPU CONFIGURATION - JUMPER BLOCK J4L1(C&D) These allow the motherboard to be switched between different speeds of the Pentium processor. These jumpers also affect the PCI and ISA clock speeds according to the following table: Host Bus Host Bus Clk Ratio Clk Ratio CPU Freq. -
Page 27: Drive Or Overdrive - J6C2
DRIVE OR OVERDRIVE - J6C2 Sets the CPU voltage to either standard voltage (3.3v), or OverDrive (3.6v). The Default setting is for a jumper to connect pin 5-6 for standard voltage. Move the jumper to connect pins 4-5 to select OverDrive voltage. RECOVERY JUMPER - J6C2 This jumper should be set to normal mode, Pins 1-2, and should only be moved when a recovery is being performed, i.e. -
Page 28: Appendix C − − Memory Map
Appendix C − − Memory Map Address Range Address Range Size Description 1024K-512M 100000-20000000 511M Extended Memory 960K-1023K F0000-FFFFF AMI System run time BIOS 944K-959K EC000-EFFFF Main BIOS Recovery Code 936K-943K EA000-EBFFF ESCD (Plug ‘N’ Play configuration area) 928K-935K E8000-E9FFF OEM LOGO (available as UMB) 896K-927K E0000-E7FFF... -
Page 29: Appendix D − − I/O Map
Appendix D − − I/O Map Address (hex) Size Description Address (hex) Size Description 0000 - 000F 16 bytes PIIX - DMA 1 0388 - 038B 4 bytes 0020 - 0021 2 bytes PIIX - Interrupt 03B4 - 03B5 2 bytes 002E - 002F 2 bytes Ultra I/O configuration... -
Page 30: Appendix E − − Pci Configuration Space Map
Dev Number (hex) Func. Number Description Intel 82437HX Intel 82371FB (PIIX 3) PCI/ISA bridge Intel 82371FB (PIIX 3) IDE Bus Master Video [ATI] Option PCI expansion Slot for 3 Slot Riser PCI Expansion Slot PCI Expansion Slot Table E-1. Advanced/RH PCI Configuration. Space Map... -
Page 31: Appendix F − − Interrupts & Dma Channels
Appendix F − − Interrupts & DMA Channels System Resource I/O Channel Check Reserved, Interval Timer Reserved, Keyboard buffer full Reserved, Cascade interrupt from slave PIC Serial Port 2 Serial Port 1 Audio Data Width System Resource Floppy 8- or 16-bits Audio Parallel Port 1 8- or 16-bits... -
Page 32: Appendix G − − Connectors
Appendix G − − Connectors POWER SUPPLY PRIMARY POWER J9H1 Name Function PWRGD Power Good +5 V + 5 volts Vcc PCI (3.3V) POWER J9J1 NOT +12 V + 12 volts POPULATED -12 V - 12 volts Name Function Ground Ground Ground Ground... -
Page 33: Front Panel−J3A1
FRONT PANEL − − J3A1 SLEEP/RESUME Signal Name SW_ON SLEEP SLEEPPU POWER INTERFACE HARD INFRA-RED DRIVE LED (DISK) Signal Name Signal Name CONIRRX IRTX PWRPU PWDRV IRRIN HDPU POWER LED / KEYLOCK POWER INTERFACE CPU FAN Signal Name Signal Name PWDRV Ground +12V... -
Page 34: Back Panel I/O
BACK PANEL I/O PS/2 KEYBOARD J8N1 & MOUSE PORTS J7N1 Signal Name Data No Connect Ground Clock SERIAL PORTS COM1 J6N2 & COM2 J5N1 PARALLEL PORT J3N1 Signal Name Signal Name Signal Name STROBE- AUTO FEED- Serial In - (SIN) Data Bit 0 ERROR- Serial Out - (SOUT) -
Page 35: Peripherals
PERIPHERALS IDE CONNECTORS J5C1 & J6C1 Signal Name Signal Name FLOPPY CONNECTOR J9K1 Reset IDE Ground Signal Name Signal Name Host Data 7 Host Data 8 Ground DENSEL Host Data 6 Host Data 9 Ground Reserved Host Data 5 Host Data 10 FDEDIN Host Data 4 Host Data 11... -
Page 36: Multimedia
MULTIMEDIA MIDI/AUDIO CONNECTOR J9L1 Signal Name Signal Name +5 V +5 V JoyStick But0 JoyStick But2 JoyStick X1 JoyStick X2 ATI MULTI-MEDIA CON. (AMC) J1H1 Ground MIDI Out Signal Name Signal Name Ground JoyStick Y2 Ground Data 0 JoyStick Y1 JoyStick But3 Ground Data 1... - Page 37 PCI / ISA RISER (J6J2) Signal Name Signal Name Signal Name Signal Name IOCHK- RSTDRV PCIINT0- PCIINT2- IRQ9 PCIINT1- PCIINT3- DRQ2 -12V 0WS- PCIRST- PCLKF +12V GNT0- IOCHRDY REQ0- GNT1- SMEMW- SA19 SMEMR- PCLKE REQ1- SA18 IOW- AD31 SA17 IOR- AD30 AD29 SA16...
- Page 38 CELP 2.1 CONNECTOR (J1D1) Signal Name Signal Name Signal Name Signal Name TIO0 TIO1 TIO2 TIO7 TIO6 TIO5 TIO4 TIO3 TIO8 TI09 VCC3 VCC5 TWE* TIO10 CADS* CADV* CWE4* COE* CWE6* VCC3 CWE5* VCC5 CWE0* CWE7* CWE2* CWE1* VCC3 VCC5 CCS* CWE3* GWE*...
-
Page 39: Appendix-H Motherboard Bios
IBM, and the ISA and EISA Hi-Flex AMIBIOS Technical Reference published by AMI. Both manuals are available at most technical bookstores. FLASH MEMORY IMPLEMENTATION The Intel 2 Mb Flash component is organized as 32 x 8 (256 KB). The Flash device is divided into five areas, as described in Table H-1. System Address... -
Page 40: Setup Utility
When this option is selected, only devices required to boot the system are assigned resources by the BIOS. Device Node information is available for all devices to ensure compatibility with Windows Copies of the IAL Plug ‘N’ Play specification may be obtained from the Intel BBS or from CompuServe by typing Go PlugPlay. -
Page 41: Language Support
The Advanced/RH BIOS accesses the user area just after completing POST. A utility called USRLUTIL is available on the Intel BBS to assist with installing a logo into flash for display during POST. -
Page 42: Setup Enable Jumper
If the password is forgotten, it can be cleared by turning off the system and setting the "password clear" jumper (See Appendix B: table B-1) to the ON position and briefly powering up the system. The Administrative password and User password are both cleared by this operation. After returning the jumper to the “password keep”... -
Page 43: Appendix I − − Pci Configuration Error Messages
Appendix I − − PCI Configuration Error Messages The following PCI messages are displayed as a group with bus, device and function information. <'NVRAM Checksum Error, NVRAM Cleared'>, \ ; String <'System Board Device Resource Conflict'>, \ ; String <'Primary Output Device Not Found'>, \ ; String <'Primary Input Device Not Found'>, \ ;... -
Page 44: Appendix J− − Amibios Error Messages And Beep Codes
Appendix J− − AMIBIOS Error messages and Beep Codes Errors can occur during POST (Power On Self Test) which is performed every time the system is powered on. Fatal errors, which prevent the system from continuing the boot process, are communicated through a series of audible beeps. -
Page 45: Error Messages (Cont.)
ERROR MESSAGES (CONT.) CMOS Time and Date Not Set Run Standard CMOS Setup to set the date and time in CMOS RAM. Diskette Boot Failure The boot disk in floppy drive A: is corrupt. It cannot be used to boot the system. Use another boot disk and follow the screen instructions. -
Page 46: Appendix K − − Soft-Off Control
Appendix K − − Soft-off Control The Advanced/RH design supports Soft-off control via the SMM code in the BIOS. The CS1 pin out of the National 306B Ultra I/O controller is connected to the Soft-off control line in our power supply circuit. The registers in the Ultra I/O controller that sets the I/O address and control of the CS1 pin is NOT setup until the SMM code is activated. -
Page 47: Appendix L − − Environmental Standards
Appendix L − − Environmental Standards MOTHERBOARD SPECIFICATIONS Parameter Condition Specification Temperature -40 o C to +70 o C Non-Operating +0 o C to +55 o C Operating (minimum air flow of 200 LFM) DC Voltage +5 V ±5 % -5 V ±5 % +12 V... -
Page 48: Appendix M − − Reliability Data
Appendix M − − Reliability Data The Mean-Time-Between-Failures (MTBF) data is calculated from predicted data @ 55C. Advanced/RH motherboard 72706 Hours Advanced/RH Technical Product Specification • • Page 48...
